Common Sense RC - E8-S-12


Common Sense RC - E8-S-12

Specifications

  • Type: Outrunner
  • Weight: 75.00g (2.65oz)
  • Diameter: 37.25mm (1.47in)
  • Length: 26.00mm (1.02in)
  • Shaft Diameter: 4.00mm (0.16in)
  • Maximum Amps: 24

Constants

  • kV: 1340
  • Rm: 0.108
  • Io: 1.8



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 1.4 9120
8 1.5 10530
10 1.8 13140

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC Sport 7x7 1 6.9 7.7 53 8130 53.9 275 9.70 88%
APC Sport 7x7 1 7.9 9.55 75 9150 60.6 353 12.45 86%
APC Sport 7x7 1 8.8 11.7 102 10200 67.6 442 15.59 86%
APC Sport 7x7 1 9.8 13.7 134 11190 74.2 522 18.41 85%
APC Sport 7x7 1 10.8 16 172 12420 82.3 620 21.87 86%
APC Sport 7x7 1 14 25.3 354 14940 99.0 961 33.90 80%
APC E 8x6 1 6.8 12.4 84 7440 42.3 412 14.53 82%
APC E 8x6 1 7.7 15.4 118 8220 46.7 512 18.06 80%
APC E 8x6 1 8.7 18.8 163 9000 51.1 624 22.01 77%
APC E 8x6 1 9.7 22.5 218 9750 55.4 744 26.24 75%
APC E 8x6 1 11.2 29.5 330 10770 61.2 930 32.80 72%
APC E 9x4.5 1 6.8 11.3 76 7620 32.5 546 19.26 84%
APC E 9x4.5 1 7.8 14.1 109 8490 36.2 693 24.44 81%
APC E 9x4.5 1 8.7 17.5 152 9330 39.8 866 30.55 80%
APC E 9x4.5 1 9.7 20.7 200 10110 43.1 1016 35.84 78%
APC E 10x7 1 7.4 20.2 149 6990 46.3 800 28.22 70%
APC E 11x5.5 1 7.3 21.1 154 6840 35.6 919 32.42 70%
