Infinite - A1709-1500
Specifications
- Type: Outrunner
- Weight: 25.00g (0.88oz)
- Diameter: 21.00mm (0.83in)
- Length: 25.00mm (0.98in)
- Shaft Diameter: 2.00mm (0.08in)
- Maximum Amps: 8
Constants
- kV: 1550
- Rm: 0.31
- Io: 0.85
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.65 | 10530 |
| 8 | 0.7 | 12240 |
| 10 | 0.85 | 15210 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| Gunther 4.92x4.33 | 1 | 6.9 | 3 | 20 | 9360 | 38.4 | 127 | 4.48 | 88% |
| Gunther 4.92x4.33 | 1 | 7.9 | 3.7 | 29 | 10470 | 42.9 | 164 | 5.78 | 86% |
| Gunther 4.92x4.33 | 1 | 8.9 | 4.35 | 38 | 11730 | 48.1 | 203 | 7.16 | 85% |
| Gunther 4.92x4.33 | 1 | 9.9 | 5.05 | 49 | 12780 | 52.4 | 243 | 8.57 | 83% |
| Gunther 4.92x4.33 | 1 | 10.9 | 5.8 | 63 | 13860 | 56.8 | 284 | 10.02 | 82% |
| Gunther White 4.92x4.33 | 1 | 6.9 | 3 | 20 | 9360 | 38.4 | 127 | 4.48 | 88% |
| Gunther White 4.92x4.33 | 1 | 7.9 | 3.7 | 29 | 10470 | 42.9 | 164 | 5.78 | 86% |
| Gunther White 4.92x4.33 | 1 | 8.9 | 4.35 | 38 | 11730 | 48.1 | 203 | 7.16 | 85% |
| Gunther White 4.92x4.33 | 1 | 9.9 | 5.05 | 49 | 12780 | 52.4 | 243 | 8.57 | 83% |
| Gunther White 4.92x4.33 | 1 | 10.9 | 5.8 | 63 | 13860 | 56.8 | 284 | 10.02 | 82% |
| GWS HD 5x4.3 | 1 | 6.9 | 2.5 | 17 | 9570 | 39.0 | 114 | 4.02 | 89% |
| GWS HD 5x4.3 | 1 | 6.9 | 2.5 | 17 | 9570 | 39.0 | 114 | 4.02 | 89% |
| GWS HD 5x4.3 | 1 | 7.9 | 3.1 | 24 | 10950 | 44.6 | 149 | 5.26 | 89% |
| GWS HD 5x4.3 | 1 | 7.9 | 3.1 | 24 | 10950 | 44.6 | 149 | 5.26 | 89% |
| GWS HD 5x4.3 | 1 | 8.9 | 3.6 | 32 | 12120 | 49.4 | 181 | 6.38 | 88% |
| GWS HD 5x4.3 | 1 | 8.9 | 3.6 | 32 | 12120 | 49.4 | 181 | 6.38 | 88% |
| GWS HD 5x4.3 | 1 | 9.9 | 4.15 | 41 | 13380 | 54.5 | 217 | 7.65 | 87% |
| GWS HD 5x4.3 | 1 | 9.9 | 4.15 | 41 | 13380 | 54.5 | 217 | 7.65 | 87% |
| GWS HD 5x4.3 | 1 | 10.9 | 4.7 | 51 | 14430 | 58.8 | 254 | 8.96 | 85% |
| GWS HD 5x4.3 | 1 | 10.9 | 4.7 | 51 | 14430 | 58.8 | 254 | 8.96 | 85% |
| GWS HD 6x3 | 1 | 7 | 2.7 | 18 | 9540 | 27.1 | 142 | 5.01 | 88% |
| GWS HD 6x3 | 1 | 7 | 2.7 | 18 | 9540 | 27.1 | 142 | 5.01 | 88% |
| GWS HD 6x3 | 1 | 7.9 | 3.35 | 26 | 10800 | 30.7 | 186 | 6.56 | 88% |
| GWS HD 6x3 | 1 | 7.9 | 3.35 | 26 | 10800 | 30.7 | 186 | 6.56 | 88% |
| GWS HD 6x3 | 1 | 8.9 | 3.95 | 35 | 11940 | 33.9 | 229 | 8.08 | 87% |
| GWS HD 6x3 | 1 | 8.9 | 3.95 | 35 | 11940 | 33.9 | 229 | 8.08 | 87% |
| GWS HD 6x3 | 1 | 9.9 | 4.6 | 45 | 13020 | 37.0 | 275 | 9.70 | 85% |
