Precision Aerobatics - Thrust 20
Specifications
- Type: Outrunner
- Weight: 73.00g (2.57oz)
- Diameter: 37.20mm (1.46in)
- Length: 31.00mm (1.22in)
- Shaft Diameter: 4.00mm (0.16in)
- Maximum Amps: 27
Constants
- kV: 1030
- Rm: 0.144
- Io: 1.05
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 1.05 | 10170 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 9x5 | 1 | 6.9 | 6.4 | 44 | 6330 | 30.0 | 390 | 13.76 | 89% |
| GWS HD 9x5 | 1 | 7.9 | 7.95 | 62 | 7110 | 33.7 | 496 | 17.50 | 87% |
| GWS HD 9x5 | 1 | 8.9 | 9.5 | 84 | 7800 | 36.9 | 606 | 21.38 | 85% |
| GWS HD 9x5 | 1 | 9.9 | 11.25 | 111 | 8550 | 40.5 | 729 | 25.71 | 84% |
| APC E 10x5 | 1 | 6.9 | 8.5 | 58 | 6000 | 28.4 | 486 | 17.14 | 84% |
| APC E 10x5 | 1 | 7.9 | 10.5 | 82 | 6720 | 31.8 | 614 | 21.66 | 83% |
| APC E 10x5 | 1 | 8.8 | 12.7 | 111 | 7380 | 34.9 | 752 | 26.53 | 81% |
| APC E 10x5 | 1 | 9.8 | 15 | 147 | 8010 | 37.9 | 887 | 31.29 | 79% |
| APC E 10x5 | 1 | 10.8 | 17.35 | 187 | 8630 | 40.9 | 1029 | 36.30 | 78% |
| GWS HD 10x6 | 1 | 6.9 | 8.5 | 58 | 6030 | 34.3 | 491 | 17.32 | 85% |
| GWS HD 10x6 | 1 | 7.9 | 10.5 | 82 | 6720 | 38.2 | 619 | 21.83 | 83% |
| GWS HD 10x6 | 1 | 8.9 | 12.5 | 111 | 7410 | 42.1 | 749 | 26.42 | 81% |
| GWS HD 10x6 | 1 | 9.9 | 14.7 | 145 | 8040 | 45.7 | 890 | 31.39 | 79% |
| GWS HD 10x6 | 1 | 10.8 | 17.1 | 184 | 8640 | 49.1 | 1015 | 35.80 | 78% |
| APC SF 11x3.8 | 1 | 6.9 | 11.7 | 80 | 5610 | 20.2 | 643 | 22.68 | 79% |
| APC SF 11x3.8 | 1 | 7.8 | 14.4 | 112 | 6510 | 23.4 | 793 | 27.97 | 81% |
| APC SF 11x3.8 | 1 | 8.8 | 17.45 | 153 | 6660 | 24.0 | 960 | 33.86 | 73% |
| APC SF 11x3.8 | 1 | 9.8 | 20.6 | 201 | 7110 | 25.6 | 1126 | 39.72 | 70% |
| APC SF 11x3.8 | 1 | 10.7 | 23.6 | 252 | 7470 | 26.9 | 1255 | 44.27 | 68% |
| APC E 11x5.5 | 1 | 6.8 | 10.8 | 73 | 5700 | 29.7 | 604 | 21.31 | 81% |
| APC E 11x5.5 | 1 | 7.8 | 13.4 | 104 | 6360 | 33.1 | 755 | 26.63 | 79% |
| APC E 11x5.5 | 1 | 8.8 | 16 | 140 | 6900 | 35.9 | 905 | 31.92 | 76% |
| APC E 11x5.5 | 1 | 9.8 | 18.8 | 184 | 7410 | 38.6 | 1040 | 36.68 | 73% |
| APC E 11x5.5 | 1 | 10.7 | 21.6 | 231 | 7860 | 40.9 | 1202 | 42.40 | 71% |
