Pulso - X 2204/54
Specifications
- Type: Outrunner
- Weight: 27.00g (0.95oz)
- Diameter: 27.50mm (1.08in)
- Length: 23.70mm (0.93in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 7.5
Constants
- kV: 1375
- Rm: 0.4
- Io: 0.35
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.35 | 9635 |
| 8 | 0.3 | 10950 |
| 10 | 0.35 | 13580 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| Gunther 4.92x4.33 | 1 | 7 | 2.1 | 14 | 8580 | 35.2 | 110 | 3.88 | 89% |
| Gunther 4.92x4.33 | 1 | 7.9 | 2.6 | 20 | 9720 | 39.9 | 141 | 4.97 | 89% |
| Gunther 4.92x4.33 | 1 | 8.9 | 3.1 | 27 | 10740 | 44.0 | 173 | 6.10 | 88% |
| Gunther 4.92x4.33 | 1 | 9.9 | 3.55 | 35 | 11760 | 48.2 | 207 | 7.30 | 86% |
| Gunther 4.92x4.33 | 1 | 10.9 | 4 | 43 | 12660 | 51.9 | 241 | 8.50 | 84% |
| Gunther White 4.92x4.33 | 1 | 7 | 2.1 | 14 | 8580 | 35.2 | 110 | 3.88 | 89% |
| Gunther White 4.92x4.33 | 1 | 7.9 | 2.6 | 20 | 9720 | 39.9 | 141 | 4.97 | 89% |
| Gunther White 4.92x4.33 | 1 | 8.9 | 3.1 | 27 | 10740 | 44.0 | 173 | 6.10 | 88% |
| Gunther White 4.92x4.33 | 1 | 9.9 | 3.55 | 35 | 11760 | 48.2 | 207 | 7.30 | 86% |
| Gunther White 4.92x4.33 | 1 | 10.9 | 4 | 43 | 12660 | 51.9 | 241 | 8.50 | 84% |
| GWS HD 5x3 | 1 | 7 | 1.2 | 8 | 9030 | 25.6 | 71 | 2.50 | 94% |
| GWS HD 5x3 | 1 | 7 | 1.2 | 8 | 9030 | 25.6 | 71 | 2.50 | 94% |
| GWS HD 5x3 | 1 | 8 | 1.55 | 12 | 10380 | 29.5 | 94 | 3.32 | 94% |
| GWS HD 5x3 | 1 | 8 | 1.55 | 12 | 10380 | 29.5 | 94 | 3.32 | 94% |
| GWS HD 5x3 | 1 | 8.9 | 1.8 | 16 | 11460 | 32.6 | 115 | 4.06 | 94% |
| GWS HD 5x3 | 1 | 8.9 | 1.8 | 16 | 11460 | 32.6 | 115 | 4.06 | 94% |
| GWS HD 5x3 | 1 | 9.9 | 2.1 | 20 | 12570 | 35.7 | 140 | 4.94 | 92% |
| GWS HD 5x3 | 1 | 9.9 | 2.1 | 20 | 12570 | 35.7 | 140 | 4.94 | 92% |
| GWS HD 5x3 | 1 | 10.9 | 2.4 | 26 | 13650 | 38.8 | 161 | 5.68 | 91% |
| GWS HD 5x3 | 1 | 10.9 | 2.4 | 26 | 13650 | 38.8 | 161 | 5.68 | 91% |
| GWS HD 6x3 | 1 | 7 | 1.8 | 12 | 8700 | 24.7 | 118 | 4.16 | 90% |
| GWS HD 6x3 | 1 | 7 | 1.8 | 12 | 8700 | 24.7 | 118 | 4.16 | 90% |
| GWS HD 6x3 | 1 | 8 | 2.3 | 18 | 9900 | 28.1 | 157 | 5.54 | 90% |
| GWS HD 6x3 | 1 | 8 | 2.3 | 18 | 9900 | 28.1 | 157 | 5.54 | 90% |
| GWS HD 6x3 | 1 | 8.9 | 2.75 | 24 | 10920 | 31.0 | 193 | 6.81 | 89% |
| GWS HD 6x3 | 1 | 8.9 | 2.75 | 24 | 10920 | 31.0 | 193 | 6.81 | 89% |
| GWS HD 6x3 | 1 | 9.9 | 3.2 | 31 | 11940 | 33.9 | 231 | 8.15 | 88% |
| GWS HD 6x3 | 1 | 9.9 | 3.2 | 31 | 11940 | 33.9 | 231 | 8.15 | 88% |
