KEDA - TR2830/22
Specifications
- Type: Outrunner
- Weight: 58.00g (2.05oz)
- Diameter: 28.00mm (1.10in)
- Length: 30.00mm (1.18in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 15
Constants
- kV: 1025
- Rm: 0.24
- Io: 0.65
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.55 | 7000 |
| 8 | 0.55 | 7995 |
| 10 | 0.65 | 10100 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 7x3.5 | 1 | 7 | 1.6 | 11 | 6780 | 22.5 | 95 | 3.35 | 94% |
| GWS HD 7x3.5 | 1 | 7.9 | 1.9 | 15 | 7620 | 25.3 | 127 | 4.48 | 94% |
| GWS HD 7x3.5 | 1 | 8.9 | 2.3 | 20 | 8520 | 28.2 | 165 | 5.82 | 93% |
| GWS HD 7x3.5 | 1 | 9.9 | 2.8 | 27 | 9540 | 31.6 | 210 | 7.41 | 94% |
| GWS HD 7x3.5 | 1 | 10.9 | 3.25 | 35 | 10380 | 34.4 | 258 | 9.10 | 93% |
| GWS HD 8x4 | 1 | 6.9 | 3.1 | 21 | 6420 | 24.3 | 214 | 7.55 | 91% |
| GWS HD 8x4 | 1 | 7.9 | 3.8 | 30 | 7230 | 27.4 | 274 | 9.67 | 89% |
| GWS HD 8x4 | 1 | 8.9 | 4.5 | 40 | 7950 | 30.1 | 333 | 11.75 | 87% |
| GWS HD 8x4 | 1 | 9.9 | 5.3 | 52 | 8730 | 33.1 | 403 | 14.22 | 86% |
| GWS HD 8x4 | 1 | 10.9 | 6.35 | 69 | 9630 | 36.5 | 488 | 17.21 | 86% |
| GWS HD 9x5 | 1 | 6.9 | 5.2 | 35 | 5910 | 28.0 | 341 | 12.03 | 84% |
| GWS HD 9x5 | 1 | 7.9 | 6.35 | 50 | 6600 | 31.2 | 427 | 15.06 | 82% |
| GWS HD 9x5 | 1 | 8.8 | 7.5 | 66 | 7230 | 34.2 | 515 | 18.17 | 80% |
| GWS HD 9x5 | 1 | 9.8 | 8.85 | 86 | 7860 | 37.2 | 610 | 21.52 | 78% |
| GWS HD 9x5 | 1 | 10.8 | 10.2 | 110 | 8460 | 40.1 | 711 | 25.08 | 76% |
| GWS HD 10x6 | 1 | 6.8 | 6.95 | 47 | 5520 | 31.4 | 420 | 14.82 | 79% |
| GWS HD 10x6 | 1 | 7.8 | 8.4 | 65 | 6120 | 34.8 | 516 | 18.20 | 77% |
| GWS HD 10x6 | 1 | 8.8 | 9.9 | 87 | 6660 | 37.8 | 619 | 21.83 | 74% |
| GWS HD 10x6 | 1 | 9.7 | 11.5 | 111 | 7200 | 40.9 | 725 | 25.57 | 72% |
| GWS HD 10x6 | 1 | 10.7 | 13 | 139 | 7650 | 43.5 | 827 | 29.17 | 70% |
| APC E 11x5.5 | 1 | 6.8 | 8.35 | 56 | 5220 | 27.2 | 494 | 17.43 | 75% |
| APC E 11x5.5 | 1 | 7.8 | 10.2 | 79 | 5760 | 30.0 | 612 | 21.59 | 72% |
| APC E 11x5.5 | 1 | 8.7 | 11.95 | 103 | 6210 | 32.3 | 716 | 25.26 | 70% |
| APC E 11x5.5 | 1 | 9.7 | 13.65 | 132 | 6630 | 34.5 | 820 | 28.92 | 67% |
| APC E 11x5.5 | 1 | 10.6 | 15.3 | 162 | 7020 | 36.6 | 913 | 32.21 | 65% |
| GWS HD 11x7 | 1 | 6.8 | 9.4 | 63 | 4950 | 32.8 | 529 | 18.66 | 71% |
| GWS HD 11x7 | 1 | 7.7 | 11.3 | 87 | 5400 | 35.8 | 643 | 22.68 | 68% |
| GWS HD 11x7 | 1 | 8.7 | 13 | 113 | 5880 | 39.0 | 744 | 26.24 | 66% |
| GWS HD 11x7 | 1 | 9.7 | 14.9 | 144 | 6270 | 41.6 | 858 | 30.27 | 63% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 11x7 | 1 | 10.6 | 16.7 | 177 | 6600 | 43.8 | 963 | 33.97 | 61% |
