KEDA - TR2826/18
Specifications
- Type: Outrunner
- Weight: 47.00g (1.66oz)
- Diameter: 28.00mm (1.10in)
- Length: 26.00mm (1.02in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 20
Constants
- kV: 1840
- Rm: 0.16
- Io: 1.05
Io Test Data
Dr Kiwi test results
Volts | Amps | RPM |
---|---|---|
7 | 0.85 | 12780 |
8 | 0.9 | 14490 |
10 | 1.05 | 18090 |
Test Data
Dr Kiwi test results
Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
---|---|---|---|---|---|---|---|---|---|
Maxx 5x5 | 1 | 6.8 | 5.5 | 37 | 11310 | 53.5 | 180 | 6.35 | 90% |
Maxx 5x5 | 1 | 6.8 | 5.5 | 37 | 11310 | 53.5 | 180 | 6.35 | 90% |
Maxx 5x5 | 1 | 7.8 | 6.9 | 53 | 12750 | 60.4 | 231 | 8.15 | 89% |
Maxx 5x5 | 1 | 7.8 | 6.9 | 53 | 12750 | 60.4 | 231 | 8.15 | 89% |
Maxx 5x5 | 1 | 8.8 | 8.2 | 72 | 13980 | 66.2 | 280 | 9.88 | 86% |
Maxx 5x5 | 1 | 8.8 | 8.2 | 72 | 13980 | 66.2 | 280 | 9.88 | 86% |
Maxx 5x5 | 1 | 9.8 | 9.75 | 95 | 15270 | 72.3 | 340 | 11.99 | 85% |
Maxx 5x5 | 1 | 9.8 | 9.75 | 95 | 15270 | 72.3 | 340 | 11.99 | 85% |
Maxx 5x5 | 1 | 10.7 | 11.05 | 118 | 16470 | 78.0 | 392 | 13.83 | 84% |
Maxx 5x5 | 1 | 10.7 | 11.05 | 118 | 16470 | 78.0 | 392 | 13.83 | 84% |
EMP 6x4 | 1 | 6.8 | 6.9 | 46 | 10980 | 41.6 | 295 | 10.41 | 88% |
EMP 6x4 | 1 | 6.9 | 6 | 41 | 11280 | 42.7 | 260 | 9.17 | 89% |
EMP 6x4 | 1 | 7.8 | 8.5 | 66 | 12300 | 46.6 | 373 | 13.16 | 86% |
EMP 6x4 | 1 | 7.8 | 7.3 | 56 | 12570 | 47.6 | 333 | 11.75 | 88% |
EMP 6x4 | 1 | 8.8 | 8.8 | 77 | 13860 | 52.5 | 413 | 14.57 | 86% |
EMP 6x4 | 1 | 8.8 | 10.05 | 88 | 13500 | 51.1 | 450 | 15.87 | 83% |
EMP 6x4 | 1 | 9.7 | 11.7 | 113 | 14640 | 55.5 | 532 | 18.77 | 82% |
EMP 6x4 | 1 | 9.8 | 10.15 | 99 | 15060 | 57.0 | 493 | 17.39 | 84% |
EMP 6x4 | 1 | 10.7 | 11.65 | 124 | 16260 | 61.6 | 575 | 20.28 | 83% |
EMP 6x4 | 1 | 10.7 | 13.45 | 143 | 15720 | 59.5 | 615 | 21.69 | 80% |
EMP 6x5 | 1 | 6.8 | 6.9 | 46 | 10980 | 52.0 | 295 | 10.41 | 88% |
EMP 6x5 | 1 | 6.9 | 6 | 41 | 11280 | 53.4 | 260 | 9.17 | 89% |
EMP 6x5 | 1 | 7.8 | 8.5 | 66 | 12300 | 58.2 | 373 | 13.16 | 86% |
EMP 6x5 | 1 | 7.8 | 7.3 | 56 | 12570 | 59.5 | 333 | 11.75 | 88% |
