E-power - GC GT2210-1780
Specifications
- Type: Outrunner
- Weight: 52.00g (1.83oz)
- Diameter: 28.47mm (1.12in)
- Length: 28.35mm (1.12in)
- Shaft Diameter: 4.00mm (0.16in)
- Maximum Amps: 18
Constants
- kV: 1795
- Rm: 0.234
- Io: 1.05
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.9 | 12180 |
| 8 | 0.95 | 13800 |
| 10 | 1.05 | 17190 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| Zagi Carbon 5.1x4.9 | 1 | 6.9 | 4.75 | 32 | 10650 | 49.4 | 158 | 5.57 | 86% |
| Zagi Carbon 5.1x4.9 | 1 | 7.8 | 5.45 | 42 | 11940 | 55.4 | 200 | 7.05 | 85% |
| Zagi Carbon 5.1x4.9 | 1 | 8.8 | 6.5 | 57 | 13140 | 61.0 | 240 | 8.47 | 83% |
| Zagi Carbon 5.1x4.9 | 1 | 9.8 | 7.85 | 76 | 14190 | 65.8 | 284 | 10.02 | 81% |
| Zagi Carbon 5.1x4.9 | 1 | 10.7 | 9.3 | 99 | 15150 | 70.3 | 322 | 11.36 | 79% |
| EMP 6x5 | 1 | 6.8 | 6.2 | 42 | 10110 | 47.9 | 243 | 8.57 | 83% |
| EMP 6x5 | 1 | 7.8 | 7.2 | 56 | 11280 | 53.4 | 303 | 10.69 | 81% |
| EMP 6x5 | 1 | 8.7 | 8.5 | 73 | 12270 | 58.1 | 362 | 12.77 | 79% |
| EMP 6x5 | 1 | 9.7 | 9.85 | 95 | 13320 | 63.1 | 430 | 15.17 | 77% |
| EMP 6x5 | 1 | 10.7 | 11.4 | 121 | 14190 | 67.2 | 484 | 17.07 | 74% |
| APC 6.5x6.5 | 1 | 6.7 | 8.7 | 58 | 9060 | 55.8 | 204 | 7.20 | 75% |
| APC 6.5x6.5 | 1 | 7.7 | 10.35 | 79 | 10020 | 61.7 | 248 | 8.75 | 72% |
| APC 6.5x6.5 | 1 | 8.6 | 11.9 | 102 | 10890 | 67.0 | 301 | 10.62 | 71% |
| APC 6.5x6.5 | 1 | 9.6 | 13.35 | 128 | 11910 | 73.3 | 372 | 13.12 | 69% |
| APC 6.5x6.5 | 1 | 10.6 | 14.8 | 156 | 12720 | 78.3 | 433 | 15.27 | 67% |
| APC E 7x5 | 1 | 6.8 | 9.55 | 64 | 8970 | 42.5 | 349 | 12.31 | 73% |
| APC E 7x5 | 1 | 7.8 | 11.35 | 88 | 9870 | 46.7 | 427 | 15.06 | 70% |
| APC E 7x5 | 1 | 8.7 | 13.1 | 113 | 10650 | 50.4 | 505 | 17.81 | 68% |
| APC E 7x5 | 1 | 9.7 | 15.1 | 146 | 11430 | 54.1 | 588 | 20.74 | 66% |
| APC E 7x5 | 1 | 10.7 | 16.7 | 178 | 12030 | 57.0 | 649 | 22.89 | 63% |
| GWS HD 8x4 | 1 | 6.8 | 9.2 | 62 | 9030 | 34.2 | 419 | 14.78 | 74% |
| GWS HD 8x4 | 1 | 7.7 | 10.95 | 84 | 9930 | 37.6 | 514 | 18.13 | 72% |
| GWS HD 8x4 | 1 | 8.7 | 12.75 | 110 | 10770 | 40.8 | 612 | 21.59 | 69% |
| GWS HD 8x4 | 1 | 9.6 | 14.6 | 140 | 11520 | 43.6 | 705 | 24.87 | 67% |
| GWS HD 8x4 | 1 | 10.6 | 16.5 | 174 | 12180 | 46.1 | 790 | 27.87 | 64% |
| APC E 8x4 | 1 | 6.7 | 10.95 | 73 | 8400 | 31.8 | 447 | 15.77 | 70% |
| APC E 8x4 | 1 | 7.7 | 12.8 | 98 | 9150 | 34.7 | 535 | 18.87 | 66% |
| APC E 8x4 | 1 | 8.7 | 14.85 | 129 | 9840 | 37.3 | 627 | 22.12 | 63% |
| APC E 8x4 | 1 | 9.6 | 16.85 | 161 | 10440 | 39.5 | 714 | 25.19 | 61% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| APC E 8x4 | 1 | 10.6 | 18.9 | 200 | 10950 | 41.5 | 802 | 28.29 | 58% |
| APC SF 9x4.7 | 1 | 7 | 15.1 | 105 | 7320 | 32.6 | 556 | 19.61 | 58% |
| APC SF 9x4.7 | 1 | 7.4 | 15.7 | 116 | 7620 | 33.9 | 589 | 20.78 | 57% |
