ELE - C20 KV2100
Specifications
- Type: Outrunner
- Weight: 19.00g (0.67oz)
- Diameter: 22.20mm (0.87in)
- Length: 22.00mm (0.87in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 8
Constants
- kV: 1800
- Rm: 0.705
- Io: 0.62
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 5.99 | 0.47 | 10320 |
| 7.03 | 0.5 | 12090 |
| 8.02 | 0.53 | 13800 |
| 9.01 | 0.57 | 15450 |
| 10.03 | 0.62 | 17220 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 5x3 | 1 | 7 | 1.95 | 13 | 10380 | 29.5 | 103 | 3.63 | 82% |
| GWS HD 5x3 | 1 | 8 | 2.3 | 18 | 11670 | 33.1 | 129 | 4.55 | 81% |
| GWS HD 5x3 | 1 | 8.9 | 2.7 | 24 | 12750 | 36.2 | 157 | 5.54 | 80% |
| GWS HD 5x3 | 1 | 10 | 3.1 | 31 | 13980 | 39.7 | 189 | 6.67 | 78% |
| GWS HD 5x3 | 1 | 10.9 | 3.45 | 37 | 15030 | 42.7 | 218 | 7.69 | 77% |
| GWS HD 5x4.3 | 1 | 7 | 2.8 | 19 | 9480 | 38.6 | 122 | 4.30 | 75% |
| GWS HD 5x4.3 | 1 | 7.9 | 3.3 | 26 | 10500 | 42.8 | 148 | 5.22 | 74% |
| GWS HD 5x4.3 | 1 | 8.9 | 3.8 | 33 | 11460 | 46.7 | 176 | 6.21 | 72% |
| GWS HD 5x4.3 | 1 | 9.9 | 4.3 | 42 | 12390 | 50.5 | 208 | 7.34 | 70% |
| GWS HD 5x4.3 | 1 | 10.9 | 4.9 | 53 | 13220 | 53.8 | 240 | 8.47 | 67% |
| Zagi Carbon 5.1x4.9 | 1 | 7 | 3.15 | 22 | 9120 | 42.3 | 127 | 4.48 | 72% |
| Zagi Carbon 5.1x4.9 | 1 | 8 | 3.7 | 29 | 10020 | 46.5 | 152 | 5.36 | 70% |
| Zagi Carbon 5.1x4.9 | 1 | 8.9 | 4.3 | 38 | 10830 | 50.2 | 179 | 6.31 | 68% |
| Zagi Carbon 5.1x4.9 | 1 | 9.9 | 4.95 | 49 | 11670 | 54.1 | 211 | 7.44 | 65% |
| Zagi Carbon 5.1x4.9 | 1 | 10.9 | 5.6 | 61 | 12360 | 57.4 | 241 | 8.50 | 63% |
| APC E 5.7x3 | 1 | 7 | 2.8 | 19 | 9450 | 26.9 | 124 | 4.37 | 75% |
| APC E 5.7x3 | 1 | 8 | 3.35 | 26 | 10470 | 29.7 | 151 | 5.33 | 73% |
| APC E 5.7x3 | 1 | 8.9 | 3.85 | 34 | 11340 | 32.2 | 181 | 6.38 | 71% |
| APC E 5.7x3 | 1 | 9.9 | 4.4 | 43 | 12240 | 34.8 | 214 | 7.55 | 69% |
| APC E 5.7x3 | 1 | 10.9 | 5 | 54 | 13050 | 37.1 | 246 | 8.68 | 67% |
| GWS HD 6x3 | 1 | 7 | 2.8 | 19 | 9510 | 27.0 | 152 | 5.36 | 75% |
| GWS HD 6x3 | 1 | 7.9 | 3.25 | 25 | 10470 | 29.7 | 182 | 6.42 | 74% |
| GWS HD 6x3 | 1 | 8.9 | 3.8 | 33 | 11430 | 32.5 | 225 | 7.94 | 71% |
