GPS - 2215-20


GPS - 2215-20

Specifications

  • Type: Outrunner
  • Weight: 63.00g (2.22oz)
  • Maximum Amps: 20

Constants

  • kV: 1240
  • Rm: 0.13
  • Io: 1.35



Io Test Data

Dr Kiwi test results
Volts Amps RPM
10 1.35 12180

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 8x4 1 6.9 5.7 39 7710 29.2 310 10.93 90%
GWS HD 8x4 1 7.9 7 55 8790 33.3 406 14.32 90%
GWS HD 8x4 1 8.9 8.4 74 9660 36.6 495 17.46 88%
GWS HD 8x4 1 9.9 9.9 98 10650 40.3 596 21.02 87%
GWS HD 8x4 1 10.9 11.6 126 11600 43.9 715 25.22 86%
GWS HD 8x4 1 14.6 19.4 283 14460 54.8 1179 41.59 80%
GWS HD 9x5 1 6.9 9.4 64 7350 34.8 491 17.32 86%
GWS HD 9x5 1 7.8 11.5 89 7920 37.5 608 21.45 82%
GWS HD 9x5 1 8.8 13.8 121 8700 41.2 748 26.38 80%
GWS HD 9x5 1 9.8 16.2 158 9330 44.2 880 31.04 77%
GWS HD 10x6 1 6.9 12.1 83 6630 37.7 593 20.92 77%
GWS HD 10x6 1 7.8 14.7 114 7260 41.2 726 25.61 75%
GWS HD 10x6 1 8.8 17.5 154 7920 45.0 866 30.55 73%
GWS HD 10x6 1 9.8 20.3 198 8520 48.4 1004 35.42 70%
GWS HD 10x6 1 10.7 23 246 9000 51.1 1150 40.57 68%
