Motrolfly - 2210-1700 v2
Specifications
- Type: Inrunner
- Weight: 43.00g (1.52oz)
- Diameter: 28.00mm (1.10in)
- Length: 24.45mm (0.96in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 18
Constants
- kV: 1895
- Rm: 0.14
- Io: 1.55
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.5 | 12780 |
| 8 | 1.55 | 14850 |
| 10 | 1.55 | 18270 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| Zagi Carbon 5.1x4.9 | 1 | 6.9 | 5.8 | 40 | 11580 | 53.7 | 192 | 6.77 | 89% |
| Zagi Carbon 5.1x4.9 | 1 | 6.9 | 5.8 | 40 | 11580 | 53.7 | 192 | 6.77 | 89% |
| Zagi Carbon 5.1x4.9 | 1 | 7.8 | 6.95 | 54 | 12930 | 60.0 | 241 | 8.50 | 87% |
| Zagi Carbon 5.1x4.9 | 1 | 7.8 | 6.95 | 54 | 12930 | 60.0 | 241 | 8.50 | 87% |
| Zagi Carbon 5.1x4.9 | 1 | 8.8 | 8.3 | 73 | 14340 | 66.5 | 299 | 10.55 | 86% |
| Zagi Carbon 5.1x4.9 | 1 | 8.8 | 8.3 | 73 | 14340 | 66.5 | 299 | 10.55 | 86% |
| Zagi Carbon 5.1x4.9 | 1 | 9.8 | 9.9 | 97 | 15810 | 73.4 | 362 | 12.77 | 85% |
| Zagi Carbon 5.1x4.9 | 1 | 9.8 | 9.9 | 97 | 15810 | 73.4 | 362 | 12.77 | 85% |
| Zagi Carbon 5.1x4.9 | 1 | 10.7 | 11.2 | 119 | 17040 | 79.1 | 421 | 14.85 | 84% |
| Zagi Carbon 5.1x4.9 | 1 | 10.7 | 11.2 | 119 | 17040 | 79.1 | 421 | 14.85 | 84% |
| APC E 6x4 | 1 | 6.9 | 6.85 | 47 | 11250 | 42.6 | 240 | 8.47 | 86% |
| APC E 6x4 | 1 | 6.9 | 6.85 | 47 | 11250 | 42.6 | 240 | 8.47 | 86% |
| APC E 6x4 | 1 | 7.8 | 8.3 | 64 | 12570 | 47.6 | 307 | 10.83 | 85% |
| APC E 6x4 | 1 | 7.8 | 8.3 | 64 | 12570 | 47.6 | 307 | 10.83 | 85% |
| APC E 6x4 | 1 | 8.8 | 9.85 | 86 | 13860 | 52.5 | 381 | 13.44 | 83% |
| APC E 6x4 | 1 | 8.8 | 9.85 | 86 | 13860 | 52.5 | 381 | 13.44 | 83% |
| APC E 6x4 | 1 | 9.7 | 11.65 | 113 | 15240 | 57.7 | 464 | 16.37 | 83% |
| APC E 6x4 | 1 | 9.7 | 11.65 | 113 | 15240 | 57.7 | 464 | 16.37 | 83% |
| APC E 6x4 | 1 | 10.7 | 13.3 | 142 | 16350 | 61.9 | 541 | 19.08 | 81% |
| APC E 6x4 | 1 | 10.7 | 13.3 | 142 | 16350 | 61.9 | 541 | 19.08 | 81% |
| APC E 6x5.5 | 1 | 6.8 | 9.3 | 63 | 10500 | 54.7 | 245 | 8.64 | 81% |
| APC E 6x5.5 | 1 | 6.8 | 9.3 | 63 | 10500 | 54.7 | 245 | 8.64 | 81% |
| APC E 6x5.5 | 1 | 7.8 | 11.15 | 86 | 11730 | 61.1 | 309 | 10.90 | 79% |
| APC E 6x5.5 | 1 | 7.8 | 11.15 | 86 | 11730 | 61.1 | 309 | 10.90 | 79% |
| APC E 6x5.5 | 1 | 8.8 | 12.95 | 113 | 12990 | 67.7 | 386 | 13.62 | 78% |
| APC E 6x5.5 | 1 | 8.8 | 12.95 | 113 | 12990 | 67.7 | 386 | 13.62 | 78% |
| APC E 6x5.5 | 1 | 9.7 | 14.9 | 144 | 14070 | 73.3 | 456 | 16.08 | 77% |
| APC E 6x5.5 | 1 | 9.7 | 14.9 | 144 | 14070 | 73.3 | 456 | 16.08 | 77% |
| APC E 6x5.5 | 1 | 10.7 | 17.2 | 184 | 15330 | 79.8 | 541 | 19.08 | 76% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| APC E 6x5.5 | 1 | 10.7 | 17.2 | 184 | 15330 | 79.8 | 541 | 19.08 | 76% |
| Graupner CAM Speed 6x6 | 1 | 6.8 | 9.2 | 62 | 10590 | 60.2 | 236 | 8.32 | 82% |
