Infinite - H2216-2600

Show Similiar

Infinite - H2216-2600

Specifications

  • Type: Outrunner
  • Weight: 70.00g (2.47oz)
  • Diameter: 27.80mm (1.09in)
  • Length: 35.50mm (1.40in)
  • Shaft Diameter: 3.17mm (0.12in)
  • Maximum Amps: 31

Constants

  • kV: 2570
  • Rm: 0.084
  • Io: 1.55



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 1.25 17370
8 1.35 19860
10 1.55 25270

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
EMP 4.1x4.1 1 6.9 7.1 48 15960 62.0 165 5.82 90%
EMP 4.1x4.1 1 6.9 7.1 48 15960 62.0 165 5.82 90%
EMP 4.1x4.1 1 7.8 8.9 69 17910 69.5 211 7.44 89%
EMP 4.1x4.1 1 7.8 8.9 69 17910 69.5 211 7.44 89%
EMP 4.1x4.1 1 8.8 10.7 94 19950 77.5 261 9.21 88%
EMP 4.1x4.1 1 8.8 10.7 94 19950 77.5 261 9.21 88%
EMP 4.1x4.1 1 9.8 13.1 128 22050 85.6 319 11.25 88%
EMP 4.1x4.1 1 9.8 13.1 128 22050 85.6 319 11.25 88%
EMP 4.1x4.1 1 10.7 15.25 163 24000 93.2 376 13.26 87%
EMP 4.1x4.1 1 10.7 15.25 163 24000 93.2 376 13.26 87%
EMP 4.5x4.5 1 6.8 8.25 56 15600 66.5 240 8.47 89%
EMP 4.5x4.5 1 6.8 8.25 56 15600 66.5 240 8.47 89%
EMP 4.5x4.5 1 7.8 10.45 81 17550 74.8 313 11.04 88%
EMP 4.5x4.5 1 7.8 10.45 81 17550 74.8 313 11.04 88%
EMP 4.5x4.5 1 8.8 12.65 111 19410 82.7 389 13.72 86%
EMP 4.5x4.5 1 8.8 12.65 111 19410 82.7 389 13.72 86%
EMP 4.5x4.5 1 9.8 15.1 147 21330 90.9 465 16.40 85%
EMP 4.5x4.5 1 9.8 15.1 147 21330 90.9 465 16.40 85%
EMP 4.5x4.5 1 10.7 17.75 189 23310 99.3 555 19.58 85%
EMP 4.5x4.5 1 10.7 17.75 189 23310 99.3 555 19.58 85%
Graupner CAM Speed 4.7x4.7 1 6.8 9.6 65 15300 68.1 214 7.55 88%
Graupner CAM Speed 4.7x4.7 1 6.8 9.6 65 15300 68.1 214 7.55 88%
Graupner CAM Speed 4.7x4.7 1 7.8 12.3 95 17070 76.0 271 9.56 85%
Graupner CAM Speed 4.7x4.7 1 7.8 12.3 95 17070 76.0 271 9.56 85%
Graupner CAM Speed 4.7x4.7 1 8.8 14.8 130 18900 84.1 333 11.75 84%
Graupner CAM Speed 4.7x4.7 1 8.8 14.8 130 18900 84.1 333 11.75 84%
Graupner CAM Speed 4.7x4.7 1 9.8 17.6 172 20670 92.0 399 14.07 82%
Graupner CAM Speed 4.7x4.7 1 9.8 17.6 172 20670 92.0 399 14.07 82%
Graupner CAM Speed 4.7x4.7 1 10.7 20.4 218 22470 100.0 470 16.58 82%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
Graupner CAM Speed 4.7x4.7 1 10.7 20.4 218 22470 100.0 470 16.58 82%
APC E 4.75x5.5 1 6.8 11.2 76 14910 77.7 195 6.88 85%
APC E 4.75x5.5 1 6.8 11.2 76 14910 77.7 195 6.88 85%
APC E 4.75x5.5 1 7.8 13.9 108 16650 86.7 246 8.68 83%
APC E 4.75x5.5 1 7.8 13.9 108 16650 86.7 246 8.68 83%
APC E 4.75x5.5 1 8.7 16.7 145 18360 95.6 297 10.48 82%
APC E 4.75x5.5 1 8.7 16.7 145 18360 95.6 297 10.48 82%
APC E 4.75x5.5 1 9.7 19.7 191 19950 103.9 349 12.31 80%
APC E 4.75x5.5 1 9.7 19.7 191 19950 103.9 349 12.31 80%
APC E 4.75x5.5 1 10.6 23.5 249 21600 112.5 413 14.57 79%
APC E 4.75x5.5 1 10.6 23.5 249 21600 112.5 413 14.57 79%
Zagi Carbon 5.1x4.9 1 7.5 14.5 108 16350 75.9 390 13.76 85%
Zagi Carbon 5.1x4.9 1 7.5 14.5 108 16350 75.9 390 13.76 85%
Zagi Carbon 5.1x4.9 1 11.5 29 333 23130 107.3 778 27.44 78%
Zagi Carbon 5.1x4.9 1 11.5 29 333 23130 107.3 778 27.44 78%
Graupner CAM Speed 5.2x5.2 1 7.4 16.6 122 15780 77.7 350 12.35 83%
Graupner CAM Speed 5.2x5.2 1 7.4 16.6 122 15780 77.7 350 12.35 83%
Graupner CAM Speed 5.2x5.2 1 11.3 32.7 369 22080 108.7 680 23.99 76%
Graupner CAM Speed 5.2x5.2 1 11.3 32.7 369 22080 108.7 680 23.99 76%
