Dualsky - XM 3536-8

Specifications

  • Type: Outrunner
  • Weight: 105.00g (3.70oz)
  • Diameter: 35.00mm (1.38in)
  • Length: 36.00mm (1.42in)
  • Shaft Diameter: 4.00mm (0.16in)
  • Maximum Amps: 28

Constants

  • kV: 1010
  • Rm: 0.112
  • Io: 1.4



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 1.15 6930
8 1.2 7920
10 1.4 9900

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
E-MAX CF 8x5 1 6.9 3 20 6660 31.5 156 5.50 96%
E-MAX CF 8x5 1 7.9 3.65 28 7530 35.7 204 7.20 94%
E-MAX CF 8x5 1 8.9 4.35 38 8400 39.8 254 8.96 93%
E-MAX CF 8x5 1 9.9 5.15 50 9270 43.9 310 10.93 93%
E-MAX CF 8x5 1 10.9 6 65 10140 48.0 373 13.16 92%
E-MAX CF 8x5 1 14 9.3 130 12690 60.1 595 20.99 90%
APC E 8x6 1 10.8 13.3 143 9090 51.6 696 24.55 83%
EMP 8x6 1 10.7 16 171 8620 49.0 838 29.56 80%
GP SF 9x4.5 1 10.6 15.6 165 7830 33.4 912 32.17 73%
GP SF 9x4.5 1 10.6 14.2 150 7590 32.3 860 30.34 71%
GP SF 9x4.5 1 10.6 18.35 194 8190 34.9 1010 35.63 76%
GP SF 9x4.5 1 10.7 12.1 129 7200 30.7 775 27.34 67%
GP SF 9x4.5 1 10.7 10.5 112 6900 29.4 693 24.44 64%
GP SF 9x4.5 1 10.8 7.7 83 6180 26.3 558 19.68 57%
GP SF 9x4.5 1 10.8 8.9 96 6540 27.9 620 21.87 60%
GP SF 9x4.5 1 10.9 4.55 49 5190 22.1 372 13.12 47%
GP SF 9x4.5 1 10.9 0.6 6 2190 9.3 62 2.19 20%
GP SF 9x4.5 1 10.9 1.65 17 3510 15.0 163 5.75 32%
GP SF 9x4.5 1 10.9 3.5 38 4710 20.1 303 10.69 43%
GP SF 9x4.5 1 10.9 6.7 73 5910 25.2 502 17.71 54%
GP SF 9x4.5 1 10.9 0.35 3 1560 6.7 30 1.06 14%
GP SF 9x4.5 1 10.9 1.3 14 3180 13.6 130 4.59 29%
GP SF 9x4.5 1 10.9 2.8 30 4350 18.5 257 9.07 40%
GP SF 9x4.5 1 10.9 5.4 58 5490 23.4 424 14.96 50%
GP SF 9x4.5 1 10.9 0.95 10 2730 11.6 96 3.39 25%
GP SF 9x4.5 1 10.9 2.15 23 3930 16.8 204 7.20 36%
E-MAX CF 9x5 1 6.9 3.95 27 6570 31.1 233 8.22 94%
E-MAX CF 9x5 1 7.9 4.85 38 7410 35.1 300 10.58 93%
E-MAX CF 9x5 1 8.9 5.8 51 8250 39.1 371 13.09 92%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
E-MAX CF 9x5 1 9.9 6.9 68 9060 42.9 453 15.98 91%
E-MAX CF 9x5 1 10.8 8.1 87 9870 46.7 530 18.70 90%
E-MAX CF 9x5 1 14 12.05 168 12300 58.2 843 29.74 87%
APC E 9x6 1 10.7 16.15 172 8670 49.3 870 30.69 80%
EMP 9x7.5 1 10.6 23.6 250 7460 53.0 1044 36.83 70%
GP SF 10x3.5 1 10.5 15.85 166 7470 24.8 1005 35.45 70%
GP SF 10x3.5 1 10.5 14.3 150 7260 24.1 930 32.80 68%
GP SF 10x3.5 1 10.5 19.6 205 7950 26.4 1143 40.32 75%
GP SF 10x3.5 1 10.5 12.15 127 6910 22.9 825 29.10 65%
GP SF 10x3.5 1 10.5 18.35 192 7830 25.9 1095 38.62 74%
