Motrolfly - 2205-2800 v2

Show Similiar


Specifications

  • Type: Outrunner
  • Weight: 28.00g (0.99oz)
  • Diameter: 28.00mm (1.10in)
  • Length: 14.00mm (0.55in)
  • Shaft Diameter: 3.00mm (0.12in)
  • Maximum Amps: 25

Constants

  • kV: 3030
  • Rm: 0.11
  • Io: 3.05



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 2.3 20000
8 2.4 23000
10 3.05 29000

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
Graupner CAM Speed 4x3 1 6.8 7.5 51 18060 51.3 175 6.17 88%
Graupner CAM Speed 4x3 1 6.8 7.5 51 18060 51.3 175 6.17 88%
Graupner CAM Speed 4x3 1 7.8 9.05 70 20310 57.7 222 7.83 86%
Graupner CAM Speed 4x3 1 7.8 9.05 70 20310 57.7 222 7.83 86%
Graupner CAM Speed 4x3 1 8.8 10.9 95 22500 63.9 275 9.70 84%
Graupner CAM Speed 4x3 1 8.8 10.9 95 22500 63.9 275 9.70 84%
Graupner CAM Speed 4x3 1 9.8 12.95 126 24570 69.8 334 11.78 83%
Graupner CAM Speed 4x3 1 9.8 12.95 126 24570 69.8 334 11.78 83%
Graupner CAM Speed 4x3 1 10.7 14.9 159 26460 75.2 385 13.58 82%
Graupner CAM Speed 4x3 1 10.7 14.9 159 26460 75.2 385 13.58 82%
APC E 4.1x4.1 1 6.8 8.4 57 17730 68.8 182 6.42 86%
APC E 4.1x4.1 1 6.8 8.4 57 17730 68.8 182 6.42 86%
APC E 4.1x4.1 1 7.8 10 78 19860 77.1 228 8.04 84%
APC E 4.1x4.1 1 7.8 10 78 19860 77.1 228 8.04 84%
APC E 4.1x4.1 1 8.8 12.2 107 21990 85.4 283 9.98 82%
APC E 4.1x4.1 1 8.8 12.2 107 21990 85.4 283 9.98 82%
APC E 4.1x4.1 1 9.7 14.3 138 23880 92.7 338 11.92 81%
APC E 4.1x4.1 1 9.7 14.3 138 23880 92.7 338 11.92 81%
APC E 4.1x4.1 1 10.7 16.7 178 25880 100.5 398 14.04 80%
APC E 4.1x4.1 1 10.7 16.7 178 25880 100.5 398 14.04 80%
Graupner CAM Speed 4.7x4.7 1 6.8 12.95 88 16290 72.5 257 9.07 79%
Graupner CAM Speed 4.7x4.7 1 6.8 12.95 88 16290 72.5 257 9.07 79%
Graupner CAM Speed 4.7x4.7 1 7.7 15.6 120 18000 80.1 315 11.11 77%
Graupner CAM Speed 4.7x4.7 1 7.7 15.6 120 18000 80.1 315 11.11 77%
Graupner CAM Speed 4.7x4.7 1 8.7 18.6 161 19620 87.3 375 13.23 74%
Graupner CAM Speed 4.7x4.7 1 8.7 18.6 161 19620 87.3 375 13.23 74%
Graupner CAM Speed 4.7x4.7 1 9.7 21.6 209 21180 94.3 438 15.45 72%
Graupner CAM Speed 4.7x4.7 1 9.7 21.6 209 21180 94.3 438 15.45 72%
Graupner CAM Speed 4.7x4.7 1 10.6 24.6 260 22590 100.5 500 17.64 70%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
Graupner CAM Speed 4.7x4.7 1 10.6 24.6 260 22590 100.5 500 17.64 70%
APC E 4.75x4.75 1 7.7 15.6 120 17490 78.7 282 9.95 75%
APC E 4.75x4.75 1 7.7 15.6 120 17490 78.7 282 9.95 75%
APC E 4.75x4.75 1 10.8 26 280 22530 101.3 467 16.47 69%
APC E 4.75x4.75 1 10.8 26 280 22530 101.3 467 16.47 69%
Maxx 5x5 1 6.6 15.85 104 15360 72.7 334 11.78 77%
Maxx 5x5 1 6.6 15.85 104 15360 72.7 334 11.78 77%
Maxx 5x5 1 7.6 18.7 142 16320 77.3 396 13.97 71%
Maxx 5x5 1 7.6 18.7 142 16320 77.3 396 13.97 71%
APC E 6x4 1 7.6 20.3 154 15840 60.0 509 17.95 69%
APC E 6x4 1 7.6 20.3 154 15840 60.0 509 17.95 69%
