KEDA - TR2830/14

Show Similiar


Specifications

  • Type: Outrunner
  • Weight: 59.00g (2.08oz)
  • Diameter: 28.00mm (1.10in)
  • Length: 30.00mm (1.18in)
  • Shaft Diameter: 3.17mm (0.12in)
  • Maximum Amps: 30

Constants

  • kV: 1630
  • Rm: 0.126
  • Io: 1.45



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 1.15 11140
8 1.25 12640
10.5 1.45 15930

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 7x3.5 1 6.9 4.9 33 10200 33.8 240 8.47 91%
GWS HD 7x3.5 1 6.9 4.9 33 10200 33.8 240 8.47 91%
GWS HD 7x3.5 1 7.8 6 46 11460 38.0 312 11.01 90%
GWS HD 7x3.5 1 7.8 6 46 11460 38.0 312 11.01 90%
GWS HD 7x3.5 1 8.8 7.25 63 12690 42.1 396 13.97 88%
GWS HD 7x3.5 1 8.8 7.25 63 12690 42.1 396 13.97 88%
GWS HD 7x3.5 1 9.8 8.5 83 13830 45.8 479 16.90 87%
GWS HD 7x3.5 1 9.8 8.5 83 13830 45.8 479 16.90 87%
GWS HD 7x3.5 1 10.8 10.25 110 15180 50.3 586 20.67 86%
GWS HD 7x3.5 1 10.8 10.25 110 15180 50.3 586 20.67 86%
APC E 7x5 1 6.8 9.25 62 9060 42.9 366 12.91 82%
APC E 7x5 1 6.8 9.25 62 9060 42.9 366 12.91 82%
APC E 7x5 1 7.8 11.6 90 10200 48.3 470 16.58 80%
APC E 7x5 1 7.8 11.6 90 10200 48.3 470 16.58 80%
APC E 7x5 1 8.8 14.1 124 11310 53.5 580 20.46 79%
APC E 7x5 1 8.8 14.1 124 11310 53.5 580 20.46 79%
APC E 7x5 1 9.6 16.15 155 12000 56.8 665 23.46 77%
APC E 7x5 1 9.6 16.15 155 12000 56.8 665 23.46 77%
APC E 7x5 1 10.6 18.7 198 12960 61.4 776 27.37 75%
APC E 7x5 1 10.6 18.7 198 12960 61.4 776 27.37 75%
APC E 7x6 1 6.8 10.6 72 8850 50.3 375 13.23 80%
APC E 7x6 1 6.8 10.6 72 8850 50.3 375 13.23 80%
APC E 7x6 1 7.7 13.05 100 9930 56.4 493 17.39 79%
APC E 7x6 1 7.7 13.05 100 9930 56.4 493 17.39 79%
APC E 7x6 1 8.6 15.2 130 10860 61.7 587 20.71 77%
APC E 7x6 1 8.6 15.2 130 10860 61.7 587 20.71 77%
APC E 7x6 1 9.6 18 172 11790 67.0 698 24.62 75%
APC E 7x6 1 9.6 18 172 11790 67.0 698 24.62 75%
APC E 7x6 1 10.6 20.7 219 12600 71.6 800 28.22 73%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 7x6 1 10.6 20.7 219 12600 71.6 800 28.22 73%
GWS HD 8x4 1 6.8 9.05 61 9120 34.5 438 15.45 82%
GWS HD 8x4 1 6.8 9.05 61 9120 34.5 438 15.45 82%
GWS HD 8x4 1 7.8 11.45 89 10290 39.0 562 19.82 81%
GWS HD 8x4 1 7.8 11.45 89 10290 39.0 562 19.82 81%
GWS HD 8x4 1 8.8 13.7 120 11220 42.5 680 23.99 78%
GWS HD 8x4 1 8.8 13.7 120 11220 42.5 680 23.99 78%
GWS HD 8x4 1 9.8 16.1 157 12150 46.0 810 28.57 76%
GWS HD 8x4 1 9.8 16.1 157 12150 46.0 810 28.57 76%
GWS HD 8x4 1 10.7 18.6 199 13020 49.3 930 32.80 75%
GWS HD 8x4 1 10.7 18.6 199 13020 49.3 930 32.80 75%
GWS HD 9x5 1 7.3 16.4 119 8460 40.1 710 25.04 71%
GWS HD 9x5 1 7.3 16.4 119 8460 40.1 710 25.04 71%
GWS HD 9x5 1 11.4 31 353 11280 53.4 1325 46.74 61%
GWS HD 9x5 1 11.4 31 353 11280 53.4 1325 46.74 61%
GWS HD 10x6 1 7.2 20.4 146 7560 43.0 802 28.29 64%
GWS HD 10x6 1 7.2 20.4 146 7560 43.0 802 28.29 64%
