Turnigy - SK3 2118-2250
Specifications
- Type: Outrunner
- Weight: 17.00g (0.60oz)
- Diameter: 21.00mm (0.83in)
- Length: 24.50mm (0.96in)
- Shaft Diameter: 2.00mm (0.08in)
- Maximum Amps: 7
Constants
- kV: 2340
- Rm: 0.38
- Io: 1
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.8 | 15660 |
| 8 | 0.85 | 17840 |
| 10 | 1 | 22340 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 4x4 | 1 | 6.9 | 3.7 | 25 | 13080 | 49.5 | 98 | 3.46 | 81% |
| GWS HD 4x4 | 1 | 7.4 | 4.15 | 30 | 13920 | 52.7 | 114 | 4.02 | 80% |
| GWS HD 4x4 | 1 | 7.8 | 4.45 | 34 | 14610 | 55.3 | 123 | 4.34 | 80% |
| GWS HD 4x4 | 1 | 8.8 | 5.25 | 46 | 16110 | 61.0 | 148 | 5.22 | 78% |
| GWS HD 4x4 | 1 | 9.8 | 6.2 | 60 | 17340 | 65.7 | 176 | 6.21 | 76% |
| GWS HD 4x4 | 1 | 10.8 | 7.1 | 76 | 18540 | 70.2 | 203 | 7.16 | 73% |
| GWS HD 4.5x3 | 1 | 7 | 3.6 | 25 | 13530 | 38.4 | 128 | 4.52 | 83% |
| GWS HD 4.5x3 | 1 | 7.4 | 3.9 | 28 | 14130 | 40.1 | 141 | 4.97 | 82% |
| GWS HD 4.5x3 | 1 | 7.8 | 4.35 | 33 | 15000 | 42.6 | 155 | 5.47 | 82% |
| GWS HD 4.5x3 | 1 | 8.8 | 5 | 44 | 16230 | 46.1 | 185 | 6.53 | 79% |
| GWS HD 4.5x3 | 1 | 9.8 | 5.9 | 57 | 17670 | 50.2 | 221 | 7.80 | 77% |
| GWS HD 4.5x3 | 1 | 10.8 | 6.7 | 72 | 18960 | 53.9 | 250 | 8.82 | 75% |
| Gunther White 4.92x4.33 | 1 | 7 | 6 | 42 | 11520 | 47.2 | 199 | 7.02 | 70% |
| Gunther White 4.92x4.33 | 1 | 7.4 | 6.45 | 47 | 12030 | 49.3 | 218 | 7.69 | 69% |
| GWS HD 5x3 | 1 | 7 | 3.7 | 25 | 13350 | 37.9 | 161 | 5.68 | 82% |
| GWS HD 5x3 | 1 | 7.4 | 4.05 | 29 | 13980 | 39.7 | 177 | 6.24 | 81% |
| GWS HD 5x4.3 | 1 | 7 | 5.55 | 38 | 11910 | 48.5 | 185 | 6.53 | 73% |
| GWS HD 5x4.3 | 1 | 7.4 | 5.9 | 43 | 12330 | 50.2 | 197 | 6.95 | 71% |
| GWS HD 6x3 | 1 | 7 | 5.6 | 39 | 12000 | 34.1 | 240 | 8.47 | 73% |
| GWS HD 6x3 | 1 | 7.4 | 5.9 | 43 | 12330 | 35.0 | 255 | 8.99 | 71% |
| GWS HD 7x3.5 | 1 | 7 | 7 | 49 | 10740 | 35.6 | 285 | 10.05 | 66% |
| GWS HD 7x3.5 | 1 | 7.4 | 7.5 | 55 | 11070 | 36.7 | 306 | 10.79 | 64% |
