TurBORIX - DAT-750
Specifications
- Type: Outrunner
- Weight: 82.00g (2.89oz)
- Shaft Diameter: 4.00mm (0.16in)
- Maximum Amps: 17
Constants
- kV: 827
- Rm: 0.164
- Io: 1.45
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.2 | 5635 |
| 8 | 1.25 | 6427 |
| 10 | 1.45 | 8045 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 10x5 | 1 | 6.9 | 5.35 | 36 | 5040 | 23.9 | 333 | 11.75 | 88% |
| APC E 10x5 | 1 | 7.8 | 6.4 | 49 | 5640 | 26.7 | 413 | 14.57 | 87% |
| APC E 10x5 | 1 | 8.8 | 7.6 | 66 | 6210 | 29.4 | 511 | 18.02 | 85% |
| APC E 10x5 | 1 | 9.8 | 8.95 | 87 | 6810 | 32.2 | 617 | 21.76 | 84% |
| APC E 10x5 | 1 | 10.7 | 10.35 | 110 | 7350 | 34.8 | 724 | 25.54 | 83% |
| APC SF 11x4.7 | 1 | 6.8 | 8.1 | 55 | 4680 | 20.8 | 493 | 17.39 | 83% |
| APC SF 11x4.7 | 1 | 7.7 | 10 | 77 | 5340 | 23.8 | 620 | 21.87 | 84% |
| APC SF 11x4.7 | 1 | 8.7 | 11.9 | 103 | 5640 | 25.1 | 750 | 26.46 | 78% |
| APC SF 11x4.7 | 1 | 9.6 | 14.05 | 134 | 6060 | 27.0 | 900 | 31.75 | 76% |
| APC SF 11x4.7 | 1 | 10.6 | 16.25 | 172 | 6480 | 28.8 | 1047 | 36.93 | 74% |
| APC SF 11x4.7 | 1 | 11.1 | 17.3 | 192 | 6720 | 29.9 | 1123 | 39.61 | 73% |
| APC E 11x5.5 | 1 | 6.8 | 6.65 | 45 | 4860 | 25.3 | 408 | 14.39 | 86% |
| APC E 11x5.5 | 1 | 7.8 | 8.1 | 63 | 5400 | 28.1 | 527 | 18.59 | 84% |
| APC E 11x5.5 | 1 | 8.8 | 9.7 | 85 | 5970 | 31.1 | 645 | 22.75 | 82% |
| APC E 11x5.5 | 1 | 9.7 | 11.4 | 110 | 6480 | 33.8 | 773 | 27.27 | 81% |
| APC E 11x5.5 | 1 | 10.7 | 13.1 | 140 | 6990 | 36.4 | 902 | 31.82 | 79% |
| GWS HD 11x7 | 1 | 6.8 | 7.7 | 52 | 4740 | 31.4 | 478 | 16.86 | 84% |
| GWS HD 11x7 | 1 | 7.8 | 9.3 | 72 | 5280 | 35.0 | 596 | 21.02 | 82% |
| GWS HD 11x7 | 1 | 8.7 | 11 | 95 | 5790 | 38.4 | 710 | 25.04 | 80% |
| GWS HD 11x7 | 1 | 9.7 | 12.85 | 124 | 6300 | 41.8 | 840 | 29.63 | 79% |
| GWS HD 11x7 | 1 | 10.7 | 14.8 | 158 | 6780 | 44.9 | 982 | 34.64 | 77% |
| APC E 11x7 | 1 | 6.8 | 8.45 | 57 | 4650 | 30.8 | 437 | 15.41 | 83% |
| APC E 11x7 | 1 | 7.7 | 10.05 | 77 | 5160 | 34.2 | 545 | 19.22 | 81% |
| APC E 11x7 | 1 | 8.7 | 12 | 104 | 5670 | 37.6 | 669 | 23.60 | 79% |
| APC E 11x7 | 1 | 9.7 | 13.6 | 131 | 6180 | 41.0 | 790 | 27.87 | 77% |
| APC E 11x7 | 1 | 10.8 | 16 | 172 | 6690 | 44.3 | 980 | 34.57 | 75% |
