G Force - G10
Specifications
- Type: Outrunner
- Weight: 140.00g (4.94oz)
- Diameter: 35.00mm (1.38in)
- Length: 36.00mm (1.42in)
- Shaft Diameter: 4.00mm (0.16in)
- Maximum Amps: 38
Constants
- kV: 1035
- Rm: 0.09
- Io: 2.3
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 2 | 7080 |
| 8 | 2.1 | 8130 |
| 10 | 2.3 | 10170 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 8x6 | 1 | 6.8 | 8.4 | 57 | 6390 | 36.3 | 299 | 10.55 | 91% |
| APC E 8x6 | 1 | 7.8 | 10.4 | 81 | 7230 | 41.1 | 385 | 13.58 | 90% |
| APC E 8x6 | 1 | 8.7 | 12.4 | 107 | 7980 | 45.3 | 467 | 16.47 | 89% |
| APC E 8x6 | 1 | 9.8 | 15.3 | 149 | 8730 | 49.6 | 582 | 20.53 | 86% |
| APC E 8x6 | 1 | 10.7 | 17.65 | 188 | 9420 | 53.5 | 680 | 23.99 | 85% |
| APC E 9x4.5 | 1 | 6.9 | 7.9 | 54 | 6480 | 27.6 | 401 | 14.14 | 91% |
| APC E 9x4.5 | 1 | 7.8 | 9.65 | 75 | 7290 | 31.1 | 516 | 18.20 | 90% |
| APC E 9x4.5 | 1 | 8.8 | 11.6 | 102 | 8100 | 34.5 | 648 | 22.86 | 89% |
| APC E 9x4.5 | 1 | 9.8 | 13.6 | 133 | 8910 | 38.0 | 773 | 27.27 | 88% |
| APC E 9x4.5 | 1 | 10.7 | 15.9 | 170 | 9630 | 41.0 | 913 | 32.21 | 87% |
| APC E 10x5 | 1 | 6.8 | 10.4 | 70 | 6240 | 29.6 | 523 | 18.45 | 89% |
| APC E 10x5 | 1 | 7.8 | 12.8 | 99 | 6990 | 33.1 | 673 | 23.74 | 87% |
| APC E 10x5 | 1 | 8.8 | 15.3 | 134 | 7740 | 36.6 | 820 | 28.92 | 85% |
| APC E 10x5 | 1 | 9.7 | 18.1 | 175 | 8460 | 40.1 | 1001 | 35.31 | 84% |
| APC E 10x5 | 1 | 10.6 | 21 | 222 | 9090 | 43.0 | 1175 | 41.45 | 83% |
| APC E 11x5.5 | 1 | 6.8 | 13.3 | 90 | 5970 | 31.1 | 680 | 23.99 | 85% |
| APC E 11x5.5 | 1 | 7.8 | 16.55 | 129 | 6690 | 34.8 | 871 | 30.72 | 83% |
| APC E 11x5.5 | 1 | 8.7 | 19.9 | 173 | 7320 | 38.1 | 1071 | 37.78 | 81% |
| APC E 11x5.5 | 1 | 10.8 | 27.9 | 301 | 8430 | 43.9 | 1499 | 52.88 | 75% |
| APC E 11x7 | 1 | 7.6 | 19.5 | 148 | 6210 | 41.2 | 853 | 30.09 | 79% |
| APC E 11x7 | 1 | 10.7 | 33.2 | 355 | 7980 | 52.9 | 1461 | 51.54 | 72% |
| GWS HD 12x6 | 1 | 7.6 | 19.8 | 150 | 6210 | 35.3 | 1015 | 35.80 | 79% |
| GWS HD 12x6 | 1 | 10.3 | 31.5 | 324 | 7830 | 44.5 | 1636 | 57.71 | 73% |
| GWS HD 12x6 | 1 | 11 | 34.7 | 381 | 8190 | 46.5 | 1811 | 63.88 | 72% |
| APC E 13x6.5 | 1 | 7.2 | 23.6 | 169 | 5520 | 34.0 | 1100 | 38.80 | 74% |
| APC E 13x6.5 | 1 | 10.4 | 38.6 | 401 | 6930 | 42.7 | 1810 | 63.85 | 64% |
| APC E 13x6.5 | 1 | 10.5 | 39.9 | 418 | 7020 | 43.2 | 1822 | 64.27 | 65% |
| APC E 13x6.5 | 1 | 10.7 | 42.4 | 453 | 7110 | 43.8 | 1988 | 70.12 | 64% |