| GWS HD 6x3 | 1 | 9.9 | 4.4 | 43 | 12270 | 34.9 | 261 | 9.21 | 69% |
| GWS HD 6x3 | 1 | 10.9 | 5 | 54 | 13110 | 37.2 | 303 | 10.69 | 67% |
| APC E 6x4 | 1 | 6.9 | 3.5 | 24 | 8640 | 32.7 | 148 | 5.22 | 70% |
| APC E 6x4 | 1 | 7.9 | 4.05 | 31 | 9450 | 35.8 | 177 | 6.24 | 66% |
| APC E 6x4 | 1 | 8.9 | 4.7 | 41 | 10290 | 39.0 | 220 | 7.76 | 64% |
| APC E 6x4 | 1 | 9.9 | 5.45 | 53 | 10980 | 41.6 | 250 | 8.82 | 62% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| APC E 6x4 | 1 | 10.9 | 6.1 | 66 | 11580 | 43.9 | 279 | 9.84 | 59% |
| Aeronaut 6x5 | 1 | 9.9 | 5.65 | 55 | 10200 | 48.3 | 265 | 9.35 | 57% |
| Aeronaut 6x5 | 1 | 10.9 | 6.3 | 68 | 10680 | 50.6 | 290 | 10.23 | 54% |
| GWS RS 6x5 | 1 | 6.9 | 4.6 | 31 | 7470 | 35.4 | 168 | 5.93 | 60% |
| GWS RS 6x5 | 1 | 7.9 | 5.4 | 42 | 8070 | 38.2 | 193 | 6.81 | 57% |
| GWS RS 6x5 | 1 | 8.9 | 6.1 | 54 | 8520 | 40.3 | 220 | 7.76 | 53% |
| GWS RS 6x5 | 1 | 9.9 | 6.7 | 66 | 8850 | 41.9 | 242 | 8.54 | 50% |
| GWS RS 6x5 | 1 | 10.9 | 7.4 | 80 | 9120 | 43.2 | 254 | 8.96 | 46% |
| EMP 6x5 | 1 | 6.9 | 3.85 | 26 | 8250 | 39.1 | 166 | 5.86 | 66% |
| EMP 6x5 | 1 | 7.4 | 4.15 | 30 | 8610 | 40.8 | 185 | 6.53 | 65% |
| EMP 6x5 | 1 | 7.9 | 4.35 | 34 | 8970 | 42.5 | 196 | 6.91 | 63% |
| EMP 6x5 | 1 | 8.9 | 5.05 | 44 | 9600 | 45.5 | 235 | 8.29 | 60% |
| EMP 6x5 | 1 | 9.9 | 5.65 | 55 | 10200 | 48.3 | 265 | 9.35 | 57% |
| EMP 6x5 | 1 | 10.9 | 6.3 | 68 | 10680 | 50.6 | 290 | 10.23 | 54% |
| Aeronaut 6.5x4 | 1 | 6.9 | 4.2 | 28 | 7950 | 30.1 | 173 | 6.10 | 64% |
| Aeronaut 6.5x4 | 1 | 7.9 | 4.9 | 38 | 8640 | 32.7 | 206 | 7.27 | 61% |
| Aeronaut 6.5x4 | 1 | 8.9 | 5.6 | 49 | 9210 | 34.9 | 235 | 8.29 | 57% |
| Aeronaut 6.5x4 | 1 | 9.9 | 6.35 | 62 | 9780 | 37.0 | 272 | 9.59 | 55% |
| Aeronaut 6.5x4 | 1 | 10.9 | 7 | 76 | 10230 | 38.8 | 303 | 10.69 | 52% |
| GWS HD 7x3.5 | 1 | 7 | 3.55 | 24 | 8670 | 28.7 | 187 | 6.60 | 69% |
| GWS HD 7x3.5 | 1 | 7.9 | 4.1 | 32 | 9480 | 31.4 | 224 | 7.90 | 67% |
| GWS HD 7x3.5 | 1 | 8.9 | 4.8 | 42 | 10200 | 33.8 | 268 | 9.45 | 64% |
| GWS HD 7x3.5 | 1 | 9.9 | 5.45 | 53 | 10890 | 36.1 | 305 | 10.76 | 61% |
Comments
Dr Kiwi on 2010-12-22 14:11:39
Perhaps same motor as AX1806N
