ARC - 2218-3580
Specifications
- Type: Outrunner
- Weight: 73.00g (2.57oz)
- Diameter: 27.60mm (1.09in)
- Length: 38.00mm (1.50in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 35
Constants
- kV: 3750
- Rm: 0.054
- Io: 3.1
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 2.55 | 25980 |
| 8 | 2.75 | 29480 |
| 10 | 3.1 | 36870 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 10x6 | 4.75 | 6.9 | 7.35 | 50 | 5160 | 29.3 | 353 | 12.45 | 95% |
| GWS HD 10x6 | 4.75 | 7.9 | 8.9 | 70 | 5910 | 33.6 | 456 | 16.08 | 95% |
| GWS HD 10x6 | 4.75 | 8.8 | 10.5 | 92 | 6600 | 37.5 | 580 | 20.46 | 95% |
| GWS HD 10x6 | 4.75 | 9.8 | 12.3 | 120 | 7290 | 41.4 | 704 | 24.83 | 94% |
| GWS HD 10x6 | 4.75 | 10.7 | 14.3 | 153 | 7950 | 45.2 | 855 | 30.16 | 94% |
