SunnySky - X2212-13



Specifications

  • Type: Outrunner
  • Weight: 58.00g (2.05oz)
  • Diameter: 27.50mm (1.08in)
  • Length: 30.00mm (1.18in)
  • Shaft Diameter: 3.00mm (0.12in)
  • Maximum Amps: 16

Constants

  • kV: 910
  • Rm: 0.23
  • Io: 0.65



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 0.55 6250
8 0.6 7140
10 0.65 8890

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 8x4 1 6.9 2.45 16 5850 22.2 176 6.21 93%
GWS HD 8x4 1 7.9 3 23 6570 24.9 229 8.08 91%
GWS HD 8x4 1 8.9 3.55 31 7290 27.6 280 9.88 90%
GWS HD 8x4 1 9.9 4.2 41 8040 30.5 343 12.10 89%
GWS HD 8x4 1 10.8 4.9 52 8730 33.1 403 14.22 89%
GWS HD 9x5 1 6.9 4.15 28 5490 26.0 289 10.19 87%
GWS HD 9x5 1 7.8 5 39 6120 29.0 359 12.66 86%
GWS HD 9x5 1 8.8 5.95 52 6750 32.0 438 15.45 84%
GWS HD 9x5 1 9.8 7 68 7350 34.8 527 18.59 82%
GWS HD 9x5 1 10.8 8.2 88 7950 37.6 628 22.15 81%
GWS HD 10x6 1 6.9 5.5 37 5190 29.5 366 12.91 83%
GWS HD 10x6 1 7.8 6.65 51 5760 32.7 448 15.80 81%
GWS HD 10x6 1 8.8 7.9 69 6330 36.0 546 19.26 79%
GWS HD 10x6 1 9.8 9.2 90 6870 39.0 640 22.58 77%
GWS HD 10x6 1 10.7 10.45 111 7380 41.9 731 25.79 76%
GWS HD 11x7 1 6.8 7.85 53 4680 31.0 479 16.90 76%
GWS HD 11x7 1 7.8 9.45 73 5160 34.2 583 20.56 73%
GWS HD 11x7 1 8.7 11.1 96 5610 37.2 690 24.34 71%
GWS HD 11x7 1 9.7 12.7 123 6030 40.0 806 28.43 68%
GWS HD 11x7 1 10.6 14.5 153 6390 42.4 910 32.10 66%
GWS HD 12x6 1 6.8 8.4 57 4560 25.9 525 18.52 74%
GWS HD 12x6 1 7.7 10.05 77 5010 28.5 634 22.36 71%
GWS HD 12x6 1 8.7 11.75 102 5460 31.0 743 26.21 69%
GWS HD 12x6 1 9.6 13.5 129 5850 33.2 874 30.83 67%
GWS HD 12x6 1 10.6 15.05 159 6180 35.1 970 34.22 64%
GWS HD 12x8 1 6.7 10.2 68 4200 31.8 558 19.68 69%
GWS HD 12x8 1 7.7 12.1 93 4590 34.8 660 23.28 66%
GWS HD 12x8 1 8.6 14 120 4920 37.3 760 26.81 63%
GWS HD 12x8 1 9.6 15.9 152 5220 39.5 860 30.34 60%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 12x8 1 10.6 17.7 187 5490 41.6 960 33.86 57%
