Infinite - A1705-1800
Specifications
- Type: Outrunner
- Weight: 17.00g (0.60oz)
- Diameter: 21.00mm (0.83in)
- Length: 21.00mm (0.83in)
- Shaft Diameter: 2.00mm (0.08in)
- Maximum Amps: 6
Constants
- kV: 1930
- Rm: 0.6
- Io: 0.55
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 6 | 0.5 | 11010 |
| 7 | 0.55 | 12750 |
| 8 | 0.55 | 14400 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 4x4 | 1 | 7 | 2.25 | 15 | 11100 | 42.0 | 70 | 2.47 | 82% |
| GWS HD 4x4 | 1 | 7 | 2.25 | 15 | 11100 | 42.0 | 70 | 2.47 | 82% |
| GWS HD 4x4 | 1 | 7.4 | 2.45 | 18 | 11700 | 44.3 | 79 | 2.79 | 82% |
| GWS HD 4x4 | 1 | 7.4 | 2.45 | 18 | 11700 | 44.3 | 79 | 2.79 | 82% |
| GWS HD 4x4 | 1 | 7.9 | 2.65 | 20 | 12420 | 47.0 | 88 | 3.10 | 81% |
| GWS HD 4x4 | 1 | 7.9 | 2.65 | 20 | 12420 | 47.0 | 88 | 3.10 | 81% |
| GWS HD 4x4 | 1 | 8.9 | 3.15 | 28 | 13710 | 51.9 | 107 | 3.77 | 80% |
| GWS HD 4x4 | 1 | 8.9 | 3.15 | 28 | 13710 | 51.9 | 107 | 3.77 | 80% |
| GWS HD 4x4 | 1 | 9.9 | 3.6 | 35 | 14880 | 56.4 | 126 | 4.44 | 78% |
| GWS HD 4x4 | 1 | 9.9 | 3.6 | 35 | 14880 | 56.4 | 126 | 4.44 | 78% |
| GWS HD 4x4 | 1 | 10.9 | 4.1 | 44 | 15990 | 60.6 | 146 | 5.15 | 76% |
| GWS HD 4x4 | 1 | 10.9 | 4.1 | 44 | 15990 | 60.6 | 146 | 5.15 | 76% |
| GWS HD 4.5x3 | 1 | 7 | 2.05 | 14 | 11250 | 32.0 | 85 | 3.00 | 83% |
| GWS HD 4.5x3 | 1 | 7 | 2.05 | 14 | 11250 | 32.0 | 85 | 3.00 | 83% |
| GWS HD 4.5x3 | 1 | 7.4 | 2.25 | 16 | 11850 | 33.7 | 94 | 3.32 | 83% |
| GWS HD 4.5x3 | 1 | 7.4 | 2.25 | 16 | 11850 | 33.7 | 94 | 3.32 | 83% |
| GWS HD 4.5x3 | 1 | 7.9 | 2.45 | 19 | 12570 | 35.7 | 105 | 3.70 | 82% |
| GWS HD 4.5x3 | 1 | 7.9 | 2.45 | 19 | 12570 | 35.7 | 105 | 3.70 | 82% |
| GWS HD 4.5x3 | 1 | 8.9 | 2.9 | 25 | 13800 | 39.2 | 128 | 4.52 | 80% |
| GWS HD 4.5x3 | 1 | 8.9 | 2.9 | 25 | 13800 | 39.2 | 128 | 4.52 | 80% |
| GWS HD 4.5x3 | 1 | 9.9 | 3.4 | 33 | 15090 | 42.9 | 154 | 5.43 | 79% |
| GWS HD 4.5x3 | 1 | 9.9 | 3.4 | 33 | 15090 | 42.9 | 154 | 5.43 | 79% |
| GWS HD 4.5x3 | 1 | 10.9 | 3.85 | 41 | 16260 | 46.2 | 180 | 6.35 | 77% |
| GWS HD 4.5x3 | 1 | 10.9 | 3.85 | 41 | 16260 | 46.2 | 180 | 6.35 | 77% |
| Gunther 4.92x4.33 | 1 | 7 | 3.5 | 24 | 9750 | 40.0 | 138 | 4.87 | 72% |
