SunnySky - X2212-6



Specifications

  • Type: Outrunner
  • Weight: 58.00g (2.05oz)
  • Diameter: 27.50mm (1.08in)
  • Length: 30.00mm (1.18in)
  • Shaft Diameter: 3.00mm (0.12in)
  • Maximum Amps: 25

Constants

  • kV: 2030
  • Rm: 0.094
  • Io: 2.4



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 1.95 13820
8 2.1 15970
10 2.4 19680

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 4.1x4.1 1 6.9 4.15 28 13110 50.9 99 3.49 94%
APC E 4.1x4.1 1 7.9 5.1 40 15060 58.5 133 4.69 94%
APC E 4.1x4.1 1 8.8 5.9 51 16740 65.0 161 5.68 94%
APC E 4.1x4.1 1 9.8 6.85 67 18330 71.2 194 6.84 92%
APC E 4.1x4.1 1 10.8 8 86 20040 77.8 233 8.22 91%
EMP 4.1x4.1 1 6.9 4.8 33 13050 50.7 112 3.95 93%
EMP 4.1x4.1 1 7.8 5.9 46 14850 57.7 146 5.15 94%
EMP 4.1x4.1 1 8.8 7 61 16470 63.9 181 6.38 92%
EMP 4.1x4.1 1 9.8 8.2 80 18090 70.2 220 7.76 91%
EMP 4.1x4.1 1 10.8 9.55 103 19650 76.3 259 9.14 90%
APC E 5x5 1 6.8 7.5 51 12390 58.7 155 5.47 90%
APC E 5x5 1 7.8 9.15 71 13890 65.8 198 6.98 88%
APC E 5x5 1 8.8 11.2 98 15510 73.4 248 8.75 87%
APC E 5x5 1 9.7 13 126 16890 80.0 294 10.37 86%
APC E 5x5 1 10.6 14.95 158 18210 86.2 344 12.13 85%
EMP 5x5 1 6.8 7.5 51 12390 58.7 221 7.80 90%
EMP 5x5 1 7.8 9.1 70 13830 65.5 278 9.81 87%
EMP 5x5 1 8.7 11.2 97 15450 73.2 348 12.28 87%
EMP 5x5 1 9.7 13.2 128 16800 79.5 409 14.43 85%
EMP 5x5 1 10.6 15.3 162 18210 86.2 481 16.97 85%
APC E 6x4 1 6.8 8.8 59 11940 45.2 272 9.59 86%
APC E 6x4 1 7.7 10.9 83 13530 51.2 354 12.49 87%
APC E 6x4 1 8.6 13.35 114 15000 56.8 444 15.66 86%
APC E 6x4 1 9.6 15.55 149 16200 61.4 525 18.52 83%
APC E 6x4 1 10.6 17.95 190 17490 66.2 616 21.73 81%
EMP 6x4 1 6.7 8 53 12090 45.8 281 9.91 89%
EMP 6x4 1 7.7 9.8 75 13590 51.5 371 13.09 87%
EMP 6x4 1 8.6 12.15 104 15180 57.5 481 16.97 87%
EMP 6x4 1 9.6 14.25 136 16560 62.7 575 20.28 85%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
EMP 6x4 1 10.6 16.5 174 17790 67.4 683 24.09 83%
EMP 6x5 1 6.7 9.5 63 11790 55.8 338 11.92 87%
EMP 6x5 1 7.7 11.65 89 13200 62.5 427 15.06 84%
EMP 6x5 1 8.6 14.35 123 14610 69.2 533 18.80 84%
EMP 6x5 1 9.6 16.85 161 15990 75.7 633 22.33 82%
EMP 6x5 1 10.6 19.3 204 17100 81.0 732 25.82 79%
APC E 6x5.5 1 6.7 12.1 81 11340 59.1 286 10.09 83%
APC E 6x5.5 1 7.6 14.55 110 12600 65.6 363 12.80 82%
APC E 6x5.5 1 8.6 17.15 147 13830 72.0 442 15.59 79%
APC E 6x5.5 1 9.5 19.8 188 15210 79.2 542 19.12 79%
APC E 6x5.5 1 10.4 22.5 234 16140 84.1 632 22.29 76%
APC E 6x5.5 1 11.1 24.3 269 17100 89.1 684 24.13 76%
APC E 7x5 1 10.5 32.1 337 14610 69.2 1015 35.80 69%