EMP 6x5 | 1 | 8.8 | 8.8 | 77 | 13860 | 65.6 | 413 | 14.57 | 86% |
EMP 6x5 | 1 | 8.8 | 10.05 | 88 | 13500 | 63.9 | 450 | 15.87 | 83% |
EMP 6x5 | 1 | 9.7 | 11.7 | 113 | 14640 | 69.3 | 532 | 18.77 | 82% |
EMP 6x5 | 1 | 9.8 | 10.15 | 99 | 15060 | 71.3 | 493 | 17.39 | 84% |
EMP 6x5 | 1 | 10.7 | 13.45 | 143 | 15720 | 74.4 | 615 | 21.69 | 80% |
Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
EMP 6x5 | 1 | 10.7 | 11.65 | 124 | 16260 | 77.0 | 575 | 20.28 | 83% |
Graupner CAM Speed 6.5x6.5 | 1 | 6.8 | 10.5 | 71 | 9960 | 61.3 | 275 | 9.70 | 80% |
Graupner CAM Speed 6.5x6.5 | 1 | 6.8 | 10.5 | 71 | 9960 | 61.3 | 275 | 9.70 | 80% |
Graupner CAM Speed 6.5x6.5 | 1 | 7.7 | 12.75 | 98 | 11010 | 67.8 | 338 | 11.92 | 78% |
Graupner CAM Speed 6.5x6.5 | 1 | 7.7 | 12.75 | 98 | 11010 | 67.8 | 338 | 11.92 | 78% |
Graupner CAM Speed 6.5x6.5 | 1 | 8.7 | 15.05 | 130 | 12060 | 74.2 | 402 | 14.18 | 75% |
Graupner CAM Speed 6.5x6.5 | 1 | 8.7 | 15.05 | 130 | 12060 | 74.2 | 402 | 14.18 | 75% |
Graupner CAM Speed 6.5x6.5 | 1 | 9.6 | 17.2 | 165 | 12900 | 79.4 | 464 | 16.37 | 73% |
Graupner CAM Speed 6.5x6.5 | 1 | 9.6 | 17.2 | 165 | 12900 | 79.4 | 464 | 16.37 | 73% |
Graupner CAM Speed 6.5x6.5 | 1 | 10.6 | 19.4 | 205 | 13800 | 84.9 | 525 | 18.52 | 71% |
Graupner CAM Speed 6.5x6.5 | 1 | 10.6 | 19.4 | 205 | 13800 | 84.9 | 525 | 18.52 | 71% |
XY 7x3 | 1 | 6.8 | 9.1 | 61 | 10410 | 29.6 | 385 | 13.58 | 83% |
XY 7x3 | 1 | 6.8 | 9.1 | 61 | 10410 | 29.6 | 385 | 13.58 | 83% |
XY 7x3 | 1 | 7.8 | 11.1 | 86 | 11610 | 33.0 | 488 | 17.21 | 81% |
XY 7x3 | 1 | 7.8 | 11.1 | 86 | 11610 | 33.0 | 488 | 17.21 | 81% |
XY 7x3 | 1 | 8.7 | 12.95 | 112 | 12570 | 35.7 | 579 | 20.42 | 79% |
XY 7x3 | 1 | 8.7 | 12.95 | 112 | 12570 | 35.7 | 579 | 20.42 | 79% |
XY 7x3 | 1 | 9.7 | 15 | 145 | 13560 | 38.5 | 694 | 24.48 | 76% |
XY 7x3 | 1 | 9.7 | 15 | 145 | 13560 | 38.5 | 694 | 24.48 | 76% |
XY 7x3 | 1 | 10.6 | 17.1 | 181 | 14520 | 41.2 | 794 | 28.01 | 74% |
XY 7x3 | 1 | 10.6 | 17.1 | 181 | 14520 | 41.2 | 794 | 28.01 | 74% |
MAS GF/3 7x3 | 1 | 6.9 | 7.5 | 51 | 10920 | 31.0 | 342 | 12.06 | 86% |
