Pulso - X 2217 5H
Specifications
- Type: Outrunner
- Weight: 72.00g (2.54oz)
- Diameter: 27.70mm (1.09in)
- Length: 35.00mm (1.38in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 34
Constants
- kV: 2800
- Rm: 0.07
- Io: 1.5
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.4 | 19530 |
| 8 | 1.45 | 22140 |
| 10 | 1.5 | 27620 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 4.1x4.1 | 1 | 6.9 | 7.7 | 53 | 18000 | 69.9 | 190 | 6.70 | 93% |
| APC E 4.1x4.1 | 1 | 6.9 | 7.7 | 53 | 18000 | 69.9 | 190 | 6.70 | 93% |
| APC E 4.1x4.1 | 1 | 7.9 | 9.7 | 76 | 20310 | 78.9 | 245 | 8.64 | 92% |
| APC E 4.1x4.1 | 1 | 7.9 | 9.7 | 76 | 20310 | 78.9 | 245 | 8.64 | 92% |
| APC E 4.1x4.1 | 1 | 8.8 | 11.5 | 101 | 22380 | 86.9 | 294 | 10.37 | 91% |
| APC E 4.1x4.1 | 1 | 8.8 | 11.5 | 101 | 22380 | 86.9 | 294 | 10.37 | 91% |
| APC E 4.1x4.1 | 1 | 9.8 | 13.8 | 135 | 24600 | 95.5 | 360 | 12.70 | 90% |
| APC E 4.1x4.1 | 1 | 9.8 | 13.8 | 135 | 24600 | 95.5 | 360 | 12.70 | 90% |
| APC E 4.1x4.1 | 1 | 10.7 | 16.1 | 172 | 26700 | 103.7 | 425 | 14.99 | 89% |
| APC E 4.1x4.1 | 1 | 10.7 | 16.1 | 172 | 26700 | 103.7 | 425 | 14.99 | 89% |
| EMP 4.5x4.5 | 1 | 6.8 | 11.3 | 76 | 17130 | 73.0 | 305 | 10.76 | 90% |
| EMP 4.5x4.5 | 1 | 6.8 | 11.3 | 76 | 17130 | 73.0 | 305 | 10.76 | 90% |
| EMP 4.5x4.5 | 1 | 7.8 | 14.1 | 109 | 19200 | 81.8 | 387 | 13.65 | 88% |
| EMP 4.5x4.5 | 1 | 7.8 | 14.1 | 109 | 19200 | 81.8 | 387 | 13.65 | 88% |
| EMP 4.5x4.5 | 1 | 8.7 | 17.25 | 150 | 21210 | 90.4 | 482 | 17.00 | 87% |
| EMP 4.5x4.5 | 1 | 8.7 | 17.25 | 150 | 21210 | 90.4 | 482 | 17.00 | 87% |
| EMP 4.5x4.5 | 1 | 9.7 | 19.7 | 191 | 23220 | 99.0 | 572 | 20.18 | 85% |
| EMP 4.5x4.5 | 1 | 9.7 | 19.7 | 191 | 23220 | 99.0 | 572 | 20.18 | 85% |
| EMP 4.5x4.5 | 1 | 10.6 | 23 | 243 | 25050 | 106.8 | 675 | 23.81 | 84% |
| EMP 4.5x4.5 | 1 | 10.6 | 23 | 243 | 25050 | 106.8 | 675 | 23.81 | 84% |
| EMP 5x5 | 1 | 7.7 | 19.3 | 148 | 17760 | 84.1 | 460 | 16.23 | 82% |
| EMP 5x5 | 1 | 7.7 | 19.3 | 148 | 17760 | 84.1 | 460 | 16.23 | 82% |
| EMP 5x5 | 1 | 11.2 | 35.4 | 396 | 23700 | 112.2 | 820 | 28.92 | 76% |
| EMP 5x5 | 1 | 11.2 | 35.4 | 396 | 23700 | 112.2 | 820 | 28.92 | 76% |
| Zagi Carbon 5.1x4.9 | 1 | 7.7 | 19.1 | 147 | 17880 | 83.0 | 480 | 16.93 | 83% |
| Zagi Carbon 5.1x4.9 | 1 | 7.7 | 19.1 | 147 | 17880 | 83.0 | 480 | 16.93 | 83% |
| Zagi Carbon 5.1x4.9 | 1 | 11.2 | 35.4 | 396 | 23820 | 110.5 | 855 | 30.16 | 76% |
| Zagi Carbon 5.1x4.9 | 1 | 11.2 | 35.4 | 396 | 23820 | 110.5 | 855 | 30.16 | 76% |
