KEDA - TR2837/16
Specifications
- Type: Outrunner
- Weight: 81.00g (2.86oz)
- Diameter: 28.00mm (1.10in)
- Length: 37.00mm (1.46in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 20
Constants
- kV: 920
- Rm: 0.164
- Io: 0.7
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.55 | 6400 |
| 8 | 0.6 | 7290 |
| 10 | 0.7 | 9080 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 9x5 | 1 | 6.9 | 4.5 | 31 | 5700 | 27.0 | 313 | 11.04 | 90% |
| GWS HD 9x5 | 1 | 7.8 | 5.6 | 43 | 6390 | 30.3 | 395 | 13.93 | 89% |
| GWS HD 9x5 | 1 | 8.8 | 6.75 | 59 | 7050 | 33.4 | 491 | 17.32 | 87% |
| GWS HD 9x5 | 1 | 9.8 | 8 | 78 | 7740 | 36.6 | 591 | 20.85 | 86% |
| GWS HD 9x5 | 1 | 10.7 | 9.2 | 98 | 8310 | 39.4 | 687 | 24.23 | 84% |
| GWS HD 10x6 | 1 | 6.8 | 6.25 | 42 | 5400 | 30.7 | 403 | 14.22 | 86% |
| GWS HD 10x6 | 1 | 7.7 | 7.65 | 58 | 6030 | 34.3 | 507 | 17.88 | 85% |
| GWS HD 10x6 | 1 | 8.7 | 9.1 | 79 | 6630 | 37.7 | 609 | 21.48 | 83% |
| GWS HD 10x6 | 1 | 9.7 | 10.75 | 104 | 7230 | 41.1 | 725 | 25.57 | 81% |
| GWS HD 10x6 | 1 | 10.6 | 12.3 | 130 | 7770 | 44.1 | 844 | 29.77 | 80% |
| GWS HD 11x7 | 1 | 6.8 | 8.9 | 60 | 5010 | 33.2 | 544 | 19.19 | 80% |
| GWS HD 11x7 | 1 | 7.7 | 10.85 | 83 | 5520 | 36.6 | 674 | 23.77 | 78% |
| GWS HD 11x7 | 1 | 8.6 | 12.8 | 110 | 6030 | 40.0 | 803 | 28.32 | 76% |
| GWS HD 11x7 | 1 | 9.6 | 14.9 | 143 | 6510 | 43.1 | 925 | 32.63 | 74% |
| GWS HD 11x7 | 1 | 10.6 | 16.95 | 179 | 6960 | 46.1 | 1060 | 37.39 | 71% |
| GWS HD 12x6 | 1 | 6.8 | 10 | 68 | 4860 | 27.6 | 608 | 21.45 | 78% |
| GWS HD 12x6 | 1 | 7.7 | 12.1 | 93 | 5370 | 30.5 | 750 | 26.46 | 76% |
| GWS HD 12x6 | 1 | 8.7 | 14.25 | 123 | 5850 | 33.2 | 890 | 31.39 | 73% |
| GWS HD 12x6 | 1 | 9.7 | 16.4 | 159 | 6270 | 35.6 | 1015 | 35.80 | 70% |
| GWS HD 12x6 | 1 | 10.6 | 18.7 | 198 | 6690 | 38.0 | 1165 | 41.09 | 69% |
| APC E 13x4 | 1 | 6.8 | 9.7 | 65 | 4920 | 18.6 | 620 | 21.87 | 79% |
| APC E 13x4 | 1 | 7.7 | 11.85 | 91 | 5430 | 20.6 | 780 | 27.51 | 77% |
| APC E 13x4 | 1 | 8.7 | 14 | 121 | 5880 | 22.3 | 930 | 32.80 | 73% |
| APC E 13x4 | 1 | 9.7 | 16.2 | 157 | 6300 | 23.9 | 1087 | 38.34 | 71% |
| APC E 13x4 | 1 | 10.6 | 18.4 | 195 | 6720 | 25.4 | 1220 | 43.03 | 69% |
| APC E 13x6.5 | 1 | 6.8 | 12.15 | 82 | 4530 | 27.9 | 698 | 24.62 | 72% |
| APC E 13x6.5 | 1 | 7.7 | 14.7 | 113 | 4950 | 30.5 | 840 | 29.63 | 70% |
| APC E 13x6.5 | 1 | 8.7 | 17.1 | 148 | 5280 | 32.5 | 965 | 34.04 | 66% |
| APC E 13x6.5 | 1 | 9.6 | 19.5 | 187 | 5640 | 34.7 | 1130 | 39.86 | 64% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| APC E 13x6.5 | 1 | 10.6 | 21.7 | 230 | 5970 | 36.8 | 1230 | 43.39 | 61% |
