Exceed - Optima 2220-2700

Show Similiar

Exceed - Optima 2220-2700

Specifications

  • Type: Outrunner
  • Weight: 76.00g (2.68oz)
  • Diameter: 28.00mm (1.10in)
  • Length: 45.20mm (1.78in)
  • Shaft Diameter: 3.20mm (0.13in)
  • Maximum Amps: 30

Constants

  • kV: 2800
  • Rm: 0.069
  • Io: 1.85

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 8x4 2.43 6.8 7.45 50 7200 27.3 327 11.53 92%
APC E 8x4 2.43 7.7 9 69 8160 30.9 427 15.06 92%
APC E 8x4 2.43 8.7 10.7 93 9060 34.3 538 18.98 90%
APC E 8x4 2.43 9.7 12.6 122 10020 38.0 659 23.25 90%
APC E 8x4 2.43 10.6 14.85 157 10890 41.2 794 28.01 89%
APC E 8x6 2.43 6.8 10.45 71 6930 39.4 360 12.70 88%
APC E 8x6 2.43 7.7 13 100 7800 44.3 464 16.37 88%
APC E 8x6 2.43 8.6 15.7 135 8610 48.9 574 20.25 87%
APC E 8x6 2.43 9.6 18.7 179 9390 53.4 700 24.69 85%
APC E 8x6 2.43 10.6 21.6 228 10170 57.8 817 28.82 83%
APC E 9x4.5 2.43 6.8 9.7 65 7020 29.9 469 16.54 90%
APC E 9x4.5 2.43 7.7 12 92 7890 33.6 612 21.59 89%
APC E 9x4.5 2.43 8.7 14.55 126 8730 37.2 740 26.10 87%
APC E 9x4.5 2.43 9.6 17.4 167 9570 40.8 905 31.92 87%
APC E 9x4.5 2.43 10.6 20.3 215 10320 44.0 1060 37.39 84%
APC E 9x6 2.43 6.7 11.9 79 6780 38.5 524 18.48 88%
APC E 9x6 2.43 7.7 14.5 111 7620 43.3 660 23.28 86%
APC E 9x6 2.43 8.7 17.65 153 8430 47.9 815 28.75 84%
APC E 9x6 2.43 9.6 20.7 198 9150 52.0 980 34.57 83%
APC E 9x6 2.43 10.6 24.2 256 9960 56.6 1160 40.92 82%
APC E 10x5 2.43 8 16.9 135 7650 36.2 812 28.64 83%
APC E 10x5 2.43 11.2 26.9 301 10050 47.6 1468 51.78 78%
