Infinite - A3007-1240
Specifications
- Type: Outrunner
- Weight: 80.00g (2.82oz)
- Diameter: 37.25mm (1.47in)
- Length: 32.90mm (1.30in)
- Shaft Diameter: 5.00mm (0.20in)
- Maximum Amps: 27
Constants
- kV: 1245
- Rm: 0.1
- Io: 1.7
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.4 | 8530 |
| 8 | 1.5 | 9700 |
| 10 | 1.7 | 12150 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 8x4 | 1 | 6.9 | 6.1 | 42 | 7860 | 29.8 | 320 | 11.29 | 91% |
| GWS HD 8x4 | 1 | 6.9 | 6.1 | 42 | 7860 | 29.8 | 320 | 11.29 | 91% |
| GWS HD 8x4 | 1 | 7.8 | 7.4 | 57 | 8820 | 33.4 | 408 | 14.39 | 91% |
| GWS HD 8x4 | 1 | 7.8 | 7.4 | 57 | 8820 | 33.4 | 408 | 14.39 | 91% |
| GWS HD 8x4 | 1 | 8.8 | 8.9 | 78 | 9780 | 37.0 | 508 | 17.92 | 89% |
| GWS HD 8x4 | 1 | 8.8 | 8.9 | 78 | 9780 | 37.0 | 508 | 17.92 | 89% |
| GWS HD 8x4 | 1 | 9.8 | 10.45 | 102 | 10710 | 40.6 | 613 | 21.62 | 88% |
| GWS HD 8x4 | 1 | 9.8 | 10.45 | 102 | 10710 | 40.6 | 613 | 21.62 | 88% |
| GWS HD 8x4 | 1 | 10.7 | 12.25 | 131 | 11640 | 44.1 | 734 | 25.89 | 87% |
| GWS HD 8x4 | 1 | 10.7 | 12.25 | 131 | 11640 | 44.1 | 734 | 25.89 | 87% |
| GWS HD 9x5 | 1 | 6.8 | 10 | 68 | 7260 | 34.4 | 510 | 17.99 | 86% |
| GWS HD 9x5 | 1 | 6.8 | 10 | 68 | 7260 | 34.4 | 510 | 17.99 | 86% |
| GWS HD 9x5 | 1 | 7.7 | 12.4 | 95 | 8130 | 38.5 | 646 | 22.79 | 85% |
| GWS HD 9x5 | 1 | 7.7 | 12.4 | 95 | 8130 | 38.5 | 646 | 22.79 | 85% |
| GWS HD 9x5 | 1 | 8.7 | 14.9 | 129 | 8940 | 42.3 | 782 | 27.58 | 83% |
| GWS HD 9x5 | 1 | 8.7 | 14.9 | 129 | 8940 | 42.3 | 782 | 27.58 | 83% |
| GWS HD 9x5 | 1 | 9.6 | 17.55 | 168 | 9690 | 45.9 | 930 | 32.80 | 81% |
| GWS HD 9x5 | 1 | 9.6 | 17.55 | 168 | 9690 | 45.9 | 930 | 32.80 | 81% |
| GWS HD 9x5 | 1 | 10.6 | 19.7 | 208 | 10350 | 49.0 | 1075 | 37.92 | 78% |
| GWS HD 9x5 | 1 | 10.6 | 19.7 | 208 | 10350 | 49.0 | 1075 | 37.92 | 78% |
| GWS HD 10x6 | 1 | 7.6 | 15.4 | 117 | 7410 | 42.1 | 740 | 26.10 | 78% |
| GWS HD 10x6 | 1 | 7.6 | 15.4 | 117 | 7410 | 42.1 | 740 | 26.10 | 78% |
| GWS HD 10x6 | 1 | 11.1 | 26.4 | 293 | 9630 | 54.7 | 1300 | 45.86 | 70% |
| GWS HD 10x6 | 1 | 11.1 | 26.4 | 293 | 9630 | 54.7 | 1300 | 45.86 | 70% |
| GWS HD 10x6 | 1 | 11.2 | 26.9 | 301 | 9720 | 55.2 | 1322 | 46.63 | 70% |
| GWS HD 10x6 | 1 | 11.2 | 26.9 | 301 | 9720 | 55.2 | 1322 | 46.63 | 70% |
| GWS HD 10x6 | 1 | 11.3 | 27.6 | 311 | 9870 | 56.1 | 1335 | 47.09 | 70% |
| GWS HD 10x6 | 1 | 11.3 | 27.6 | 311 | 9870 | 56.1 | 1335 | 47.09 | 70% |
| GWS HD 10x6 | 1 | 11.5 | 29.7 | 341 | 10140 | 57.6 | 1435 | 50.62 | 71% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 10x6 | 1 | 11.5 | 29.7 | 341 | 10140 | 57.6 | 1435 | 50.62 | 71% |