GP SF 10x3.5 1 10.7 9 96 6270 20.8 670 23.63 58%
GP SF 10x3.5 1 10.7 10.4 111 6570 21.8 744 26.24 61%
GP SF 10x3.5 1 10.8 7.9 85 6030 20.0 605 21.34 55%
GP SF 10x3.5 1 10.9 5.8 63 5430 18.0 480 16.93 49%
GP SF 10x3.5 1 10.9 0.8 8 2520 8.3 84 2.96 23%
GP SF 10x3.5 1 10.9 3.5 38 4560 15.1 319 11.25 41%
GP SF 10x3.5 1 10.9 0.9 9 2700 8.9 100 3.53 25%
GP SF 10x3.5 1 10.9 0.55 5 2100 7.0 56 1.98 19%
GP SF 10x3.5 1 10.9 0.35 3 1620 5.4 31 1.09 15%
GP SF 10x3.5 1 10.9 1.15 12 2970 9.8 124 4.37 27%
GP SF 10x3.5 1 10.9 4.75 51 5040 16.7 412 14.53 46%
GP SF 10x3.5 1 10.9 1.4 15 3210 10.6 145 5.11 29%
GP SF 10x3.5 1 10.9 2.85 31 4200 13.9 272 9.59 38%
GP SF 10x3.5 1 10.9 6.7 73 5700 18.9 536 18.91 52%
GP SF 10x3.5 1 10.9 1.9 20 3600 11.9 196 6.91 33%
APC SF 10x3.8 1 10.5 19.3 202 7980 28.7 1130 39.86 75%
APC SF 10x3.8 1 10.6 13.8 146 7320 26.3 900 31.75 68%
APC SF 10x3.8 1 10.6 15.4 163 7530 27.1 965 34.04 70%
APC SF 10x3.8 1 10.6 17.4 184 7800 28.1 1060 37.39 73%
APC SF 10x3.8 1 10.7 9.65 103 6570 23.6 704 24.83 61%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC SF 10x3.8 1 10.7 11.9 127 6960 25.1 800 28.22 64%
APC SF 10x3.8 1 10.8 5.75 62 5580 20.1 473 16.68 51%
APC SF 10x3.8 1 10.8 6.8 73 5880 21.2 538 18.98 54%
APC SF 10x3.8 1 10.8 7.9 85 6180 22.2 603 21.27 57%
APC SF 10x3.8 1 10.9 2.8 30 4380 15.8 267 9.42 40%
APC SF 10x3.8 1 10.9 1.7 18 3660 13.2 175 6.17 33%
APC SF 10x3.8 1 10.9 4.1 44 5010 18.0 361 12.73 46%
APC SF 10x3.8 1 10.9 1.3 14 3270 11.8 138 4.87 30%
APC SF 10x3.8 1 10.9 3.4 37 4710 16.9 314 11.08 43%
APC SF 10x3.8 1 10.9 0.85 9 2730 9.8 93 3.28 25%
APC SF 10x3.8 1 10.9 2.3 25 4080 14.7 229 8.08 37%
APC SF 10x3.8 1 10.9 0.5 5 2040 7.3 48 1.69 19%
APC SF 10x3.8 1 10.9 4.7 51 5250 18.9 405 14.29 48%
GP SF 10x4.5 1 10.6 21 222 7380 31.4 1173 41.38 69%
GP SF 10x4.5 1 10.6 23.2 245 7470 31.8 1200 42.33 70%
GP SF 10x4.5 1 10.7 17.2 184 6900 29.4 1020 35.98 64%
GP SF 10x4.5 1 10.7 19.1 204 7110 30.3 1090 38.45 66%
GP SF 10x4.5 1 10.7 15 160 6600 28.1 942 33.23 61%
GP SF 10x4.5 1 10.8 8.6 92 5580 23.8 646 22.79 51%
GP SF 10x4.5 1 10.8 6.4 69 5010 21.4 516 18.20 46%
GP SF 10x4.5 1 10.8 10.25 110 5880 25.1 730 25.75 54%
GP SF 10x4.5 1 10.8 7.4 79 5280 22.5 570 20.11 48%
GP SF 10x4.5 1 10.8 13.2 142 6390 27.2 870 30.69 59%
GP SF 10x4.5 1 10.8 11.75 126 6150 26.2 796 28.08 56%
GP SF 10x4.5 1 10.9 0.5 5 1770 7.5 54 1.90 16%
GP SF 10x4.5 1 10.9 1.4 15 2820 12.0 152 5.36 26%
