Suppo - H2217/4
Specifications
- Type: Outrunner
- Weight: 66.00g (2.33oz)
- Diameter: 27.60mm (1.09in)
- Length: 33.40mm (1.31in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 55
Constants
- kV: 3765
- Rm: 0.064
- Io: 0.4
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 3.8 | 25420 |
| 8 | 3.8 | 28140 |
| 10 | 4 | 36120 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 4.1x4.1 | 1 | 7.8 | 19.1 | 148 | 24240 | 94.1 | 341 | 12.03 | 83% |
| APC E 4.1x4.1 | 1 | 11.1 | 34.2 | 379 | 32310 | 125.4 | 602 | 21.23 | 77% |
