KEDA - TR2826/22

Show Similiar


Specifications

  • Type: Outrunner
  • Weight: 48.00g (1.69oz)
  • Diameter: 28.00mm (1.10in)
  • Length: 26.00mm (1.02in)
  • Shaft Diameter: 3.17mm (0.12in)
  • Maximum Amps: 20

Constants

  • kV: 1510
  • Rm: 0.2
  • Io: 0.85



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 0.65 10470
8 0.7 11910
10 0.85 14850

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 7x5 1 6.8 7.55 51 8490 40.2 321 11.32 83%
APC E 7x5 1 6.8 7.55 51 8490 40.2 321 11.32 83%
APC E 7x5 1 7.8 9.05 70 9390 44.5 400 14.11 80%
APC E 7x5 1 7.8 9.05 70 9390 44.5 400 14.11 80%
APC E 7x5 1 8.8 10.75 94 10290 48.7 490 17.28 77%
APC E 7x5 1 8.8 10.75 94 10290 48.7 490 17.28 77%
APC E 7x5 1 9.7 12.55 121 11100 52.6 560 19.75 76%
APC E 7x5 1 9.7 12.55 121 11100 52.6 560 19.75 76%
APC E 7x5 1 10.7 14.35 153 11850 56.1 658 23.21 73%
APC E 7x5 1 10.7 14.35 153 11850 56.1 658 23.21 73%
APC E 7x6 1 6.8 8.55 58 8220 46.7 323 11.39 80%
APC E 7x6 1 6.8 8.55 58 8220 46.7 323 11.39 80%
APC E 7x6 1 7.8 10.05 78 9120 51.8 410 14.46 77%
APC E 7x6 1 7.8 10.05 78 9120 51.8 410 14.46 77%
APC E 7x6 1 8.7 11.85 103 9960 56.6 500 17.64 76%
APC E 7x6 1 8.7 11.85 103 9960 56.6 500 17.64 76%
APC E 7x6 1 9.7 13.8 133 10710 60.9 575 20.28 73%
APC E 7x6 1 9.7 13.8 133 10710 60.9 575 20.28 73%
APC E 7x6 1 10.7 15.55 166 11430 64.9 665 23.46 71%
APC E 7x6 1 10.7 15.55 166 11430 64.9 665 23.46 71%
APC Sport 7x7 1 6.8 8.2 55 8310 55.1 295 10.41 81%
APC Sport 7x7 1 6.8 8.2 55 8310 55.1 295 10.41 81%
APC Sport 7x7 1 7.8 9.85 76 9210 61.0 365 12.87 78%
APC Sport 7x7 1 7.8 9.85 76 9210 61.0 365 12.87 78%
APC Sport 7x7 1 8.7 11.5 100 10020 66.4 431 15.20 76%
APC Sport 7x7 1 8.7 11.5 100 10020 66.4 431 15.20 76%
APC Sport 7x7 1 9.7 13.4 129 10830 71.8 508 17.92 74%
APC Sport 7x7 1 9.7 13.4 129 10830 71.8 508 17.92 74%
APC Sport 7x7 1 10.7 15.1 161 11580 76.8 574 20.25 72%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC Sport 7x7 1 10.7 15.1 161 11580 76.8 574 20.25 72%
GWS HD 8x4 1 6.8 7.35 49 8520 32.3 390 13.76 83%
GWS HD 8x4 1 6.8 7.35 49 8520 32.3 390 13.76 83%
GWS HD 8x4 1 7.8 9.1 70 9480 35.9 495 17.46 80%
GWS HD 8x4 1 7.8 9.1 70 9480 35.9 495 17.46 80%
GWS HD 8x4 1 8.8 10.75 94 10320 39.1 592 20.88 78%
GWS HD 8x4 1 8.8 10.75 94 10320 39.1 592 20.88 78%
GWS HD 8x4 1 9.7 12.45 120 11130 42.2 680 23.99 76%
GWS HD 8x4 1 9.7 12.45 120 11130 42.2 680 23.99 76%
GWS HD 8x4 1 10.7 14.2 151 11850 44.9 780 27.51 73%
GWS HD 8x4 1 10.7 14.2 151 11850 44.9 780 27.51 73%
APC E 8x6 1 6.8 12.25 83 7260 41.2 399 14.07 71%
APC E 8x6 1 6.8 12.25 83 7260 41.2 399 14.07 71%
APC E 8x6 1 7.7 14.7 113 7860 44.7 470 16.58 68%
APC E 8x6 1 7.7 14.7 113 7860 44.7 470 16.58 68%
APC E 8x6 1 8.7 16.9 147 8340 47.4 535 18.87 63%
APC E 8x6 1 8.7 16.9 147 8340 47.4 535 18.87 63%
APC E 8x6 1 9.6 19.2 184 8760 49.8 592 20.88 60%
APC E 8x6 1 9.6 19.2 184 8760 49.8 592 20.88 60%
APC E 8x6 1 10.6 21.1 223 9150 52.0 650 22.93 57%
APC E 8x6 1 10.6 21.1 223 9150 52.0 650 22.93 57%
GWS HD 9x5 1 6.8 11.5 78 7470 35.4 550 19.40 73%
GWS HD 9x5 1 6.8 11.5 78 7470 35.4 550 19.40 73%
GWS HD 9x5 1 7.7 13.7 105 8160 38.6 657 23.17 70%
GWS HD 9x5 1 7.7 13.7 105 8160 38.6 657 23.17 70%
GWS HD 9x5 1 8.7 15.8 137 8730 41.3 756 26.67 66%
GWS HD 9x5 1 8.7 15.8 137 8730 41.3 756 26.67 66%
GWS HD 9x5 1 9.6 18 172 9240 43.8 849 29.95 64%
GWS HD 9x5 1 9.6 18 172 9240 43.8 849 29.95 64%
GWS HD 9x5 1 10.6 20.2 214 9660 45.7 960 33.86 60%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 9x5 1 10.6 20.2 214 9660 45.7 960 33.86 60%
