E-power - GC GT2210-1270
Specifications
- Type: Outrunner
- Weight: 52.00g (1.83oz)
- Diameter: 28.47mm (1.12in)
- Length: 28.35mm (1.12in)
- Shaft Diameter: 4.00mm (0.16in)
- Maximum Amps: 12
Constants
- kV: 1305
- Rm: 0.35
- Io: 0.75
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.7 | 8820 |
| 8 | 0.75 | 10120 |
| 10 | 0.75 | 12550 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 8x4 | 1 | 6.9 | 4.7 | 32 | 7260 | 27.5 | 271 | 9.56 | 81% |
| GWS HD 8x4 | 1 | 7.8 | 5.5 | 42 | 8040 | 30.5 | 327 | 11.53 | 79% |
| GWS HD 8x4 | 1 | 8.8 | 6.4 | 56 | 8760 | 33.2 | 394 | 13.90 | 76% |
| GWS HD 8x4 | 1 | 9.8 | 7.35 | 72 | 9540 | 36.1 | 461 | 16.26 | 75% |
| GWS HD 8x4 | 1 | 10.8 | 8.4 | 90 | 10200 | 38.6 | 535 | 18.87 | 72% |
| GWS HD 8x6 | 1 | 6.8 | 6.75 | 45 | 6420 | 36.5 | 286 | 10.09 | 72% |
| GWS HD 8x6 | 1 | 7.8 | 7.9 | 61 | 7020 | 39.9 | 346 | 12.20 | 69% |
| GWS HD 8x6 | 1 | 8.7 | 9.15 | 79 | 7590 | 43.1 | 401 | 14.14 | 67% |
| GWS HD 8x6 | 1 | 9.7 | 10.45 | 101 | 8070 | 45.9 | 458 | 16.16 | 64% |
| GWS HD 8x6 | 1 | 10.6 | 11.45 | 121 | 8490 | 48.2 | 509 | 17.95 | 61% |
| APC E 8x6 | 1 | 6.8 | 7.4 | 50 | 6060 | 34.4 | 269 | 9.49 | 68% |
| APC E 8x6 | 1 | 7.8 | 8.75 | 68 | 6600 | 37.5 | 324 | 11.43 | 65% |
| APC E 8x6 | 1 | 8.7 | 10.05 | 87 | 7140 | 40.6 | 376 | 13.26 | 63% |
| APC E 8x6 | 1 | 9.7 | 11.25 | 109 | 7590 | 43.1 | 437 | 15.41 | 60% |
| APC E 8x6 | 1 | 10.7 | 12.6 | 134 | 7980 | 45.3 | 497 | 17.53 | 57% |
| APC SF 9x4.7 | 1 | 6.8 | 7.3 | 49 | 6090 | 27.1 | 367 | 12.95 | 69% |
| APC SF 9x4.7 | 1 | 7.8 | 8.6 | 67 | 6660 | 29.6 | 446 | 15.73 | 65% |
| APC SF 9x4.7 | 1 | 8.7 | 9.9 | 86 | 7170 | 31.9 | 527 | 18.59 | 63% |
| APC SF 9x4.7 | 1 | 9.7 | 11.15 | 108 | 7680 | 34.2 | 593 | 20.92 | 61% |
| APC SF 9x4.7 | 1 | 10.7 | 12.3 | 131 | 8100 | 36.1 | 668 | 23.56 | 58% |
| GWS HD 9x5 | 1 | 6.8 | 7.1 | 48 | 6240 | 29.5 | 373 | 13.16 | 70% |
| GWS HD 9x5 | 1 | 7.8 | 8.3 | 64 | 6870 | 32.5 | 445 | 15.70 | 67% |
| GWS HD 9x5 | 1 | 8.7 | 9.45 | 82 | 7380 | 34.9 | 521 | 18.38 | 65% |
| GWS HD 9x5 | 1 | 9.7 | 10.8 | 104 | 7860 | 37.2 | 590 | 20.81 | 62% |
| GWS HD 9x5 | 1 | 10.7 | 12 | 128 | 8310 | 39.3 | 670 | 23.63 | 60% |
| GWS HD 10x6 | 1 | 6.8 | 8.7 | 59 | 5640 | 32.0 | 429 | 15.13 | 64% |
| GWS HD 10x6 | 1 | 7.7 | 10.1 | 77 | 6120 | 34.8 | 503 | 17.74 | 61% |
| GWS HD 10x6 | 1 | 8.7 | 11.5 | 100 | 6540 | 37.2 | 578 | 20.39 | 58% |
| GWS HD 10x6 | 1 | 9.7 | 12.7 | 123 | 6870 | 39.0 | 630 | 22.22 | 54% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 10x6 | 1 | 10.6 | 14.1 | 149 | 7200 | 40.9 | 700 | 24.69 | 52% |