| Gunther 4.92x4.33 | 1 | 7.4 | 3.8 | 28 | 10200 | 41.8 | 152 | 5.36 | 71% |
| Gunther 4.92x4.33 | 1 | 7.9 | 4.3 | 33 | 10770 | 44.2 | 171 | 6.03 | 71% |
| Gunther 4.92x4.33 | 1 | 8.9 | 4.9 | 43 | 11760 | 48.2 | 205 | 7.23 | 68% |
| Gunther 4.92x4.33 | 1 | 9.9 | 5.6 | 55 | 12690 | 52.0 | 239 | 8.43 | 66% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| Gunther 4.92x4.33 | 1 | 10.9 | 6.35 | 69 | 13560 | 55.6 | 279 | 9.84 | 64% |
| Gunther White 4.92x4.33 | 1 | 7 | 3.5 | 24 | 9750 | 40.0 | 138 | 4.87 | 72% |
| Gunther White 4.92x4.33 | 1 | 7.4 | 3.8 | 28 | 10200 | 41.8 | 152 | 5.36 | 71% |
| Gunther White 4.92x4.33 | 1 | 7.9 | 4.3 | 33 | 10770 | 44.2 | 171 | 6.03 | 71% |
| Gunther White 4.92x4.33 | 1 | 8.9 | 4.9 | 43 | 11760 | 48.2 | 205 | 7.23 | 68% |
| Gunther White 4.92x4.33 | 1 | 9.9 | 5.6 | 55 | 12690 | 52.0 | 239 | 8.43 | 66% |
| Gunther White 4.92x4.33 | 1 | 10.9 | 6.35 | 69 | 13560 | 55.6 | 279 | 9.84 | 64% |
| GWS HD 5x3 | 1 | 7 | 2.3 | 16 | 11070 | 31.4 | 102 | 3.60 | 82% |
| GWS HD 5x3 | 1 | 7 | 2.3 | 16 | 11070 | 31.4 | 102 | 3.60 | 82% |
| GWS HD 5x3 | 1 | 7.4 | 2.5 | 18 | 11610 | 33.0 | 113 | 3.99 | 81% |
| GWS HD 5x3 | 1 | 7.4 | 2.5 | 18 | 11610 | 33.0 | 113 | 3.99 | 81% |
| GWS HD 5x3 | 1 | 7.9 | 2.75 | 21 | 12360 | 35.1 | 128 | 4.52 | 81% |
| GWS HD 5x3 | 1 | 7.9 | 2.75 | 21 | 12360 | 35.1 | 128 | 4.52 | 81% |
| GWS HD 5x3 | 1 | 8.9 | 3.2 | 28 | 13500 | 38.4 | 154 | 5.43 | 79% |
| GWS HD 5x3 | 1 | 8.9 | 3.2 | 28 | 13500 | 38.4 | 154 | 5.43 | 79% |
| GWS HD 5x3 | 1 | 9.9 | 3.7 | 36 | 14700 | 41.8 | 183 | 6.46 | 77% |
| GWS HD 5x3 | 1 | 9.9 | 3.7 | 36 | 14700 | 41.8 | 183 | 6.46 | 77% |
| GWS HD 5x3 | 1 | 10.9 | 4.2 | 45 | 15810 | 44.9 | 211 | 7.44 | 75% |
| GWS HD 5x3 | 1 | 10.9 | 4.2 | 45 | 15810 | 44.9 | 211 | 7.44 | 75% |
| GWS HD 5x4.3 | 1 | 7 | 3 | 21 | 10290 | 41.9 | 131 | 4.62 | 76% |
| GWS HD 5x4.3 | 1 | 7 | 3 | 21 | 10290 | 41.9 | 131 | 4.62 | 76% |
| GWS HD 5x4.3 | 1 | 7.4 | 3.3 | 24 | 10890 | 44.3 | 147 | 5.19 | 76% |
| GWS HD 5x4.3 | 1 | 7.4 | 3.3 | 24 | 10890 | 44.3 | 147 | 5.19 | 76% |
| GWS HD 5x4.3 | 1 | 7.9 | 3.6 | 28 | 11430 | 46.5 | 162 | 5.71 | 75% |
| GWS HD 5x4.3 | 1 | 7.9 | 3.6 | 28 | 11430 | 46.5 | 162 | 5.71 | 75% |
