Motrolfly - 2205-1350 v2

Show Similiar


Specifications

  • Type: Outrunner
  • Weight: 28.00g (0.99oz)
  • Diameter: 28.00mm (1.10in)
  • Length: 14.00mm (0.55in)
  • Shaft Diameter: 3.00mm (0.12in)
  • Maximum Amps: 9

Constants

  • kV: 1370
  • Rm: 0.44
  • Io: 0.4



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 0.4 9330
8 0.4 10680
10 0.4 13290

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 7x3.5 1 6.9 2.35 16 8160 27.1 146 5.15 86%
GWS HD 7x3.5 1 6.9 2.35 16 8160 27.1 146 5.15 86%
GWS HD 7x3.5 1 7.9 2.85 22 9150 30.3 188 6.63 85%
GWS HD 7x3.5 1 7.9 2.85 22 9150 30.3 188 6.63 85%
GWS HD 7x3.5 1 8.9 3.5 31 10200 33.8 243 8.57 84%
GWS HD 7x3.5 1 8.9 3.5 31 10200 33.8 243 8.57 84%
GWS HD 7x3.5 1 9.9 4.1 40 11100 36.8 295 10.41 82%
GWS HD 7x3.5 1 9.9 4.1 40 11100 36.8 295 10.41 82%
GWS HD 7x3.5 1 10.9 4.7 51 11940 39.6 349 12.31 80%
GWS HD 7x3.5 1 10.9 4.7 51 11940 39.6 349 12.31 80%
APC E 7x5 1 6.9 4.45 30 7020 33.2 211 7.44 74%
APC E 7x5 1 6.9 4.45 30 7020 33.2 211 7.44 74%
APC E 7x5 1 7.9 5.35 42 7770 36.8 263 9.28 72%
APC E 7x5 1 7.9 5.35 42 7770 36.8 263 9.28 72%
APC E 7x5 1 8.8 6.15 54 8370 39.6 308 10.86 69%
APC E 7x5 1 8.8 6.15 54 8370 39.6 308 10.86 69%
APC E 7x5 1 9.8 7.15 70 9090 43.0 367 12.95 68%
APC E 7x5 1 9.8 7.15 70 9090 43.0 367 12.95 68%
APC E 7x5 1 10.8 8.2 88 9690 45.9 426 15.03 65%
APC E 7x5 1 10.8 8.2 88 9690 45.9 426 15.03 65%
APC SF 7x6 1 6.8 5 34 6690 38.0 213 7.51 72%
APC SF 7x6 1 6.8 5 34 6690 38.0 213 7.51 72%
APC SF 7x6 1 7.9 6.05 47 7380 41.9 259 9.14 68%
APC SF 7x6 1 7.9 6.05 47 7380 41.9 259 9.14 68%
APC SF 7x6 1 8.8 7.05 62 7920 45.0 301 10.62 66%
APC SF 7x6 1 8.8 7.05 62 7920 45.0 301 10.62 66%
APC SF 7x6 1 9.9 8.15 80 8430 47.9 353 12.45 62%
APC SF 7x6 1 9.9 8.15 80 8430 47.9 353 12.45 62%
APC SF 7x6 1 10.8 9.15 98 8820 50.1 382 13.47 60%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC SF 7x6 1 10.8 9.15 98 8820 50.1 382 13.47 60%
GWS RS 7x6 1 6.9 5.4 37 6510 37.0 243 8.57 69%
GWS RS 7x6 1 6.9 5.4 37 6510 37.0 243 8.57 69%
GWS RS 7x6 1 7.8 6.4 49 7110 40.4 295 10.41 67%
GWS RS 7x6 1 7.8 6.4 49 7110 40.4 295 10.41 67%
GWS RS 7x6 1 8.8 7.4 65 7650 43.5 343 12.10 63%
GWS RS 7x6 1 8.8 7.4 65 7650 43.5 343 12.10 63%
GWS RS 7x6 1 9.8 8.6 84 8040 45.7 379 13.37 60%
GWS RS 7x6 1 9.8 8.6 84 8040 45.7 379 13.37 60%
GWS RS 7x6 1 10.8 9.65 104 8400 47.7 419 14.78 57%
GWS RS 7x6 1 10.8 9.65 104 8400 47.7 419 14.78 57%
GWS HD 8x4 1 6.9 4.45 30 7080 26.8 265 9.35 75%
GWS HD 8x4 1 6.9 4.45 30 7080 26.8 265 9.35 75%
GWS HD 8x4 1 7.9 5.3 41 7770 29.4 322 11.36 72%
GWS HD 8x4 1 7.9 5.3 41 7770 29.4 322 11.36 72%
GWS HD 8x4 1 8.9 6.25 55 8460 32.0 387 13.65 69%
GWS HD 8x4 1 8.9 6.25 55 8460 32.0 387 13.65 69%
GWS HD 8x4 1 9.8 7.15 70 9090 34.4 448 15.80 68%
GWS HD 8x4 1 9.8 7.15 70 9090 34.4 448 15.80 68%
GWS HD 8x4 1 10.8 8.2 88 9660 36.6 509 17.95 65%
GWS HD 8x4 1 10.8 8.2 88 9660 36.6 509 17.95 65%
APC SF 9x4.7 1 7 6.9 48 5760 25.6 345 12.17 60%
APC SF 9x4.7 1 7 6.9 48 5760 25.6 345 12.17 60%
APC SF 9x4.7 1 7.4 7.35 54 5910 26.3 367 12.95 58%
APC SF 9x4.7 1 7.4 7.35 54 5910 26.3 367 12.95 58%
GWS HD 9x5 1 7 6.6 46 6030 28.6 352 12.42 63%
GWS HD 9x5 1 7 6.6 46 6030 28.6 352 12.42 63%
GWS HD 9x5 1 7.4 7 51 6240 29.6 376 13.26 62%
GWS HD 9x5 1 7.4 7 51 6240 29.6 376 13.26 62%
GWS HD 10x6 1 7 8 56 5220 29.7 377 13.30 54%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 10x6 1 7 8 56 5220 29.7 377 13.30 54%
GWS HD 10x6 1 7.4 8.3 61 5310 30.2 389 13.72 52%
GWS HD 10x6 1 7.4 8.3 61 5310 30.2 389 13.72 52%
