Pulso - X 2212L/34


Pulso - X 2212L/34

Specifications

  • Type: Outrunner
  • Weight: 62.00g (2.19oz)
  • Diameter: 27.70mm (1.09in)
  • Length: 30.00mm (1.18in)
  • Shaft Diameter: 3.00mm (0.12in)
  • Maximum Amps: 11

Constants

  • kV: 670
  • Rm: 0.37
  • Io: 0.35



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 0.35 4650
8 0.35 5310
10 0.35 6630

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 9x5 1 6.9 2 13 4260 20.2 172 6.07 92%
GWS HD 9x5 1 6.9 2 13 4260 20.2 172 6.07 92%
GWS HD 9x5 1 7.9 2.45 19 4800 22.7 221 7.80 91%
GWS HD 9x5 1 7.9 2.45 19 4800 22.7 221 7.80 91%
GWS HD 9x5 1 8.9 2.9 25 5310 25.1 273 9.63 89%
GWS HD 9x5 1 8.9 2.9 25 5310 25.1 273 9.63 89%
GWS HD 9x5 1 9.9 3.45 34 5820 27.6 333 11.75 88%
GWS HD 9x5 1 9.9 3.45 34 5820 27.6 333 11.75 88%
GWS HD 9x5 1 10.9 3.95 43 6300 29.8 392 13.83 86%
GWS HD 9x5 1 10.9 3.95 43 6300 29.8 392 13.83 86%
GWS HD 9x5 1 14 5.75 80 7770 36.8 596 21.02 83%
GWS HD 9x5 1 14 5.75 80 7770 36.8 596 21.02 83%
GWS HD 10x6 1 6.9 2.75 18 4080 23.2 231 8.15 88%
GWS HD 10x6 1 6.9 2.75 18 4080 23.2 231 8.15 88%
GWS HD 10x6 1 7.9 3.35 26 4590 26.1 291 10.26 87%
GWS HD 10x6 1 7.9 3.35 26 4590 26.1 291 10.26 87%
GWS HD 10x6 1 8.9 4 35 5040 28.6 356 12.56 85%
GWS HD 10x6 1 8.9 4 35 5040 28.6 356 12.56 85%
GWS HD 10x6 1 9.9 4.7 46 5520 31.4 424 14.96 83%
GWS HD 10x6 1 9.9 4.7 46 5520 31.4 424 14.96 83%
GWS HD 10x6 1 10.9 5.4 58 5970 33.9 497 17.53 82%
GWS HD 10x6 1 10.9 5.4 58 5970 33.9 497 17.53 82%
GWS HD 10x6 1 14 7.7 107 7260 41.2 725 25.57 77%
GWS HD 10x6 1 14 7.7 107 7260 41.2 725 25.57 77%
APC E 10x7 1 6.9 4.7 32 3630 24.1 306 10.79 79%
APC E 10x7 1 6.9 4.7 32 3630 24.1 306 10.79 79%
APC E 10x7 1 7.9 5.7 45 4020 26.6 379 13.37 76%
APC E 10x7 1 7.9 5.7 45 4020 26.6 379 13.37 76%
APC E 10x7 1 8.9 6.85 60 4350 28.8 457 16.12 73%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 10x7 1 8.9 6.85 60 4350 28.8 457 16.12 73%
APC E 10x7 1 9.9 7.9 78 4680 31.0 525 18.52 71%
APC E 10x7 1 9.9 7.9 78 4680 31.0 525 18.52 71%
APC E 10x7 1 10.9 9 98 4980 33.0 601 21.20 68%
APC E 10x7 1 10.9 9 98 4980 33.0 601 21.20 68%
APC E 10x7 1 14 12.7 177 5730 38.0 822 29.00 61%
APC E 10x7 1 14 12.7 177 5730 38.0 822 29.00 61%
APC SF 11x4.7 1 6.9 4.1 28 3780 16.8 323 11.39 82%
APC SF 11x4.7 1 6.9 4.1 28 3780 16.8 323 11.39 82%
APC SF 11x4.7 1 7.9 5.05 39 4170 18.6 411 14.50 79%
APC SF 11x4.7 1 7.9 5.05 39 4170 18.6 411 14.50 79%
APC SF 11x4.7 1 8.9 6.05 53 4530 20.2 496 17.50 76%
APC SF 11x4.7 1 8.9 6.05 53 4530 20.2 496 17.50 76%
APC SF 11x4.7 1 9.9 7.15 70 4890 21.8 595 20.99 74%
APC SF 11x4.7 1 9.9 7.15 70 4890 21.8 595 20.99 74%
APC SF 11x4.7 1 10.9 8.2 89 5190 23.1 683 24.09 71%
APC SF 11x4.7 1 10.9 8.2 89 5190 23.1 683 24.09 71%
GWS HD 11x7 1 6.9 3.95 27 3780 25.1 317 11.18 82%
GWS HD 11x7 1 6.9 3.95 27 3780 25.1 317 11.18 82%
GWS HD 11x7 1 7.9 4.8 37 4230 28.0 394 13.90 80%
GWS HD 11x7 1 7.9 4.8 37 4230 28.0 394 13.90 80%
GWS HD 11x7 1 8.9 5.7 50 4620 30.6 483 17.04 77%
GWS HD 11x7 1 8.9 5.7 50 4620 30.6 483 17.04 77%
GWS HD 11x7 1 9.9 6.6 65 5040 33.4 563 19.86 76%
GWS HD 11x7 1 9.9 6.6 65 5040 33.4 563 19.86 76%
GWS HD 11x7 1 10.9 7.5 81 5400 35.8 649 22.89 74%
GWS HD 11x7 1 10.9 7.5 81 5400 35.8 649 22.89 74%
GWS HD 12x6 1 6.9 4.3 29 3690 21.0 349 12.31 80%
GWS HD 12x6 1 6.9 4.3 29 3690 21.0 349 12.31 80%
GWS HD 12x6 1 7.9 5.2 41 4110 23.4 433 15.27 78%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 12x6 1 7.9 5.2 41 4110 23.4 433 15.27 78%
GWS HD 12x6 1 8.9 6.15 54 4500 25.6 523 18.45 75%
GWS HD 12x6 1 8.9 6.15 54 4500 25.6 523 18.45 75%
GWS HD 12x6 1 9.9 7.15 70 4890 27.8 617 21.76 74%
GWS HD 12x6 1 9.9 7.15 70 4890 27.8 617 21.76 74%
GWS HD 12x6 1 10.9 8.1 88 5220 29.7 709 25.01 71%
GWS HD 12x6 1 10.9 8.1 88 5220 29.7 709 25.01 71%
