Motrolfly - 2203-2200 v2
Specifications
- Type: Outrunner
- Weight: 18.00g (0.63oz)
- Diameter: 28.00mm (1.10in)
- Length: 13.70mm (0.54in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 9
Constants
- kV: 2260
- Rm: 0.44
- Io: 0.75
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.65 | 14980 |
| 8 | 0.7 | 16950 |
| 10 | 0.75 | 21110 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 4x4 | 1 | 6.9 | 3.25 | 22 | 12600 | 47.7 | 87 | 3.07 | 81% |
| GWS HD 4x4 | 1 | 6.9 | 3.25 | 22 | 12600 | 47.7 | 87 | 3.07 | 81% |
| GWS HD 4x4 | 1 | 7.9 | 3.9 | 30 | 14100 | 53.4 | 111 | 3.92 | 79% |
| GWS HD 4x4 | 1 | 7.9 | 3.9 | 30 | 14100 | 53.4 | 111 | 3.92 | 79% |
| GWS HD 4x4 | 1 | 8.9 | 4.6 | 40 | 15570 | 59.0 | 136 | 4.80 | 77% |
| GWS HD 4x4 | 1 | 8.9 | 4.6 | 40 | 15570 | 59.0 | 136 | 4.80 | 77% |
| GWS HD 4x4 | 1 | 9.9 | 5.3 | 52 | 16980 | 64.3 | 161 | 5.68 | 76% |
| GWS HD 4x4 | 1 | 9.9 | 5.3 | 52 | 16980 | 64.3 | 161 | 5.68 | 76% |
| GWS HD 4x4 | 1 | 10.8 | 5.9 | 63 | 18090 | 68.5 | 185 | 6.53 | 74% |
| GWS HD 4x4 | 1 | 10.8 | 5.9 | 63 | 18090 | 68.5 | 185 | 6.53 | 74% |
| Gunther 4.92x4.33 | 1 | 6.9 | 5 | 34 | 10830 | 44.4 | 166 | 5.86 | 69% |
| Gunther 4.92x4.33 | 1 | 7.9 | 5.7 | 45 | 11790 | 48.3 | 198 | 6.98 | 66% |
| Gunther 4.92x4.33 | 1 | 8.9 | 6.85 | 60 | 13050 | 53.5 | 247 | 8.71 | 65% |
| Gunther 4.92x4.33 | 1 | 9.9 | 7.8 | 77 | 13980 | 57.3 | 290 | 10.23 | 62% |
| Gunther 4.92x4.33 | 1 | 10.9 | 9.1 | 99 | 14790 | 60.6 | 332 | 11.71 | 60% |
| Gunther White 4.92x4.33 | 1 | 6.9 | 5 | 34 | 10830 | 44.4 | 166 | 5.86 | 69% |
| Gunther White 4.92x4.33 | 1 | 7.9 | 5.7 | 45 | 11790 | 48.3 | 198 | 6.98 | 66% |
| Gunther White 4.92x4.33 | 1 | 8.9 | 6.85 | 60 | 13050 | 53.5 | 247 | 8.71 | 65% |
| Gunther White 4.92x4.33 | 1 | 9.9 | 7.8 | 77 | 13980 | 57.3 | 290 | 10.23 | 62% |
| Gunther White 4.92x4.33 | 1 | 10.9 | 9.1 | 99 | 14790 | 60.6 | 332 | 11.71 | 60% |
| GWS HD 5x4.3 | 1 | 6.9 | 4.3 | 29 | 11580 | 47.1 | 164 | 5.78 | 74% |
| GWS HD 5x4.3 | 1 | 6.9 | 4.3 | 29 | 11580 | 47.1 | 164 | 5.78 | 74% |
| GWS HD 5x4.3 | 1 | 7.9 | 5 | 39 | 12840 | 52.3 | 203 | 7.16 | 72% |
| GWS HD 5x4.3 | 1 | 7.9 | 5 | 39 | 12840 | 52.3 | 203 | 7.16 | 72% |
| GWS HD 5x4.3 | 1 | 8.9 | 5.75 | 51 | 14040 | 57.2 | 240 | 8.47 | 70% |
| GWS HD 5x4.3 | 1 | 8.9 | 5.75 | 51 | 14040 | 57.2 | 240 | 8.47 | 70% |
| GWS HD 5x4.3 | 1 | 9.9 | 6.6 | 65 | 15180 | 61.8 | 278 | 9.81 | 68% |
| GWS HD 5x4.3 | 1 | 9.9 | 6.6 | 65 | 15180 | 61.8 | 278 | 9.81 | 68% |
| GWS HD 5x4.3 | 1 | 10.9 | 7.4 | 80 | 16260 | 66.2 | 321 | 11.32 | 66% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 5x4.3 | 1 | 10.9 | 7.4 | 80 | 16260 | 66.2 | 321 | 11.32 | 66% |
| GWS HD 6x3 | 1 | 6.9 | 4.6 | 31 | 11280 | 32.0 | 203 | 7.16 | 72% |
| GWS HD 6x3 | 1 | 6.9 | 4.6 | 31 | 11280 | 32.0 | 203 | 7.16 | 72% |
| GWS HD 6x3 | 1 | 7.4 | 5 | 37 | 11910 | 33.8 | 230 | 8.11 | 71% |
| GWS HD 6x3 | 1 | 7.4 | 5 | 37 | 11910 | 33.8 | 230 | 8.11 | 71% |
| GWS HD 7x3.5 | 1 | 6.9 | 5.5 | 37 | 9930 | 32.9 | 236 | 8.32 | 64% |
| GWS HD 7x3.5 | 1 | 6.9 | 5.5 | 37 | 9930 | 32.9 | 236 | 8.32 | 64% |
| GWS HD 7x3.5 | 1 | 7.4 | 6.1 | 45 | 10470 | 34.7 | 264 | 9.31 | 63% |
| GWS HD 7x3.5 | 1 | 7.4 | 6.1 | 45 | 10470 | 34.7 | 264 | 9.31 | 63% |
| APC SF 7x4 | 1 | 6.9 | 7.4 | 51 | 8280 | 31.4 | 258 | 9.10 | 53% |
| APC SF 7x4 | 1 | 6.9 | 7.4 | 51 | 8280 | 31.4 | 258 | 9.10 | 53% |
| APC SF 7x4 | 1 | 7.4 | 7.6 | 56 | 8490 | 32.2 | 268 | 9.45 | 51% |
| APC SF 7x4 | 1 | 7.4 | 7.6 | 56 | 8490 | 32.2 | 268 | 9.45 | 51% |
