TurBORIX - 3125-1000
Specifications
- Type: Outrunner
- Weight: 54.00g (1.90oz)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 12
Constants
- kV: 1050
- Rm: 0.3
- Io: 0.85
Io Test Data
Dr Kiwi test results
Volts | Amps | RPM |
---|---|---|
7 | 0.7 | 7140 |
8 | 0.75 | 8180 |
10 | 0.85 | 10150 |
Test Data
Dr Kiwi test results
Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
---|---|---|---|---|---|---|---|---|---|
GWS HD 8x4 | 1 | 6.9 | 3.15 | 21 | 6420 | 24.3 | 204 | 7.20 | 89% |
GWS HD 8x4 | 1 | 7.9 | 3.8 | 30 | 7200 | 27.3 | 259 | 9.14 | 87% |
GWS HD 8x4 | 1 | 8.9 | 4.4 | 39 | 7920 | 30.0 | 317 | 11.18 | 85% |
GWS HD 8x4 | 1 | 9.8 | 5.1 | 49 | 8640 | 32.7 | 381 | 13.44 | 84% |
GWS HD 8x4 | 1 | 10.8 | 5.9 | 63 | 9360 | 35.5 | 450 | 15.87 | 83% |
GWS HD 9x5 | 1 | 6.9 | 5.3 | 36 | 5820 | 27.6 | 329 | 11.61 | 80% |
GWS HD 9x5 | 1 | 7.8 | 6.35 | 49 | 6450 | 30.5 | 408 | 14.39 | 79% |
GWS HD 9x5 | 1 | 8.8 | 7.45 | 65 | 7050 | 33.4 | 495 | 17.46 | 76% |
GWS HD 9x5 | 1 | 9.8 | 8.55 | 83 | 7650 | 36.2 | 581 | 20.49 | 74% |
GWS HD 9x5 | 1 | 10.7 | 9.7 | 103 | 8160 | 38.6 | 670 | 23.63 | 73% |
GWS HD 9x5 | 1 | 11.1 | 10 | 111 | 8310 | 39.3 | 690 | 24.34 | 71% |
GWS HD 10x6 | 1 | 6.9 | 6.75 | 46 | 5460 | 31.0 | 402 | 14.18 | 75% |
GWS HD 10x6 | 1 | 7.8 | 7.9 | 61 | 6000 | 34.1 | 479 | 16.90 | 73% |
GWS HD 10x6 | 1 | 8.8 | 9.3 | 81 | 6540 | 37.2 | 579 | 20.42 | 71% |
GWS HD 10x6 | 1 | 9.7 | 10.6 | 102 | 7020 | 39.9 | 667 | 23.53 | 69% |
GWS HD 10x6 | 1 | 10.7 | 11.85 | 126 | 7470 | 42.4 | 757 | 26.70 | 66% |
GWS HD 11x7 | 1 | 6.8 | 8.9 | 60 | 4860 | 32.2 | 509 | 17.95 | 68% |
GWS HD 11x7 | 1 | 7.4 | 9.9 | 73 | 5130 | 34.0 | 567 | 20.00 | 66% |
GWS HD 11x7 | 1 | 7.7 | 10.5 | 80 | 5340 | 35.4 | 606 | 21.38 | 66% |
GWS HD 11x7 | 1 | 8.7 | 12 | 104 | 5700 | 37.8 | 707 | 24.94 | 62% |
GWS HD 11x7 | 1 | 9.6 | 13.55 | 130 | 6060 | 40.2 | 794 | 28.01 | 60% |
GWS HD 11x7 | 1 | 10.6 | 15.1 | 160 | 6390 | 42.4 | 889 | 31.36 | 57% |
