SunnySky - X2208-11



Specifications

  • Type: Outrunner
  • Weight: 46.00g (1.62oz)
  • Diameter: 27.60mm (1.09in)
  • Length: 25.00mm (0.98in)
  • Shaft Diameter: 3.00mm (0.12in)
  • Maximum Amps: 15

Constants

  • kV: 1450
  • Rm: 0.193
  • Io: 0.9



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 0.75 10060
8 0.8 11460
10 0.9 14200

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 7x5 1 6.8 6.55 44 8010 37.9 276 9.74 81%
APC E 7x5 1 7.7 8.05 61 8940 42.3 353 12.45 80%
APC E 7x5 1 8.7 9.75 84 9840 46.6 433 15.27 78%
APC E 7x5 1 9.6 11.3 108 10680 50.6 515 18.17 77%
APC E 7x5 1 10.6 13.1 138 11400 54.0 602 21.23 74%
APC E 7x6 1 6.7 7.4 49 7770 44.1 286 10.09 80%
APC E 7x6 1 7.7 8.95 68 8670 49.3 362 12.77 78%
APC E 7x6 1 8.6 10.6 91 9600 54.5 457 16.12 77%
APC E 7x6 1 9.6 12.3 118 10380 59.0 536 18.91 75%
APC E 7x6 1 10.6 14.2 150 11100 63.1 621 21.91 72%
APC Sport 7x7 1 6.8 7.85 53 7680 50.9 230 8.11 78%
APC Sport 7x7 1 7.7 9.45 72 8520 56.5 287 10.12 76%
APC Sport 7x7 1 8.6 11.3 97 9360 62.0 352 12.42 75%
APC Sport 7x7 1 9.6 13.15 126 10140 67.2 417 14.71 73%
APC Sport 7x7 1 10.6 14.75 156 10860 72.0 480 16.93 71%
GWS HD 8x4 1 6.8 6.4 43 8070 30.6 345 12.17 82%
GWS HD 8x4 1 7.7 7.85 60 8970 34.0 432 15.24 80%
GWS HD 8x4 1 8.6 9.5 81 9900 37.5 527 18.59 79%
GWS HD 8x4 1 9.6 11.25 108 10740 40.7 631 22.26 77%
GWS HD 8x4 1 10.6 12.9 136 11460 43.4 716 25.26 75%
GWS HD 9x5 1 6.7 9.85 65 7080 33.5 483 17.04 73%
GWS HD 9x5 1 7.6 11.85 90 7800 36.9 588 20.74 71%
GWS HD 9x5 1 8.6 14 120 8460 40.1 700 24.69 68%
GWS HD 9x5 1 9.6 16.35 156 9030 42.8 814 28.71 65%
GWS HD 9x5 1 10.6 18.4 195 9510 45.0 900 31.75 62%
