Motrolfly - 2205-1800 v2

Show Similiar


Specifications

  • Type: Outrunner
  • Weight: 28.00g (0.99oz)
  • Diameter: 28.00mm (1.10in)
  • Length: 14.00mm (0.55in)
  • Shaft Diameter: 3.00mm (0.12in)
  • Maximum Amps: 15

Constants

  • kV: 2175
  • Rm: 0.245
  • Io: 0.75



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 0.55 14910
8 0.6 16830
10 0.75 20970

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
Multiplex 5x4 1 6.9 4.4 30 12210 46.2 188 6.63 81%
Multiplex 5x4 1 6.9 4.4 30 12210 46.2 188 6.63 81%
Multiplex 5x4 1 7.9 5.55 43 13710 51.9 241 8.50 80%
Multiplex 5x4 1 7.9 5.55 43 13710 51.9 241 8.50 80%
Multiplex 5x4 1 8.9 6.7 59 15150 57.4 295 10.41 78%
Multiplex 5x4 1 8.9 6.7 59 15150 57.4 295 10.41 78%
Multiplex 5x4 1 9.8 8.05 78 16680 63.2 350 12.35 78%
Multiplex 5x4 1 9.8 8.05 78 16680 63.2 350 12.35 78%
Multiplex 5x4 1 10.8 9.3 100 17940 68.0 420 14.82 76%
Multiplex 5x4 1 10.8 9.3 100 17940 68.0 420 14.82 76%
Zagi Carbon 5.1x4.9 1 6.9 5.65 38 12180 56.5 202 7.13 81%
Zagi Carbon 5.1x4.9 1 6.9 5.65 38 12180 56.5 202 7.13 81%
Zagi Carbon 5.1x4.9 1 7.8 6.85 53 13470 62.5 251 8.85 79%
Zagi Carbon 5.1x4.9 1 7.8 6.85 53 13470 62.5 251 8.85 79%
Zagi Carbon 5.1x4.9 1 8.8 8.4 73 14910 69.2 311 10.97 78%
Zagi Carbon 5.1x4.9 1 8.8 8.4 73 14910 69.2 311 10.97 78%
Zagi Carbon 5.1x4.9 1 9.8 9.5 93 15900 73.8 351 12.38 75%
Zagi Carbon 5.1x4.9 1 9.8 9.5 93 15900 73.8 351 12.38 75%
Zagi Carbon 5.1x4.9 1 10.7 10.9 116 17040 79.1 404 14.25 73%
Zagi Carbon 5.1x4.9 1 10.7 10.9 116 17040 79.1 404 14.25 73%
APC FF 5.7x3 1 6.9 5.2 35 12270 34.9 202 7.13 82%
APC FF 5.7x3 1 6.9 5.2 35 12270 34.9 202 7.13 82%
APC FF 5.7x3 1 7.8 6.4 49 13650 38.8 257 9.07 80%
APC FF 5.7x3 1 7.8 6.4 49 13650 38.8 257 9.07 80%
APC FF 5.7x3 1 8.8 7.5 66 14880 42.3 310 10.93 78%
APC FF 5.7x3 1 8.8 7.5 66 14880 42.3 310 10.93 78%
APC FF 5.7x3 1 9.8 8.8 86 16170 45.9 366 12.91 76%
APC FF 5.7x3 1 9.8 8.8 86 16170 45.9 366 12.91 76%
APC FF 5.7x3 1 10.8 10.2 110 17310 49.2 417 14.71 74%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC FF 5.7x3 1 10.8 10.2 110 17310 49.2 417 14.71 74%
APC E 6x4 1 6.9 6.75 46 11130 42.2 239 8.43 74%
APC E 6x4 1 6.9 6.75 46 11130 42.2 239 8.43 74%
APC E 6x4 1 7.8 8.2 63 12270 46.5 296 10.44 72%
APC E 6x4 1 7.8 8.2 63 12270 46.5 296 10.44 72%
APC E 6x4 1 8.8 9.6 84 13440 50.9 361 12.73 70%
APC E 6x4 1 8.8 9.6 84 13440 50.9 361 12.73 70%
APC E 6x4 1 9.8 11.35 111 14910 56.5 445 15.70 70%
APC E 6x4 1 9.8 11.35 111 14910 56.5 445 15.70 70%
APC E 6x4 1 10.7 13.1 140 15690 59.4 501 17.67 67%
APC E 6x4 1 10.7 13.1 140 15690 59.4 501 17.67 67%
APC E 7x5 1 7 11.65 81 9120 43.2 369 13.02 60%
APC E 7x5 1 7 11.65 81 9120 43.2 369 13.02 60%
APC E 7x5 1 7.4 12.6 93 9480 44.9 395 13.93 59%
APC E 7x5 1 7.4 12.6 93 9480 44.9 395 13.93 59%
GWS HD 8x4 1 7 11.6 81 9180 34.8 451 15.91 60%
GWS HD 8x4 1 7 11.6 81 9180 34.8 451 15.91 60%
GWS HD 8x4 1 7.4 12.5 92 9540 36.1 489 17.25 59%
GWS HD 8x4 1 7.4 12.5 92 9540 36.1 489 17.25 59%