| GWS HD 6x3 | 1 | 9.9 | 4.6 | 45 | 13020 | 37.0 | 275 | 9.70 | 85% |
| GWS HD 6x3 | 1 | 10.9 | 5.35 | 58 | 14130 | 40.1 | 326 | 11.50 | 84% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 6x3 | 1 | 10.9 | 5.35 | 58 | 14130 | 40.1 | 326 | 11.50 | 84% |
| GWS HD 7x3.5 | 1 | 6.9 | 3.6 | 24 | 9120 | 30.2 | 197 | 6.95 | 85% |
| GWS HD 7x3.5 | 1 | 6.9 | 3.6 | 24 | 9120 | 30.2 | 197 | 6.95 | 85% |
| GWS HD 7x3.5 | 1 | 7.9 | 4.35 | 34 | 10110 | 33.5 | 249 | 8.78 | 83% |
| GWS HD 7x3.5 | 1 | 7.9 | 4.35 | 34 | 10110 | 33.5 | 249 | 8.78 | 83% |
| GWS HD 7x3.5 | 1 | 8.9 | 5.3 | 47 | 11150 | 37.0 | 312 | 11.01 | 81% |
| GWS HD 7x3.5 | 1 | 8.9 | 5.3 | 47 | 11150 | 37.0 | 312 | 11.01 | 81% |
| GWS HD 7x3.5 | 1 | 9.9 | 6.15 | 60 | 12180 | 40.4 | 372 | 13.12 | 79% |
| GWS HD 7x3.5 | 1 | 9.9 | 6.15 | 60 | 12180 | 40.4 | 372 | 13.12 | 79% |
| GWS HD 7x3.5 | 1 | 10.9 | 7.15 | 77 | 13140 | 43.5 | 439 | 15.49 | 78% |
| GWS HD 7x3.5 | 1 | 10.9 | 7.15 | 77 | 13140 | 43.5 | 439 | 15.49 | 78% |
| APC SF 7x4 | 1 | 7 | 5.45 | 38 | 8310 | 31.5 | 265 | 9.35 | 77% |
| APC SF 7x4 | 1 | 7 | 5.45 | 38 | 8310 | 31.5 | 265 | 9.35 | 77% |
| APC SF 7x4 | 1 | 7.4 | 5.9 | 43 | 8610 | 32.6 | 289 | 10.19 | 75% |
| APC SF 7x4 | 1 | 7.4 | 5.9 | 43 | 8610 | 32.6 | 289 | 10.19 | 75% |
| APC SF 7x4 | 1 | 7.9 | 6.4 | 50 | 9000 | 34.1 | 316 | 11.15 | 73% |
| APC SF 7x4 | 1 | 7.9 | 6.4 | 50 | 9000 | 34.1 | 316 | 11.15 | 73% |
| APC SF 7x4 | 1 | 8.9 | 7.6 | 67 | 9750 | 36.9 | 376 | 13.26 | 71% |
| APC SF 7x4 | 1 | 8.9 | 7.6 | 67 | 9750 | 36.9 | 376 | 13.26 | 71% |
| APC SF 7x4 | 1 | 9.9 | 9 | 89 | 10470 | 39.7 | 441 | 15.56 | 68% |
| APC SF 7x4 | 1 | 9.9 | 9 | 89 | 10470 | 39.7 | 441 | 15.56 | 68% |
| APC SF 7x4 | 1 | 10.9 | 10.2 | 111 | 11070 | 41.9 | 500 | 17.64 | 66% |
| APC SF 7x4 | 1 | 10.9 | 10.2 | 111 | 11070 | 41.9 | 500 | 17.64 | 66% |
| GWS HD 8x4 | 1 | 7 | 6.35 | 44 | 7830 | 29.7 | 324 | 11.43 | 72% |
| GWS HD 8x4 | 1 | 7 | 6.35 | 44 | 7830 | 29.7 | 324 | 11.43 | 72% |
| GWS HD 8x4 | 1 | 7.4 | 6.8 | 50 | 8130 | 30.8 | 347 | 12.24 | 71% |
| GWS HD 8x4 | 1 | 7.4 | 6.8 | 50 | 8130 | 30.8 | 347 | 12.24 | 71% |
| GWS RS 8x4.3 | 1 | 7 | 7.55 | 52 | 7200 | 29.3 | 347 | 12.24 | 66% |
| GWS RS 8x4.3 | 1 | 7 | 7.55 | 52 | 7200 | 29.3 | 347 | 12.24 | 66% |
| GWS RS 8x4.3 | 1 | 7.4 | 8.05 | 59 | 7410 | 30.2 | 371 | 13.09 | 65% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS RS 8x4.3 | 1 | 7.4 | 8.05 | 59 | 7410 | 30.2 | 371 | 13.09 | 65% |
