Infinite - A2205-1560

Show Similiar


Specifications

  • Type: Outrunner
  • Weight: 34.00g (1.20oz)
  • Diameter: 27.70mm (1.09in)
  • Length: 24.60mm (0.97in)
  • Shaft Diameter: 3.00mm (0.12in)
  • Maximum Amps: 10

Constants

  • kV: 1580
  • Rm: 0.3
  • Io: 0.75



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 0.6 10740
8 0.65 12180
10 0.75 15450

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 6x4 1 6.9 3.9 26 9270 35.1 161 5.68 85%
APC E 6x4 1 6.9 3.9 26 9270 35.1 161 5.68 85%
APC E 6x4 1 7.9 4.65 36 10320 39.1 203 7.16 83%
APC E 6x4 1 7.9 4.65 36 10320 39.1 203 7.16 83%
APC E 6x4 1 8.9 5.6 49 11430 43.3 253 8.92 81%
APC E 6x4 1 8.9 5.6 49 11430 43.3 253 8.92 81%
APC E 6x4 1 9.8 6.45 63 12360 46.8 300 10.58 80%
APC E 6x4 1 9.8 6.45 63 12360 46.8 300 10.58 80%
APC E 6x4 1 10.8 7.4 79 13350 50.6 350 12.35 78%
APC E 6x4 1 10.8 7.4 79 13350 50.6 350 12.35 78%
HZ 6x4 1 6.9 4 27 9030 34.2 163 5.75 83%
HZ 6x4 1 6.9 4 27 9030 34.2 163 5.75 83%
HZ 6x4 1 7.9 5 39 10170 38.5 211 7.44 81%
HZ 6x4 1 7.9 5 39 10170 38.5 211 7.44 81%
HZ 6x4 1 8.9 5.9 52 11220 42.5 263 9.28 80%
HZ 6x4 1 8.9 5.9 52 11220 42.5 263 9.28 80%
HZ 6x4 1 9.9 6.8 67 12210 46.2 320 11.29 78%
HZ 6x4 1 9.9 6.8 67 12210 46.2 320 11.29 78%
HZ 6x4 1 10.8 7.8 84 13140 49.8 378 13.33 77%
HZ 6x4 1 10.8 7.8 84 13140 49.8 378 13.33 77%
EMP 6x4 1 6.9 3.65 25 9390 35.6 172 6.07 86%
EMP 6x4 1 7.9 4.4 34 10500 39.8 220 7.76 84%
EMP 6x4 1 8.9 5.3 47 11580 43.9 278 9.81 82%
EMP 6x4 1 9.9 6.15 60 12570 47.6 335 11.82 80%
EMP 6x4 1 10.8 7 75 13500 51.1 392 13.83 79%
EMP 6x5 1 6.9 3.65 25 9390 44.5 172 6.07 86%
EMP 6x5 1 7.9 4.4 34 10500 49.7 220 7.76 84%
EMP 6x5 1 8.9 5.3 47 11580 54.8 278 9.81 82%
EMP 6x5 1 9.9 6.15 60 12570 59.5 335 11.82 80%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
EMP 6x5 1 10.8 7 75 13500 63.9 392 13.83 79%
APC E 6x5.5 1 6.9 5.05 34 8610 44.8 161 5.68 79%
APC E 6x5.5 1 6.9 5.05 34 8610 44.8 161 5.68 79%
APC E 6x5.5 1 7.9 6.2 48 9660 50.3 204 7.20 77%
APC E 6x5.5 1 7.9 6.2 48 9660 50.3 204 7.20 77%
APC E 6x5.5 1 8.9 7.3 64 10560 55.0 247 8.71 75%
APC E 6x5.5 1 8.9 7.3 64 10560 55.0 247 8.71 75%
APC E 6x5.5 1 9.8 8.45 82 11400 59.4 293 10.34 74%
APC E 6x5.5 1 9.8 8.45 82 11400 59.4 293 10.34 74%
APC E 6x5.5 1 10.8 9.6 103 12240 63.8 335 11.82 72%
APC E 6x5.5 1 10.8 9.6 103 12240 63.8 335 11.82 72%
Aeronaut 6.5x4 1 6.9 4.5 31 8850 33.5 207 7.30 81%
Aeronaut 6.5x4 1 6.9 4.5 31 8850 33.5 207 7.30 81%
Aeronaut 6.5x4 1 7.9 5.55 43 9930 37.6 262 9.24 80%
Aeronaut 6.5x4 1 7.9 5.55 43 9930 37.6 262 9.24 80%
Aeronaut 6.5x4 1 8.9 6.5 57 10980 41.6 336 11.85 78%
Aeronaut 6.5x4 1 8.9 6.5 57 10980 41.6 336 11.85 78%
Aeronaut 6.5x4 1 9.8 7.5 73 11850 44.9 395 13.93 77%
Aeronaut 6.5x4 1 9.8 7.5 73 11850 44.9 395 13.93 77%
Aeronaut 6.5x4 1 10.8 8.7 93 12720 48.2 462 16.30 75%
Aeronaut 6.5x4 1 10.8 8.7 93 12720 48.2 462 16.30 75%
MAS EO 6.5x4 1 6.9 5.9 40 8220 31.1 203 7.16 75%
MAS EO 6.5x4 1 6.9 5.9 40 8220 31.1 203 7.16 75%
