Exceed - Rocket 2215-3400

Show Similiar

Exceed - Rocket 2215-3400

Specifications

  • Type: Outrunner
  • Weight: 63.00g (2.22oz)
  • Diameter: 38.00mm (1.50in)
  • Length: 35.50mm (1.40in)
  • Shaft Diameter: 3.20mm (0.13in)
  • Maximum Amps: 30

Constants

  • kV: 3195
  • Rm: 0.052
  • Io: 2.45



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 1.9 22010
8 2.05 25120
10 2.45 31590

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 8x4 3 6.9 5.45 37 6990 26.5 251 8.85 95%
GWS HD 8x4 3 7.9 6.5 51 7980 30.2 328 11.57 95%
GWS HD 8x4 3 8.9 7.7 68 8910 33.8 417 14.71 94%
GWS HD 8x4 3 9.9 9.15 90 9900 37.5 529 18.66 94%
GWS HD 8x4 3 10.8 10.55 113 10770 40.8 622 21.94 94%
APC E 8x4 3 6.9 6.5 44 6900 26.1 299 10.55 94%
APC E 8x4 3 7.8 8.2 63 7860 29.8 388 13.69 95%
APC E 8x4 3 8.8 9.45 83 8730 33.1 493 17.39 93%
APC E 8x4 3 9.8 11.25 110 9690 36.7 616 21.73 93%
APC E 8x4 3 10.8 13.3 143 10560 40.0 734 25.89 92%
APC E 8x6 3 6.8 9 61 6690 38.0 330 11.64 92%
APC E 8x6 3 7.8 11.55 90 7560 43.0 442 15.59 91%
APC E 8x6 3 8.7 14 121 8400 47.7 545 19.22 91%
APC E 8x6 3 9.7 16.6 161 9180 52.2 650 22.93 89%
APC E 8x6 3 10.6 19.8 209 9990 56.8 770 27.16 88%
APC E 9x4.5 3 6.8 8.35 56 6660 28.4 427 15.06 92%
APC E 9x4.5 3 7.7 10.5 80 7590 32.3 562 19.82 93%
APC E 9x4.5 3 8.7 12.85 111 8460 36.1 700 24.69 91%
APC E 9x4.5 3 9.6 15.25 146 9240 39.4 850 29.98 90%
APC E 9x4.5 3 10.6 17.95 190 10050 42.8 1006 35.49 89%
APC E 10x5 3 6.7 11.25 75 6480 30.7 570 20.11 91%
APC E 10x5 3 7.7 14.1 108 7320 34.7 745 26.28 89%
APC E 10x5 3 8.7 17.35 150 8130 38.5 920 32.45 88%
APC E 10x5 3 9.6 20.9 200 8910 42.2 1100 38.80 87%
APC E 10x5 3 10.6 24.3 257 10230 48.4 1330 46.91 91%
APC E 11x5.5 3 7.9 19.1 150 7050 36.7 965 34.04 84%
APC E 11x5.5 3 10.9 34.1 371 9300 48.4 1765 62.26 80%
