Suppo - A2208-12
Specifications
- Type: Outrunner
- Weight: 39.00g (1.38oz)
- Diameter: 27.60mm (1.09in)
- Length: 22.25mm (0.88in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 16
Constants
- kV: 1825
- Rm: 0.21
- Io: 1.05
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.95 | 12400 |
| 8 | 1 | 14150 |
| 10 | 1.05 | 17700 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 5.25x6.25 | 1 | 6.9 | 6.8 | 46 | 10380 | 61.4 | 155 | 5.47 | 82% |
| APC E 5.25x6.25 | 1 | 7.8 | 8.1 | 63 | 11490 | 68.0 | 190 | 6.70 | 81% |
| APC E 5.25x6.25 | 1 | 8.8 | 9.55 | 84 | 12570 | 74.4 | 230 | 8.11 | 78% |
| APC E 5.25x6.25 | 1 | 9.8 | 11.05 | 108 | 13650 | 80.8 | 271 | 9.56 | 76% |
| APC E 5.25x6.25 | 1 | 10.8 | 12.6 | 136 | 14640 | 86.7 | 311 | 10.97 | 74% |
| APC E 6x4 | 1 | 6.9 | 5.9 | 40 | 10650 | 40.3 | 227 | 8.01 | 85% |
| APC E 6x4 | 1 | 7.9 | 7.05 | 55 | 11850 | 44.9 | 285 | 10.05 | 82% |
| APC E 6x4 | 1 | 8.8 | 8.25 | 72 | 13020 | 49.3 | 347 | 12.24 | 81% |
| APC E 6x4 | 1 | 9.8 | 9.6 | 94 | 14160 | 53.6 | 417 | 14.71 | 79% |
| APC E 6x4 | 1 | 10.8 | 10.95 | 118 | 15240 | 57.7 | 486 | 17.14 | 77% |
| APC Sport 6x4 | 1 | 6.9 | 6.25 | 43 | 10530 | 39.9 | 233 | 8.22 | 84% |
| APC Sport 6x4 | 1 | 7.8 | 7.4 | 57 | 11730 | 44.4 | 290 | 10.23 | 82% |
| APC Sport 6x4 | 1 | 8.8 | 8.75 | 77 | 12900 | 48.9 | 358 | 12.63 | 80% |
| APC Sport 6x4 | 1 | 9.8 | 10.05 | 98 | 14040 | 53.2 | 425 | 14.99 | 79% |
| APC Sport 6x4 | 1 | 10.8 | 11.5 | 124 | 15150 | 57.4 | 500 | 17.64 | 77% |
| Graupner CAM Speed 6x6 | 1 | 6.9 | 7.85 | 54 | 10020 | 56.9 | 216 | 7.62 | 80% |
| Graupner CAM Speed 6x6 | 1 | 7.8 | 9.3 | 72 | 11070 | 62.9 | 268 | 9.45 | 78% |
| Graupner CAM Speed 6x6 | 1 | 8.8 | 10.85 | 95 | 12120 | 68.9 | 326 | 11.50 | 75% |
| Graupner CAM Speed 6x6 | 1 | 9.8 | 12.4 | 121 | 13140 | 74.7 | 382 | 13.47 | 73% |
| Graupner CAM Speed 6x6 | 1 | 10.8 | 14.1 | 152 | 14040 | 79.8 | 441 | 15.56 | 71% |
| Graupner Speed 6.5x6.5 | 1 | 6.8 | 9.45 | 64 | 9450 | 58.2 | 252 | 8.89 | 76% |
| Graupner Speed 6.5x6.5 | 1 | 7.8 | 11.25 | 87 | 10410 | 64.1 | 305 | 10.76 | 73% |
| Graupner Speed 6.5x6.5 | 1 | 8.8 | 13.1 | 115 | 11280 | 69.4 | 360 | 12.70 | 70% |
| Graupner Speed 6.5x6.5 | 1 | 9.8 | 15.15 | 148 | 12150 | 74.8 | 420 | 14.82 | 68% |
| Graupner Speed 6.5x6.5 | 1 | 10.7 | 16.8 | 179 | 12780 | 78.7 | 464 | 16.37 | 65% |
| GWS HD 7x3.5 | 1 | 6.9 | 5.45 | 37 | 10830 | 35.9 | 267 | 9.42 | 86% |
| GWS HD 7x3.5 | 1 | 7.9 | 6.6 | 52 | 12060 | 40.0 | 342 | 12.06 | 84% |
| GWS HD 7x3.5 | 1 | 8.9 | 7.9 | 70 | 13260 | 44.0 | 424 | 14.96 | 82% |
| GWS HD 7x3.5 | 1 | 9.9 | 9.15 | 90 | 14400 | 47.7 | 503 | 17.74 | 80% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 7x3.5 | 1 | 10.8 | 10.5 | 113 | 15420 | 51.1 | 588 | 20.74 | 78% |
| Graupner SF 7x4 | 1 | 6.8 | 10.45 | 71 | 9090 | 34.4 | 424 | 14.96 | 73% |
| Graupner SF 7x4 | 1 | 7.8 | 12.4 | 96 | 9990 | 37.8 | 517 | 18.24 | 70% |
| Graupner SF 7x4 | 1 | 8.8 | 14.25 | 125 | 10830 | 41.0 | 607 | 21.41 | 67% |
| Graupner SF 7x4 | 1 | 9.8 | 16.35 | 160 | 11670 | 44.2 | 701 | 24.73 | 65% |
| Graupner SF 7x4 | 1 | 10.7 | 18.25 | 195 | 12330 | 46.7 | 787 | 27.76 | 63% |
| APC Sport 7x4 | 1 | 6.8 | 8.7 | 59 | 9690 | 36.7 | 357 | 12.59 | 78% |
| APC Sport 7x4 | 1 | 7.8 | 10.45 | 81 | 10710 | 40.6 | 445 | 15.70 | 75% |
| APC Sport 7x4 | 1 | 8.8 | 12.1 | 106 | 11670 | 44.2 | 535 | 18.87 | 73% |
| APC Sport 7x4 | 1 | 9.8 | 13.9 | 136 | 12570 | 47.6 | 623 | 21.98 | 70% |
| APC Sport 7x4 | 1 | 10.7 | 15.7 | 167 | 13410 | 50.8 | 715 | 25.22 | 69% |
| APC E 7x5 | 1 | 6.9 | 10.5 | 72 | 9180 | 43.5 | 387 | 13.65 | 73% |
| APC E 7x5 | 1 | 7.8 | 12.5 | 97 | 10020 | 47.4 | 472 | 16.65 | 70% |
| APC E 7x5 | 1 | 8.8 | 14.5 | 127 | 10830 | 51.3 | 560 | 19.75 | 67% |
| APC E 7x5 | 1 | 9.8 | 16.7 | 163 | 11580 | 54.8 | 645 | 22.75 | 65% |
| APC E 7x5 | 1 | 10.7 | 18.7 | 200 | 12120 | 57.4 | 725 | 25.57 | 62% |
| GWS HD 8x4 | 1 | 7 | 10.4 | 72 | 9450 | 35.8 | 476 | 16.79 | 74% |