GP SF 10x4.5 1 10.9 3.35 36 3990 17.0 315 11.11 36%
GP SF 10x4.5 1 10.9 0.7 7 2070 8.8 77 2.72 19%
GP SF 10x4.5 1 10.9 1.65 17 3060 13.0 179 6.31 28%
GP SF 10x4.5 1 10.9 2.05 22 3300 14.1 209 7.37 30%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GP SF 10x4.5 1 10.9 4.5 49 4440 18.9 391 13.79 40%
GP SF 10x4.5 1 10.9 5.4 58 4740 20.2 453 15.98 43%
GP SF 10x4.5 1 10.9 0.85 9 2280 9.7 94 3.32 21%
GP SF 10x4.5 1 10.9 1.1 11 2610 11.1 126 4.44 24%
GP SF 10x4.5 1 10.9 2.6 28 3600 15.3 255 8.99 33%
APC SF 10x4.7 1 10.5 18.1 190 7560 33.6 1070 37.74 71%
APC SF 10x4.7 1 10.5 20.4 214 7830 34.9 1150 40.57 74%
APC SF 10x4.7 1 10.5 16.5 173 7380 32.9 1005 35.45 70%
APC SF 10x4.7 1 10.6 14 148 7020 31.2 905 31.92 66%
APC SF 10x4.7 1 10.6 11.45 121 6600 29.4 785 27.69 62%
APC SF 10x4.7 1 10.6 10 106 6330 28.2 712 25.12 59%
APC SF 10x4.7 1 10.7 8.4 89 5970 26.6 624 22.01 55%
APC SF 10x4.7 1 10.8 5.1 55 5070 22.6 429 15.13 46%
APC SF 10x4.7 1 10.8 6.35 68 5430 24.2 505 17.81 50%
APC SF 10x4.7 1 10.8 7.3 78 5700 25.4 563 19.86 52%
APC SF 10x4.7 1 10.8 4.25 45 4740 21.1 377 13.30 43%
APC SF 10x4.7 1 10.9 1.55 16 3300 14.7 165 5.82 30%
APC SF 10x4.7 1 10.9 0.3 3 1500 6.7 34 1.20 14%
APC SF 10x4.7 1 10.9 1.1 11 2850 12.7 119 4.20 26%
APC SF 10x4.7 1 10.9 2.65 28 4020 17.9 255 8.99 37%
APC SF 10x4.7 1 10.9 0.6 6 2130 9.5 65 2.29 19%
APC SF 10x4.7 1 10.9 3.4 37 4410 19.6 317 11.18 40%
APC SF 10x4.7 1 10.9 2.2 23 3780 16.8 222 7.83 34%
APC E 10x5 1 6.8 8.2 55 5940 28.1 467 16.47 86%
APC E 10x5 1 7.8 10.2 79 6690 31.7 600 21.16 85%
APC E 10x5 1 8.7 12.1 105 7350 34.8 732 25.82 84%
APC E 10x5 1 9.7 14.5 140 8010 37.9 883 31.15 82%
APC E 10x5 1 10.6 16.45 174 8580 40.6 1012 35.70 80%
APC E 10x5 1 14 25.1 351 10470 49.6 1550 54.67 74%
E-MAX CF 10x5 1 6.9 7.05 48 6210 29.4 400 14.11 89%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
E-MAX CF 10x5 1 7.8 8.55 66 6930 32.8 499 17.60 88%
E-MAX CF 10x5 1 8.8 10.2 89 7650 36.2 611 21.55 86%
E-MAX CF 10x5 1 9.7 11.85 114 8340 39.5 725 25.57 85%
E-MAX CF 10x5 1 10.7 13.8 147 9060 42.9 845 29.81 84%
E-MAX CF 10x5 1 14 20.2 282 11190 53.0 1320 46.56 79%
Evolution 10x6 1 10.6 19 201 8220 46.7 1010 35.63 77%
APC SF 10x7 1 10.5 23.2 243 6750 44.7 1080 38.10 64%
APC SF 10x7 1 10.6 20.5 217 6540 43.4 1005 35.45 61%
APC SF 10x7 1 10.6 17 180 6180 41.0 895 31.57 58%
APC SF 10x7 1 10.7 14.05 150 5880 39.0 790 27.87 54%
APC SF 10x7 1 10.8 5.2 56 4230 28.0 404 14.25 39%