| GWS HD 5x4.3 | 1 | 8.9 | 4.2 | 37 | 12630 | 51.4 | 198 | 6.98 | 74% |
| GWS HD 5x4.3 | 1 | 8.9 | 4.2 | 37 | 12630 | 51.4 | 198 | 6.98 | 74% |
| GWS HD 5x4.3 | 1 | 9.9 | 4.75 | 47 | 13620 | 55.5 | 230 | 8.11 | 71% |
| GWS HD 5x4.3 | 1 | 9.9 | 4.75 | 47 | 13620 | 55.5 | 230 | 8.11 | 71% |
| GWS HD 5x4.3 | 1 | 10.9 | 5.35 | 58 | 14580 | 59.4 | 263 | 9.28 | 69% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 5x4.3 | 1 | 10.9 | 5.35 | 58 | 14580 | 59.4 | 263 | 9.28 | 69% |
| GWS HD 6x3 | 1 | 7 | 3.2 | 22 | 10140 | 28.8 | 160 | 5.64 | 75% |
| GWS HD 6x3 | 1 | 7 | 3.2 | 22 | 10140 | 28.8 | 160 | 5.64 | 75% |
| GWS HD 6x3 | 1 | 7.4 | 3.45 | 25 | 10530 | 29.9 | 175 | 6.17 | 74% |
| GWS HD 6x3 | 1 | 7.4 | 3.45 | 25 | 10530 | 29.9 | 175 | 6.17 | 74% |
| GWS HD 6x3 | 1 | 7.9 | 3.85 | 30 | 11190 | 31.8 | 197 | 6.95 | 73% |
| GWS HD 6x3 | 1 | 7.9 | 3.85 | 30 | 11190 | 31.8 | 197 | 6.95 | 73% |
| GWS HD 6x3 | 1 | 8.9 | 4.5 | 40 | 12180 | 34.6 | 240 | 8.47 | 71% |
| GWS HD 6x3 | 1 | 8.9 | 4.5 | 40 | 12180 | 34.6 | 240 | 8.47 | 71% |
| GWS HD 6x3 | 1 | 9.9 | 5.2 | 51 | 13140 | 37.3 | 281 | 9.91 | 69% |
| GWS HD 6x3 | 1 | 9.9 | 5.2 | 51 | 13140 | 37.3 | 281 | 9.91 | 69% |
| GWS HD 6x3 | 1 | 10.9 | 5.9 | 64 | 13950 | 39.6 | 320 | 11.29 | 66% |
| GWS HD 6x3 | 1 | 10.9 | 5.9 | 64 | 13950 | 39.6 | 320 | 11.29 | 66% |
| GWS HD 7x3.5 | 1 | 7 | 4.1 | 28 | 9210 | 30.5 | 203 | 7.16 | 68% |
| GWS HD 7x3.5 | 1 | 7 | 4.1 | 28 | 9210 | 30.5 | 203 | 7.16 | 68% |
| GWS HD 7x3.5 | 1 | 7.4 | 4.4 | 32 | 9570 | 31.7 | 220 | 7.76 | 67% |
| GWS HD 7x3.5 | 1 | 7.4 | 4.4 | 32 | 9570 | 31.7 | 220 | 7.76 | 67% |
| APC SF 7x4 | 1 | 7 | 5.55 | 38 | 7830 | 29.7 | 240 | 8.47 | 58% |
| APC SF 7x4 | 1 | 7 | 5.55 | 38 | 7830 | 29.7 | 240 | 8.47 | 58% |
| APC SF 7x4 | 1 | 7.4 | 6 | 44 | 8010 | 30.3 | 248 | 8.75 | 56% |
| APC SF 7x4 | 1 | 7.4 | 6 | 44 | 8010 | 30.3 | 248 | 8.75 | 56% |
| GWS RS 8x4.3 | 1 | 7 | 6.95 | 48 | 6240 | 25.4 | 262 | 9.24 | 46% |
| GWS RS 8x4.3 | 1 | 7 | 6.95 | 48 | 6240 | 25.4 | 262 | 9.24 | 46% |
| GWS RS 8x4.3 | 1 | 7.4 | 7.4 | 54 | 6330 | 25.8 | 277 | 9.77 | 44% |
| GWS RS 8x4.3 | 1 | 7.4 | 7.4 | 54 | 6330 | 25.8 | 277 | 9.77 | 44% |
