E-flite - 400



Specifications

  • Type: Outrunner
  • Weight: 57.00g (2.01oz)
  • Maximum Amps: 13

Constants

  • kV: 890
  • Rm: 0.28
  • Io: 0.65



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 0.55 6165
8 0.6 7020
10 0.65 8750

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 8x4 1 6.9 2.3 15 5700 21.6 160 5.64 93%
GWS HD 8x4 1 7.9 2.85 22 6480 24.6 208 7.34 92%
GWS HD 8x4 1 9 3.4 30 7230 27.4 260 9.17 90%
GWS HD 8x4 1 9.9 4 39 7920 30.0 315 11.11 90%
GWS HD 8x4 1 11 4.6 50 8640 32.7 384 13.55 88%
GWS HD 9x5 1 6.9 3.9 26 5340 25.3 270 9.52 87%
GWS HD 9x5 1 7.9 4.8 37 6030 28.6 348 12.28 86%
GWS HD 9x5 1 8.9 5.65 50 6630 31.4 425 14.99 84%
GWS HD 9x5 1 9.9 6.75 66 7230 34.2 511 18.02 82%
GWS HD 9x5 1 10.9 7.7 83 7770 36.8 592 20.88 80%
GWS RS 9x7 1 6.9 6.4 44 4770 31.6 324 11.43 78%
GWS RS 9x7 1 7.9 7.85 62 5280 35.0 400 14.11 75%
GWS RS 9x7 1 8.8 9.15 80 5700 37.8 472 16.65 73%
GWS RS 9x7 1 9.8 10.75 105 6150 40.8 550 19.40 71%
GWS RS 9x7 1 10.8 12.3 132 6480 43.0 608 21.45 67%
GWS HD 10x6 1 6.9 5.25 36 5070 28.8 349 12.31 83%
GWS HD 10x6 1 7.9 6.35 50 5610 31.9 433 15.27 80%
GWS HD 10x6 1 8.9 7.55 67 6150 34.9 523 18.45 78%
GWS HD 10x6 1 9.8 8.75 85 6660 37.8 614 21.66 76%
GWS HD 10x6 1 10.8 10 108 7110 40.4 699 24.66 74%
GWS HD 3T 10x6 1 6.9 6.5 44 4740 26.9 391 13.79 77%
GWS HD 3T 10x6 1 7.9 7.8 61 5240 29.8 488 17.21 75%
GWS HD 3T 10x6 1 8.8 9.2 80 5720 32.5 579 20.42 73%
GWS HD 3T 10x6 1 9.8 10.65 104 6160 35.0 687 24.23 71%
GWS HD 3T 10x6 1 10.8 12 129 6560 37.3 780 27.51 68%
GWS RS 11x4.7 1 7 7.9 55 4470 19.9 471 16.61 72%
GWS RS 11x4.7 1 7.4 8.65 64 4680 20.8 522 18.41 71%
