Turnigy - 2730-1500 R&B
Specifications
- Type: Outrunner
- Weight: 26.00g (0.92oz)
- Diameter: 27.05mm (1.06in)
- Length: 28.60mm (1.13in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 8
Constants
- kV: 1600
- Rm: 0.41
- Io: 0.35
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.3 | 11000 |
| 8 | 0.3 | 12500 |
| 10 | 0.35 | 15750 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| RRC 5x4.5 | 1 | 6.9 | 2.3 | 15 | 9750 | 41.5 | 117 | 4.13 | 88% |
| RRC 5x4.5 | 1 | 7.9 | 2.8 | 22 | 10890 | 46.4 | 145 | 5.11 | 86% |
| RRC 5x4.5 | 1 | 8.9 | 3.4 | 30 | 12120 | 51.6 | 179 | 6.31 | 85% |
| RRC 5x4.5 | 1 | 9.9 | 4 | 39 | 13140 | 56.0 | 216 | 7.62 | 83% |
| RRC 5x4.5 | 1 | 10.9 | 4.6 | 50 | 14160 | 60.3 | 252 | 8.89 | 81% |
| Zagi Carbon 5.1x4.9 | 1 | 6.9 | 2.9 | 20 | 9420 | 43.7 | 125 | 4.41 | 85% |
| Zagi Carbon 5.1x4.9 | 1 | 7.9 | 3.5 | 27 | 10470 | 48.6 | 155 | 5.47 | 83% |
| Zagi Carbon 5.1x4.9 | 1 | 8.9 | 4.1 | 36 | 11520 | 53.5 | 190 | 6.70 | 81% |
| Zagi Carbon 5.1x4.9 | 1 | 9.8 | 4.8 | 47 | 12150 | 56.4 | 224 | 7.90 | 77% |
| Zagi Carbon 5.1x4.9 | 1 | 10.8 | 5.55 | 59 | 13500 | 62.6 | 262 | 9.24 | 78% |
| EMP 6x5 | 1 | 6.9 | 3.8 | 26 | 8820 | 41.8 | 190 | 6.70 | 80% |
| EMP 6x5 | 1 | 7.9 | 4.55 | 35 | 9750 | 46.2 | 234 | 8.25 | 77% |
| EMP 6x5 | 1 | 8.9 | 5.35 | 47 | 10710 | 50.7 | 280 | 9.88 | 75% |
| EMP 6x5 | 1 | 9.8 | 6.2 | 60 | 11550 | 54.7 | 329 | 11.61 | 74% |
| EMP 6x5 | 1 | 10.8 | 7.1 | 76 | 12360 | 58.5 | 376 | 13.26 | 72% |
| GWS HD 7x3.5 | 1 | 6.9 | 3.3 | 22 | 9120 | 30.2 | 190 | 6.70 | 83% |
| GWS HD 7x3.5 | 1 | 7.9 | 3.95 | 31 | 10140 | 33.6 | 240 | 8.47 | 80% |
| GWS HD 7x3.5 | 1 | 8.9 | 4.75 | 42 | 11160 | 37.0 | 298 | 10.51 | 78% |
| GWS HD 7x3.5 | 1 | 9.9 | 5.5 | 54 | 12060 | 40.0 | 353 | 12.45 | 76% |
| GWS HD 7x3.5 | 1 | 10.9 | 6.35 | 69 | 12960 | 43.0 | 411 | 14.50 | 74% |
| APC E 7x5 | 1 | 6.8 | 5.85 | 39 | 7500 | 35.5 | 248 | 8.75 | 69% |
| APC E 7x5 | 1 | 7.8 | 7 | 54 | 8220 | 38.9 | 303 | 10.69 | 66% |
| APC E 7x5 | 1 | 8.8 | 8.15 | 71 | 8820 | 41.8 | 355 | 12.52 | 63% |
| APC E 7x5 | 1 | 9.7 | 9.3 | 90 | 9360 | 44.3 | 395 | 13.93 | 60% |
| APC E 7x5 | 1 | 10.7 | 10.3 | 110 | 9870 | 46.7 | 444 | 15.66 | 58% |
| GWS HD 8x4 | 1 | 6.9 | 5.9 | 40 | 7590 | 28.8 | 305 | 10.76 | 69% |
| GWS HD 8x4 | 1 | 7.9 | 7 | 55 | 8250 | 31.2 | 368 | 12.98 | 65% |
| GWS HD 8x4 | 1 | 8.8 | 8.05 | 70 | 8820 | 33.4 | 425 | 14.99 | 63% |
| GWS HD 8x4 | 1 | 9.8 | 9 | 88 | 9390 | 35.6 | 480 | 16.93 | 60% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 8x4 | 1 | 10.7 | 10.3 | 110 | 9840 | 37.3 | 537 | 18.94 | 57% |
Comments
AUselessGeek on 2011-10-27 07:12:03
You guys gotta try this motor with a GWS 8x4.3 slow fly (EP-0843). On 2S it'll pull a 220 gram plane straight up with no probs.