MAS GF/3 7x3 | 1 | 6.9 | 7.5 | 51 | 10920 | 31.0 | 342 | 12.06 | 86% |
MAS GF/3 7x3 | 1 | 7.8 | 9.1 | 70 | 12120 | 34.4 | 430 | 15.17 | 84% |
MAS GF/3 7x3 | 1 | 7.8 | 9.1 | 70 | 12120 | 34.4 | 430 | 15.17 | 84% |
MAS GF/3 7x3 | 1 | 8.7 | 10.8 | 93 | 13230 | 37.6 | 517 | 18.24 | 83% |
MAS GF/3 7x3 | 1 | 8.7 | 10.8 | 93 | 13230 | 37.6 | 517 | 18.24 | 83% |
MAS GF/3 7x3 | 1 | 9.7 | 12.55 | 121 | 14400 | 40.9 | 617 | 21.76 | 81% |
MAS GF/3 7x3 | 1 | 9.7 | 12.55 | 121 | 14400 | 40.9 | 617 | 21.76 | 81% |
MAS GF/3 7x3 | 1 | 10.7 | 14.4 | 154 | 15450 | 43.9 | 714 | 25.19 | 78% |
Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
MAS GF/3 7x3 | 1 | 10.7 | 14.4 | 154 | 15450 | 43.9 | 714 | 25.19 | 78% |
APC E 7x5 | 1 | 6.7 | 11.55 | 77 | 9660 | 45.7 | 421 | 14.85 | 78% |
APC E 7x5 | 1 | 6.7 | 11.55 | 77 | 9660 | 45.7 | 421 | 14.85 | 78% |
APC E 7x5 | 1 | 7.7 | 14 | 107 | 10620 | 50.3 | 522 | 18.41 | 75% |
APC E 7x5 | 1 | 7.7 | 14 | 107 | 10620 | 50.3 | 522 | 18.41 | 75% |
APC E 7x5 | 1 | 8.6 | 16.5 | 141 | 11550 | 54.7 | 610 | 21.52 | 73% |
APC E 7x5 | 1 | 8.6 | 16.5 | 141 | 11550 | 54.7 | 610 | 21.52 | 73% |
APC E 7x5 | 1 | 9.7 | 19 | 184 | 12360 | 58.5 | 715 | 25.22 | 69% |
APC E 7x5 | 1 | 9.7 | 19 | 184 | 12360 | 58.5 | 715 | 25.22 | 69% |
APC E 7x5 | 1 | 10.6 | 21.5 | 227 | 13050 | 61.8 | 803 | 28.32 | 67% |
APC E 7x5 | 1 | 10.6 | 21.5 | 227 | 13050 | 61.8 | 803 | 28.32 | 67% |
GWS HD 8x4 | 1 | 6.8 | 11.6 | 78 | 9720 | 36.8 | 514 | 18.13 | 78% |
GWS HD 8x4 | 1 | 6.8 | 11.6 | 78 | 9720 | 36.8 | 514 | 18.13 | 78% |
GWS HD 8x4 | 1 | 7.7 | 14.25 | 109 | 10710 | 40.6 | 630 | 22.22 | 76% |
GWS HD 8x4 | 1 | 7.7 | 14.25 | 109 | 10710 | 40.6 | 630 | 22.22 | 76% |
GWS HD 8x4 | 1 | 8.7 | 16.75 | 145 | 11580 | 43.9 | 740 | 26.10 | 72% |
GWS HD 8x4 | 1 | 8.7 | 16.75 | 145 | 11580 | 43.9 | 740 | 26.10 | 72% |
GWS HD 8x4 | 1 | 9.6 | 19.3 | 185 | 12360 | 46.8 | 853 | 30.09 | 70% |
GWS HD 8x4 | 1 | 9.6 | 19.3 | 185 | 12360 | 46.8 | 853 | 30.09 | 70% |
GWS HD 8x4 | 1 | 10.6 | 21.8 | 231 | 13020 | 49.3 | 984 | 34.71 | 67% |
GWS HD 8x4 | 1 | 10.6 | 21.8 | 231 | 13020 | 49.3 | 984 | 34.71 | 67% |