APC SF 10x7 1 10.8 7.05 76 4680 31.0 500 17.64 43%
APC SF 10x7 1 10.8 2.4 25 3240 21.5 224 7.90 30%
APC SF 10x7 1 10.8 9.3 100 5160 34.2 609 21.48 47%
APC SF 10x7 1 10.8 2.95 31 3480 23.1 265 9.35 32%
APC SF 10x7 1 10.8 11.4 123 5520 36.6 694 24.48 51%
APC SF 10x7 1 10.8 3.75 40 3780 25.1 314 11.08 35%
APC SF 10x7 1 10.9 0.45 4 1560 10.3 49 1.73 14%
APC SF 10x7 1 10.9 1.1 11 2340 15.5 114 4.02 21%
APC SF 10x7 1 10.9 1.6 17 2760 18.3 160 5.64 25%
APC E 10x7 1 10.6 19.4 205 8220 54.5 1072 37.81 77%
Aeronaut 10x7 1 10.6 20.2 214 8100 53.7 1075 37.92 76%
GP SF 10x7 1 10.6 21.5 227 6540 43.4 1013 35.73 61%
GP SF 10x7 1 10.7 17.5 187 6150 40.8 886 31.25 57%
GP SF 10x7 1 10.8 14.7 158 5880 39.0 800 28.22 54%
GP SF 10x7 1 10.8 12.1 130 5520 36.6 705 24.87 51%
GP SF 10x7 1 10.8 9.7 104 5130 34.0 606 21.38 47%
GP SF 10x7 1 10.9 0.6 6 1680 11.1 61 2.15 15%
GP SF 10x7 1 10.9 2.15 23 3030 20.1 202 7.13 28%
GP SF 10x7 1 10.9 4.7 51 4020 26.6 365 12.87 37%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GP SF 10x7 1 10.9 2.8 30 3300 21.9 243 8.57 30%
GP SF 10x7 1 10.9 1.45 15 2610 17.3 143 5.04 24%
GP SF 10x7 1 10.9 7.4 80 4710 31.2 505 17.81 43%
GP SF 10x7 1 10.9 5.9 64 4380 29.0 430 15.17 40%
GP SF 10x7 1 10.9 3.7 40 3690 24.5 304 10.72 34%
GP SF 10x7 1 10.9 1 10 2160 14.3 104 3.67 20%
GP SF 10x7 1 10.9 0.35 3 1230 8.2 33 1.16 11%
GP SF 10x7 1 11.5 24.5 281 6870 45.5 1143 40.32 59%
GP SF 11x4.5 1 10.1 24.1 243 6780 28.9 1233 43.49 66%
GP SF 11x4.5 1 10.5 22.4 235 6660 28.4 1218 42.96 63%
GP SF 11x4.5 1 10.6 19.3 204 6420 27.4 1100 38.80 60%
GP SF 11x4.5 1 10.7 17.25 184 6210 26.5 1022 36.05 57%
GP SF 11x4.5 1 10.7 15.15 162 6000 25.6 950 33.51 56%
GP SF 11x4.5 1 10.8 11.6 125 5580 23.8 797 28.11 51%
GP SF 11x4.5 1 10.8 9.75 105 5250 22.4 709 25.01 48%
GP SF 11x4.5 1 10.8 8.15 88 4980 21.2 621 21.91 46%
GP SF 11x4.5 1 10.8 12.9 139 5730 24.4 850 29.98 53%
GP SF 11x4.5 1 10.9 3.3 35 3630 15.5 322 11.36 33%
GP SF 11x4.5 1 10.9 6.8 74 4680 19.9 550 19.40 43%
GP SF 11x4.5 1 10.9 2.55 27 3330 14.2 255 8.99 30%
GP SF 11x4.5 1 10.9 5.9 64 4440 18.9 502 17.71 40%
GP SF 11x4.5 1 10.9 2.1 22 3060 13.0 220 7.76 28%
GP SF 11x4.5 1 10.9 4.35 47 4020 17.1 394 13.90 37%
GP SF 11x4.5 1 10.9 1.5 16 2670 11.4 166 5.86 24%
GP SF 11x4.5 1 11 1 11 2250 9.6 112 3.95 20%
GP SF 11x4.5 1 11 0.55 6 1740 7.4 65 2.29 16%

Comments

Dr Kiwi on 2010-12-22 13:52:31
This is a 12-arm, 14-magnet motor.