| GWS HD 6x3 | 1 | 10.9 | 3.7 | 40 | 12900 | 36.6 | 275 | 9.70 | 86% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 6x3 | 1 | 10.9 | 3.7 | 40 | 12900 | 36.6 | 275 | 9.70 | 86% |
| GWS HD 7x3.5 | 1 | 6.9 | 2.45 | 16 | 8310 | 27.5 | 151 | 5.33 | 88% |
| GWS HD 7x3.5 | 1 | 6.9 | 2.45 | 16 | 8310 | 27.5 | 151 | 5.33 | 88% |
| GWS HD 7x3.5 | 1 | 8 | 3.1 | 24 | 9450 | 31.3 | 200 | 7.05 | 86% |
| GWS HD 7x3.5 | 1 | 8 | 3.1 | 24 | 9450 | 31.3 | 200 | 7.05 | 86% |
| GWS HD 7x3.5 | 1 | 9 | 3.7 | 33 | 10410 | 34.5 | 245 | 8.64 | 84% |
| GWS HD 7x3.5 | 1 | 9 | 3.7 | 33 | 10410 | 34.5 | 245 | 8.64 | 84% |
| GWS HD 7x3.5 | 1 | 9.9 | 4.3 | 42 | 11250 | 37.3 | 289 | 10.19 | 83% |
| GWS HD 7x3.5 | 1 | 9.9 | 4.3 | 42 | 11250 | 37.3 | 289 | 10.19 | 83% |
| GWS HD 7x3.5 | 1 | 10.9 | 5 | 54 | 12150 | 40.3 | 340 | 11.99 | 81% |
| GWS HD 7x3.5 | 1 | 10.9 | 5 | 54 | 12150 | 40.3 | 340 | 11.99 | 81% |
| APC SF 7x4 | 1 | 6.9 | 3.95 | 27 | 7500 | 28.4 | 225 | 7.94 | 79% |
| APC SF 7x4 | 1 | 6.9 | 3.95 | 27 | 7500 | 28.4 | 225 | 7.94 | 79% |
| APC SF 7x4 | 1 | 7.9 | 4.8 | 37 | 8310 | 31.5 | 278 | 9.81 | 77% |
| APC SF 7x4 | 1 | 7.9 | 4.8 | 37 | 8310 | 31.5 | 278 | 9.81 | 77% |
| APC SF 7x4 | 1 | 8.9 | 5.7 | 50 | 9060 | 34.3 | 336 | 11.85 | 74% |
| APC SF 7x4 | 1 | 8.9 | 5.7 | 50 | 9060 | 34.3 | 336 | 11.85 | 74% |
| APC SF 7x4 | 1 | 9.9 | 6.9 | 68 | 9780 | 37.0 | 402 | 14.18 | 72% |
| APC SF 7x4 | 1 | 9.9 | 6.9 | 68 | 9780 | 37.0 | 402 | 14.18 | 72% |
| APC SF 7x4 | 1 | 10.9 | 7.9 | 86 | 10380 | 39.3 | 460 | 16.23 | 69% |
| APC SF 7x4 | 1 | 10.9 | 7.9 | 86 | 10380 | 39.3 | 460 | 16.23 | 69% |
| GWS RS 8x4.3 | 1 | 7 | 5.75 | 40 | 6810 | 27.7 | 315 | 11.11 | 71% |
| GWS RS 8x4.3 | 1 | 7 | 5.75 | 40 | 6810 | 27.7 | 315 | 11.11 | 71% |
| GWS RS 8x4.3 | 1 | 7.4 | 6.1 | 45 | 7020 | 28.6 | 340 | 11.99 | 69% |
| GWS RS 8x4.3 | 1 | 7.4 | 6.1 | 45 | 7020 | 28.6 | 340 | 11.99 | 69% |
| GWS RS 8x4.3 | 1 | 7.9 | 6.65 | 52 | 7320 | 29.8 | 370 | 13.05 | 67% |
| GWS RS 8x4.3 | 1 | 7.9 | 6.65 | 52 | 7320 | 29.8 | 370 | 13.05 | 67% |
| GWS RS 8x4.3 | 1 | 8.9 | 7.7 | 68 | 7920 | 32.2 | 434 | 15.31 | 65% |
| GWS RS 8x4.3 | 1 | 8.9 | 7.7 | 68 | 7920 | 32.2 | 434 | 15.31 | 65% |
| GWS RS 8x4.3 | 1 | 9.9 | 8.8 | 87 | 8490 | 34.6 | 497 | 17.53 | 62% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS RS 8x4.3 | 1 | 9.9 | 8.8 | 87 | 8490 | 34.6 | 497 | 17.53 | 62% |
| GWS RS 8x4.3 | 1 | 10.9 | 9.7 | 105 | 8920 | 36.3 | 546 | 19.26 | 60% |
| GWS RS 8x4.3 | 1 | 10.9 | 9.7 | 105 | 8920 | 36.3 | 546 | 19.26 | 60% |