| Graupner CAM Speed 6x6 | 1 | 6.8 | 9.2 | 62 | 10590 | 60.2 | 236 | 8.32 | 82% |
| Graupner CAM Speed 6x6 | 1 | 7.8 | 11.1 | 86 | 11760 | 66.8 | 298 | 10.51 | 80% |
| Graupner CAM Speed 6x6 | 1 | 7.8 | 11.1 | 86 | 11760 | 66.8 | 298 | 10.51 | 80% |
| Graupner CAM Speed 6x6 | 1 | 8.7 | 12.9 | 112 | 12870 | 73.1 | 356 | 12.56 | 78% |
| Graupner CAM Speed 6x6 | 1 | 8.7 | 12.9 | 112 | 12870 | 73.1 | 356 | 12.56 | 78% |
| Graupner CAM Speed 6x6 | 1 | 9.7 | 14.95 | 145 | 13980 | 79.4 | 424 | 14.96 | 76% |
| Graupner CAM Speed 6x6 | 1 | 9.7 | 14.95 | 145 | 13980 | 79.4 | 424 | 14.96 | 76% |
| Graupner CAM Speed 6x6 | 1 | 10.7 | 17.6 | 188 | 15180 | 86.2 | 501 | 17.67 | 75% |
| Graupner CAM Speed 6x6 | 1 | 10.7 | 17.6 | 188 | 15180 | 86.2 | 501 | 17.67 | 75% |
| Graupner Speed 6.5x6.5 | 1 | 6.8 | 11.2 | 76 | 10050 | 61.9 | 283 | 9.98 | 78% |
| Graupner Speed 6.5x6.5 | 1 | 6.8 | 11.2 | 76 | 10050 | 61.9 | 283 | 9.98 | 78% |
| Graupner Speed 6.5x6.5 | 1 | 7.7 | 13.5 | 103 | 11100 | 68.3 | 343 | 12.10 | 76% |
| Graupner Speed 6.5x6.5 | 1 | 7.7 | 13.5 | 103 | 11100 | 68.3 | 343 | 12.10 | 76% |
| Graupner Speed 6.5x6.5 | 1 | 8.7 | 15.8 | 137 | 12120 | 74.6 | 408 | 14.39 | 74% |
| Graupner Speed 6.5x6.5 | 1 | 8.7 | 15.8 | 137 | 12120 | 74.6 | 408 | 14.39 | 74% |
| Graupner Speed 6.5x6.5 | 1 | 9.7 | 18.2 | 176 | 13050 | 80.3 | 478 | 16.86 | 71% |
| Graupner Speed 6.5x6.5 | 1 | 9.7 | 18.2 | 176 | 13050 | 80.3 | 478 | 16.86 | 71% |
| Graupner Speed 6.5x6.5 | 1 | 10.7 | 20.6 | 220 | 13950 | 85.9 | 540 | 19.05 | 69% |
| Graupner Speed 6.5x6.5 | 1 | 10.7 | 20.6 | 220 | 13950 | 85.9 | 540 | 19.05 | 69% |
| APC E 7x5 | 1 | 6.7 | 12.3 | 82 | 9780 | 46.3 | 428 | 15.10 | 77% |
| APC E 7x5 | 1 | 6.7 | 12.3 | 82 | 9780 | 46.3 | 428 | 15.10 | 77% |
| APC E 7x5 | 1 | 7.7 | 14.85 | 114 | 10770 | 51.0 | 532 | 18.77 | 74% |
| APC E 7x5 | 1 | 7.7 | 14.85 | 114 | 10770 | 51.0 | 532 | 18.77 | 74% |
| APC E 7x5 | 1 | 8.7 | 17.45 | 151 | 11700 | 55.4 | 634 | 22.36 | 71% |
| APC E 7x5 | 1 | 8.7 | 17.45 | 151 | 11700 | 55.4 | 634 | 22.36 | 71% |
| APC E 7x5 | 1 | 9.7 | 20.1 | 194 | 12570 | 59.5 | 729 | 25.71 | 68% |
| APC E 7x5 | 1 | 9.7 | 20.1 | 194 | 12570 | 59.5 | 729 | 25.71 | 68% |
| APC E 7x5 | 1 | 10.7 | 22.8 | 243 | 13290 | 62.9 | 825 | 29.10 | 66% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| APC E 7x5 | 1 | 10.7 | 22.8 | 243 | 13290 | 62.9 | 825 | 29.10 | 66% |
| GWS HD 8x4 | 1 | 7 | 12.75 | 89 | 10080 | 38.2 | 544 | 19.19 | 76% |
| GWS HD 8x4 | 1 | 7 | 12.75 | 89 | 10080 | 38.2 | 544 | 19.19 | 76% |
| GWS HD 8x4 | 1 | 7.4 | 13.65 | 101 | 10530 | 39.9 | 590 | 20.81 | 75% |
| GWS HD 8x4 | 1 | 7.4 | 13.65 | 101 | 10530 | 39.9 | 590 | 20.81 | 75% |
| GWS HD 9x5 | 1 | 7.3 | 19.4 | 141 | 8580 | 40.6 | 732 | 25.82 | 62% |
| GWS HD 9x5 | 1 | 7.3 | 19.4 | 141 | 8580 | 40.6 | 732 | 25.82 | 62% |
