KEDA - TR2830/12



Specifications

  • Type: Outrunner
  • Weight: 58.00g (2.05oz)
  • Diameter: 28.00mm (1.10in)
  • Length: 30.00mm (1.18in)
  • Shaft Diameter: 3.00mm (0.12in)
  • Maximum Amps: 30

Constants

  • kV: 1945
  • Rm: 0.1
  • Io: 1.85



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 1.5 13300
8 1.6 15300
10 1.85 18940

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
EMP 4.5x4.5 1 6.9 5 34 12510 53.3 157 5.54 93%
EMP 4.5x4.5 1 6.9 5 34 12510 53.3 157 5.54 93%
EMP 4.5x4.5 1 7.9 6.05 47 14190 60.5 206 7.27 92%
EMP 4.5x4.5 1 7.9 6.05 47 14190 60.5 206 7.27 92%
EMP 4.5x4.5 1 8.9 7.1 63 15720 67.0 256 9.03 91%
EMP 4.5x4.5 1 8.9 7.1 63 15720 67.0 256 9.03 91%
EMP 4.5x4.5 1 9.8 8.35 81 17310 73.8 312 11.01 91%
EMP 4.5x4.5 1 9.8 8.35 81 17310 73.8 312 11.01 91%
EMP 4.5x4.5 1 10.8 9.6 103 18810 80.2 370 13.05 90%
EMP 4.5x4.5 1 10.8 9.6 103 18810 80.2 370 13.05 90%
EMP 4.5x4.5 1 14 14.2 198 23460 100.0 567 20.00 86%
EMP 4.5x4.5 1 14 14.2 198 23460 100.0 567 20.00 86%
Zagi Carbon 5.1x4.9 1 6.9 6.4 44 12300 57.1 211 7.44 92%
Zagi Carbon 5.1x4.9 1 6.9 6.4 44 12300 57.1 211 7.44 92%
Zagi Carbon 5.1x4.9 1 7.8 7.9 61 13770 63.9 267 9.42 91%
Zagi Carbon 5.1x4.9 1 7.8 7.9 61 13770 63.9 267 9.42 91%
Zagi Carbon 5.1x4.9 1 8.8 9.5 83 15240 70.7 326 11.50 89%
Zagi Carbon 5.1x4.9 1 8.8 9.5 83 15240 70.7 326 11.50 89%
Zagi Carbon 5.1x4.9 1 9.8 11.1 108 16740 77.7 399 14.07 88%
Zagi Carbon 5.1x4.9 1 9.8 11.1 108 16740 77.7 399 14.07 88%
Zagi Carbon 5.1x4.9 1 10.8 12.7 137 18030 83.7 462 16.30 86%
Zagi Carbon 5.1x4.9 1 10.8 12.7 137 18030 83.7 462 16.30 86%
Zagi Carbon 5.1x4.9 1 14 19 266 22260 103.3 708 24.97 82%
Zagi Carbon 5.1x4.9 1 14 19 266 22260 103.3 708 24.97 82%
EMP 6x4 1 6.8 7.55 51 11970 45.3 295 10.41 91%
EMP 6x4 1 7.8 9.4 73 13380 50.7 377 13.30 88%
EMP 6x4 1 8.8 11.4 100 14760 55.9 468 16.51 86%
EMP 6x4 1 9.8 13.05 127 16230 61.5 571 20.14 85%
EMP 6x4 1 10.7 15 160 17520 66.4 668 23.56 84%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
EMP 6x4 1 14 22.4 313 21600 81.8 1040 36.68 79%
EMP 6x5 1 6.8 7.55 51 11970 56.7 295 10.41 91%
EMP 6x5 1 7.8 9.4 73 13380 63.4 377 13.30 88%
EMP 6x5 1 8.8 11.4 100 14760 69.9 468 16.51 86%
EMP 6x5 1 9.8 13.05 127 16230 76.8 571 20.14 85%
EMP 6x5 1 10.7 15 160 17520 83.0 668 23.56 84%
EMP 6x5 1 14 22.4 313 21600 102.3 1040 36.68 79%
APC EP 7x5 1 6.8 14.3 97 10680 50.6 516 18.20 81%
APC EP 7x5 1 6.8 14.3 97 10680 50.6 516 18.20 81%
APC EP 7x5 1 7.7 17.45 134 11760 55.7 635 22.40 79%
APC EP 7x5 1 7.7 17.45 134 11760 55.7 635 22.40 79%
APC EP 7x5 1 8.5 20.1 170 12570 59.5 739 26.07 76%
APC EP 7x5 1 8.5 20.1 170 12570 59.5 739 26.07 76%
APC EP 7x5 1 10.4 26.7 277 14270 67.6 975 34.39 71%
APC EP 7x5 1 10.4 26.7 277 14270 67.6 975 34.39 71%
APC EP 7x5 1 10.5 27.1 284 14340 67.9 993 35.03 70%
APC EP 7x5 1 10.5 27.1 284 14340 67.9 993 35.03 70%
APC EP 7x5 1 10.8 29.1 314 14730 69.7 1062 37.46 70%
APC EP 7x5 1 10.8 29.1 314 14730 69.7 1062 37.46 70%
