TurBORIX - 3125-1800
Specifications
- Type: Outrunner
- Weight: 46.00g (1.62oz)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 14
Constants
- kV: 1640
- Rm: 0.246
- Io: 0.85
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.7 | 11200 |
| 8 | 0.75 | 12800 |
| 10 | 0.85 | 15890 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| EMP 5x5 | 1 | 6.9 | 3.7 | 25 | 10080 | 47.7 | 145 | 5.11 | 89% |
| EMP 5x5 | 1 | 7.9 | 4.5 | 35 | 11280 | 53.4 | 183 | 6.46 | 87% |
| EMP 5x5 | 1 | 8.9 | 5.35 | 47 | 12480 | 59.1 | 227 | 8.01 | 86% |
| EMP 5x5 | 1 | 9.9 | 6.3 | 62 | 13680 | 64.8 | 271 | 9.56 | 84% |
| EMP 5x5 | 1 | 10.8 | 7.2 | 77 | 14700 | 69.6 | 313 | 11.04 | 83% |
| EMP 5x5 | 1 | 14 | 10.7 | 149 | 18030 | 85.4 | 474 | 16.72 | 79% |
| EMP 6x4 | 1 | 6.9 | 4.1 | 28 | 9930 | 37.6 | 183 | 6.46 | 88% |
| EMP 6x4 | 1 | 7.9 | 5 | 39 | 11200 | 42.4 | 233 | 8.22 | 86% |
| EMP 6x4 | 1 | 8.9 | 5.9 | 52 | 12300 | 46.6 | 296 | 10.44 | 84% |
| EMP 6x4 | 1 | 9.8 | 6.8 | 66 | 13440 | 50.9 | 353 | 12.45 | 84% |
| EMP 6x4 | 1 | 10.7 | 7.8 | 83 | 14430 | 54.7 | 420 | 14.82 | 82% |
| EMP 6x5 | 1 | 6.8 | 4.8 | 32 | 9630 | 45.6 | 224 | 7.90 | 86% |
| EMP 6x5 | 1 | 7.8 | 5.8 | 45 | 10710 | 50.7 | 278 | 9.81 | 84% |
| EMP 6x5 | 1 | 8.8 | 6.85 | 60 | 11850 | 56.1 | 338 | 11.92 | 82% |
| EMP 6x5 | 1 | 9.8 | 8.05 | 78 | 12870 | 60.9 | 399 | 14.07 | 80% |
| EMP 6x5 | 1 | 10.7 | 9.3 | 99 | 13860 | 65.6 | 469 | 16.54 | 79% |
| EMP 6x5 | 1 | 14.3 | 14.2 | 203 | 17100 | 81.0 | 730 | 25.75 | 73% |
| APC E 7x5 | 1 | 6.8 | 7.95 | 54 | 8490 | 40.2 | 317 | 11.18 | 76% |
| APC E 7x5 | 1 | 7.8 | 9.5 | 74 | 9360 | 44.3 | 384 | 13.55 | 73% |
| APC E 7x5 | 1 | 8.7 | 11.2 | 97 | 10170 | 48.2 | 462 | 16.30 | 71% |
| APC E 7x5 | 1 | 9.7 | 13 | 126 | 10830 | 51.3 | 530 | 18.70 | 68% |
| APC E 7x5 | 1 | 10.7 | 14.5 | 155 | 11430 | 54.1 | 594 | 20.95 | 65% |
