Dynam - A22-20L V2
Specifications
- Type: Outrunner
- Weight: 89.00g (3.14oz)
- Diameter: 28.10mm (1.11in)
- Length: 40.00mm (1.57in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 20
Constants
- kV: 940
- Rm: 0.2
- Io: 0.65
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.55 | 6510 |
| 8 | 0.6 | 7430 |
| 10 | 0.65 | 9260 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 8x4 | 1 | 7 | 2.8 | 19 | 6120 | 23.2 | 198 | 6.98 | 93% |
| GWS HD 8x4 | 1 | 7.9 | 3.5 | 27 | 6870 | 26.0 | 254 | 8.96 | 93% |
| GWS HD 8x4 | 1 | 8.9 | 4.2 | 37 | 7590 | 28.8 | 307 | 10.83 | 91% |
| GWS HD 8x4 | 1 | 9.9 | 5.05 | 49 | 8370 | 31.7 | 381 | 13.44 | 90% |
| GWS HD 8x4 | 1 | 10.9 | 5.75 | 62 | 9030 | 34.2 | 447 | 15.77 | 88% |
| GWS HD 9x5 | 1 | 6.9 | 4.7 | 32 | 5760 | 27.3 | 319 | 11.25 | 89% |
| GWS HD 9x5 | 1 | 7.9 | 5.85 | 46 | 6420 | 30.4 | 407 | 14.36 | 86% |
| GWS HD 9x5 | 1 | 8.9 | 7 | 62 | 7080 | 33.5 | 494 | 17.43 | 85% |
| GWS HD 9x5 | 1 | 9.9 | 8.2 | 81 | 7680 | 36.4 | 589 | 20.78 | 83% |
| GWS HD 9x5 | 1 | 10.8 | 9.45 | 102 | 8310 | 39.4 | 685 | 24.16 | 82% |
| GWS HD 10x6 | 1 | 6.9 | 6.5 | 44 | 5430 | 30.9 | 405 | 14.29 | 84% |
| GWS HD 10x6 | 1 | 7.8 | 7.85 | 61 | 6030 | 34.3 | 506 | 17.85 | 82% |
| GWS HD 10x6 | 1 | 8.8 | 9.356 | 82 | 6630 | 37.7 | 609 | 21.48 | 80% |
| GWS HD 10x6 | 1 | 9.8 | 10.9 | 106 | 7200 | 40.9 | 722 | 25.47 | 78% |
| GWS HD 10x6 | 1 | 10.7 | 12.55 | 134 | 7710 | 43.8 | 837 | 29.52 | 77% |
| GWS HD 11x7 | 1 | 6.8 | 9 | 61 | 4950 | 32.8 | 536 | 18.91 | 77% |
| GWS HD 11x7 | 1 | 7.8 | 10.9 | 85 | 5460 | 36.2 | 663 | 23.39 | 74% |
| GWS HD 11x7 | 1 | 8.8 | 12.8 | 112 | 5970 | 39.6 | 780 | 27.51 | 72% |
| GWS HD 11x7 | 1 | 9.8 | 14.9 | 146 | 6450 | 42.8 | 920 | 32.45 | 70% |
| GWS HD 11x7 | 1 | 10.7 | 16.7 | 178 | 6870 | 45.5 | 1030 | 36.33 | 68% |
| GWS HD 12x6 | 1 | 6.9 | 9.85 | 67 | 4830 | 27.4 | 593 | 20.92 | 74% |
| GWS HD 12x6 | 1 | 7.8 | 11.75 | 91 | 5340 | 30.3 | 723 | 25.50 | 73% |
| GWS HD 12x6 | 1 | 8.8 | 13.85 | 121 | 5790 | 32.9 | 845 | 29.81 | 70% |
| GWS HD 12x6 | 1 | 9.7 | 15.9 | 154 | 6210 | 35.3 | 970 | 34.22 | 68% |
| GWS HD 12x6 | 1 | 10.7 | 18 | 192 | 6600 | 37.5 | 1109 | 39.12 | 66% |
