GPS - C28-26-B
Specifications
- Type: Outrunner
- Weight: 46.00g (1.62oz)
- Diameter: 27.80mm (1.09in)
- Length: 27.00mm (1.06in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 15
Constants
- kV: 1620
- Rm: 0.2
- Io: 1.56
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 1.56 | 15720 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 5.25x6.25 | 1 | 10.9 | 11 | 119 | 13800 | 81.7 | 279 | 9.84 | 78% |
| APC E 6x5.5 | 1 | 10.9 | 11.85 | 129 | 13470 | 70.2 | 427 | 15.06 | 76% |
| GWS HD 7x3.5 | 1 | 6.9 | 5.1 | 35 | 9780 | 32.4 | 241 | 8.50 | 87% |
| GWS HD 7x3.5 | 1 | 7.9 | 6.1 | 48 | 10980 | 36.4 | 308 | 10.86 | 86% |
| GWS HD 7x3.5 | 1 | 8.9 | 7.25 | 64 | 12180 | 40.4 | 383 | 13.51 | 84% |
| GWS HD 7x3.5 | 1 | 9.9 | 8.4 | 83 | 13230 | 43.9 | 463 | 16.33 | 82% |
| GWS HD 7x3.5 | 1 | 10.9 | 9.75 | 106 | 14280 | 47.3 | 554 | 19.54 | 81% |
| APC SF 7x4 | 1 | 6.9 | 7.8 | 53 | 8970 | 34.0 | 333 | 11.75 | 80% |
| APC SF 7x4 | 1 | 7.9 | 9.4 | 74 | 9900 | 37.5 | 413 | 14.57 | 77% |
| APC SF 7x4 | 1 | 8.9 | 11.1 | 98 | 10800 | 40.9 | 503 | 17.74 | 75% |
| APC SF 7x4 | 1 | 9.9 | 13 | 128 | 11610 | 44.0 | 591 | 20.85 | 72% |
| APC SF 7x4 | 1 | 10.9 | 14.7 | 160 | 12330 | 46.7 | 677 | 23.88 | 70% |
| APC E 7x5 | 1 | 6.9 | 8.7 | 60 | 8580 | 40.6 | 338 | 11.92 | 77% |
| APC E 7x5 | 1 | 7.9 | 10.5 | 82 | 9480 | 44.9 | 422 | 14.89 | 74% |
| APC E 7x5 | 1 | 8.9 | 12.3 | 109 | 10350 | 49.0 | 504 | 17.78 | 72% |
| APC E 7x5 | 1 | 9.9 | 14.3 | 141 | 11130 | 52.7 | 590 | 20.81 | 69% |
| APC E 7x5 | 1 | 10.9 | 16 | 174 | 11820 | 56.0 | 668 | 23.56 | 67% |
| GWS HD 8x4 | 1 | 6.9 | 8.8 | 60 | 8610 | 32.6 | 409 | 14.43 | 77% |
| GWS HD 8x4 | 1 | 7.9 | 10.5 | 82 | 9480 | 35.9 | 498 | 17.57 | 74% |
| GWS HD 8x4 | 1 | 8.9 | 12.3 | 109 | 10320 | 39.1 | 598 | 21.09 | 72% |
| GWS HD 8x4 | 1 | 9.9 | 14.25 | 141 | 11070 | 41.9 | 700 | 24.69 | 69% |