MAS EO 6.5x4 1 7.8 7.05 54 9090 34.4 251 8.85 74%
MAS EO 6.5x4 1 7.8 7.05 54 9090 34.4 251 8.85 74%
MAS EO 6.5x4 1 8.8 8.4 73 9960 37.7 306 10.79 72%
MAS EO 6.5x4 1 8.8 8.4 73 9960 37.7 306 10.79 72%
MAS EO 6.5x4 1 9.8 9.75 95 10710 40.6 357 12.59 69%
MAS EO 6.5x4 1 9.8 9.75 95 10710 40.6 357 12.59 69%
MAS EO 6.5x4 1 10.8 11.1 119 11460 43.4 414 14.60 67%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
MAS EO 6.5x4 1 10.8 11.1 119 11460 43.4 414 14.60 67%
APC Sport 6.5x6.5 1 6.9 6.3 43 8130 50.0 168 5.93 75%
APC Sport 6.5x6.5 1 6.9 6.3 43 8130 50.0 168 5.93 75%
APC Sport 6.5x6.5 1 7.8 7.4 57 8910 54.8 204 7.20 72%
APC Sport 6.5x6.5 1 7.8 7.4 57 8910 54.8 204 7.20 72%
APC Sport 6.5x6.5 1 8.8 8.85 77 9750 60.0 247 8.71 70%
APC Sport 6.5x6.5 1 8.8 8.85 77 9750 60.0 247 8.71 70%
APC Sport 6.5x6.5 1 9.8 10.25 100 10560 65.0 294 10.37 68%
APC Sport 6.5x6.5 1 9.8 10.25 100 10560 65.0 294 10.37 68%
APC Sport 6.5x6.5 1 10.8 11.2 120 11250 69.2 343 12.10 66%
APC Sport 6.5x6.5 1 10.8 11.2 120 11250 69.2 343 12.10 66%
APC SF Broad 7x3.8 1 6.9 6.7 46 7920 28.5 317 11.18 73%
APC SF Broad 7x3.8 1 7.9 8.15 64 8640 31.1 389 13.72 69%
APC SF Broad 7x3.8 1 8.8 9.8 86 9360 33.7 455 16.05 67%
APC SF Broad 7x3.8 1 9.8 11.25 110 9960 35.8 532 18.77 64%
APC SF Broad 7x3.8 1 10.7 12.6 134 10470 37.7 588 20.74 62%
APC WSF 7x3.8 1 6.9 6.7 46 7920 28.5 317 11.18 73%
APC WSF 7x3.8 1 7.9 8.15 64 8640 31.1 389 13.72 69%
APC WSF 7x3.8 1 8.8 9.8 86 9360 33.7 455 16.05 67%
APC WSF 7x3.8 1 9.8 11.25 110 9960 35.8 532 18.77 64%
APC WSF 7x3.8 1 10.7 12.6 134 10470 37.7 588 20.74 62%
APC E 7x5 1 6.9 6.7 46 7920 37.5 278 9.81 73%
APC E 7x5 1 6.9 6.7 46 7920 37.5 278 9.81 73%
APC E 7x5 1 7.9 7.95 62 8730 41.3 343 12.10 70%
APC E 7x5 1 7.9 7.95 62 8730 41.3 343 12.10 70%
APC E 7x5 1 8.9 9.6 85 9570 45.3 414 14.60 68%
APC E 7x5 1 8.9 9.6 85 9570 45.3 414 14.60 68%
APC E 7x5 1 9.8 10.9 106 10170 48.1 475 16.76 66%
APC E 7x5 1 9.8 10.9 106 10170 48.1 475 16.76 66%
APC E 7x5 1 10.8 12.2 131 10770 51.0 533 18.80 63%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 7x5 1 10.8 12.2 131 10770 51.0 533 18.80 63%
GWS HD 8x4 1 6.9 6.6 45 7920 30.0 338 11.92 73%
GWS HD 8x4 1 6.9 6.6 45 7920 30.0 338 11.92 73%
GWS HD 8x4 1 7.8 7.9 61 8700 33.0 410 14.46 71%
GWS HD 8x4 1 7.8 7.9 61 8700 33.0 410 14.46 71%
GWS HD 8x4 1 8.8 9.5 83 9480 35.9 493 17.39 68%
GWS HD 8x4 1 8.8 9.5 83 9480 35.9 493 17.39 68%
GWS HD 8x4 1 9.8 10.9 106 10110 38.3 569 20.07 65%
GWS HD 8x4 1 9.8 10.9 106 10110 38.3 569 20.07 65%
GWS HD 8x4 1 10.7 12.3 131 10680 40.5 638 22.50 63%
GWS HD 8x4 1 10.7 12.3 131 10680 40.5 638 22.50 63%
GWS HD 9x5 1 7 10 70 6780 32.1 451 15.91 61%
GWS HD 9x5 1 7 10 70 6780 32.1 451 15.91 61%
GWS HD 9x5 1 7.4 10.4 76 6930 32.8 480 16.93 59%
GWS HD 9x5 1 7.4 10.4 76 6930 32.8 480 16.93 59%
GWS HD 10x6 1 7 11.8 82 5850 33.2 477 16.83 53%
GWS HD 10x6 1 7 11.8 82 5850 33.2 477 16.83 53%
GWS HD 10x6 1 7.4 12.1 89 5910 33.6 490 17.28 51%
GWS HD 10x6 1 7.4 12.1 89 5910 33.6 490 17.28 51%
