Neu - Neutrino 1210/8Y
Specifications
- Type: Outrunner
- Weight: 16.00g (0.56oz)
- Diameter: 31.00mm (1.22in)
- Length: 9.00mm (0.35in)
- Shaft Diameter: 2.00mm (0.08in)
- Maximum Amps: 8
Constants
- kV: 2015
- Rm: 0.4
- Io: 0.6
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.45 | 13736 |
| 7.4 | 0.5 | 14498 |
| 8 | 0.6 | 15592 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 4x4 | 1 | 7 | 2.65 | 18 | 11910 | 45.1 | 79 | 2.79 | 84% |
| GWS HD 4x4 | 1 | 7.4 | 2.9 | 21 | 12480 | 47.3 | 87 | 3.07 | 84% |
| GWS HD 4x4 | 1 | 8 | 3.3 | 26 | 13410 | 50.8 | 100 | 3.53 | 83% |
| GWS HD 4.5x3 | 1 | 7 | 2.4 | 16 | 12090 | 34.4 | 99 | 3.49 | 86% |
| GWS HD 4.5x3 | 1 | 7.4 | 2.65 | 19 | 12720 | 36.1 | 110 | 3.88 | 85% |
| GWS HD 4.5x3 | 1 | 8 | 3 | 24 | 13590 | 38.6 | 126 | 4.44 | 84% |
| Gunther 4.92x4.33 | 1 | 7 | 4.45 | 31 | 10650 | 43.7 | 163 | 5.75 | 76% |
| Gunther 4.92x4.33 | 1 | 7.4 | 4.8 | 35 | 11100 | 45.5 | 177 | 6.24 | 74% |
| Gunther 4.92x4.33 | 1 | 8 | 5.3 | 42 | 11730 | 48.1 | 199 | 7.02 | 73% |
| GWS HD 5x3 | 1 | 7 | 2.95 | 20 | 11850 | 33.7 | 116 | 4.09 | 84% |
| GWS HD 5x3 | 1 | 7.4 | 3.15 | 23 | 12390 | 35.2 | 126 | 4.44 | 83% |
| GWS HD 5x3 | 1 | 8 | 3.45 | 27 | 13200 | 37.5 | 146 | 5.15 | 82% |
| GWS HD 5x4.3 | 1 | 7 | 4.1 | 28 | 10830 | 44.1 | 148 | 5.22 | 77% |
| GWS HD 5x4.3 | 1 | 7.4 | 4.4 | 32 | 11310 | 46.0 | 161 | 5.68 | 76% |
| GWS HD 5x4.3 | 1 | 8 | 5 | 40 | 12090 | 49.2 | 184 | 6.49 | 75% |
| Zagi Carbon 5.1x4.9 | 1 | 7 | 4.65 | 32 | 10410 | 48.3 | 148 | 5.22 | 74% |
| Zagi Carbon 5.1x4.9 | 1 | 7.4 | 5.05 | 37 | 10920 | 50.7 | 164 | 5.78 | 73% |
| Zagi Carbon 5.1x4.9 | 1 | 8 | 5.65 | 45 | 11550 | 53.6 | 185 | 6.53 | 72% |
| APC FF 5.7x3 | 1 | 7 | 4.1 | 28 | 10860 | 30.9 | 148 | 5.22 | 77% |
| APC FF 5.7x3 | 1 | 7.4 | 4.4 | 32 | 11280 | 32.0 | 160 | 5.64 | 76% |
| APC FF 5.7x3 | 1 | 8 | 4.95 | 39 | 12000 | 34.1 | 186 | 6.56 | 74% |
| GWS HD 6x3 | 1 | 7 | 4 | 28 | 10950 | 31.1 | 188 | 6.63 | 78% |
| GWS HD 6x3 | 1 | 7.4 | 4.35 | 32 | 11370 | 32.3 | 205 | 7.23 | 76% |
| GWS HD 6x3 | 1 | 8 | 4.9 | 39 | 12060 | 34.3 | 231 | 8.15 | 75% |
| GWS HD 6x3 | 1 | 10.8 | 8 | 86 | 14820 | 42.1 | 363 | 12.80 | 68% |
| GWS HD 6x3 | 1 | 10.8 | 8.15 | 88 | 14820 | 42.1 | 365 | 12.87 | 68% |
| APC E 6x4 | 1 | 7 | 5.5 | 38 | 9900 | 37.5 | 176 | 6.21 | 70% |
| APC E 6x4 | 1 | 7.4 | 5.9 | 43 | 10290 | 39.0 | 191 | 6.74 | 69% |
| APC E 6x4 | 1 | 8 | 6.6 | 52 | 10830 | 41.0 | 214 | 7.55 | 67% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 7x3.5 | 1 | 7 | 5.2 | 36 | 10080 | 33.4 | 218 | 7.69 | 71% |
| GWS HD 7x3.5 | 1 | 7.4 | 5.6 | 41 | 10440 | 34.6 | 234 | 8.25 | 70% |
| GWS HD 7x3.5 | 1 | 8 | 6.3 | 50 | 11010 | 36.5 | 264 | 9.31 | 68% |
| APC SF 7x4 | 1 | 7 | 7.3 | 51 | 8490 | 32.2 | 280 | 9.88 | 60% |
| APC SF 7x4 | 1 | 7.4 | 7.8 | 57 | 8700 | 33.0 | 299 | 10.55 | 58% |
| APC SF 7x4 | 1 | 8 | 8.55 | 68 | 9000 | 34.1 | 318 | 11.22 | 56% |
| GWS HD 8x4 | 1 | 7 | 8.3 | 58 | 7680 | 29.1 | 299 | 10.55 | 54% |
| GWS HD 8x4 | 1 | 7.4 | 8.6 | 63 | 7770 | 29.4 | 317 | 11.18 | 52% |
| GWS HD 8x4 | 1 | 8 | 9.5 | 76 | 8100 | 30.7 | 342 | 12.06 | 50% |
Comments
Dr Kiwi on 2010-12-22 14:32:22
This is a 24-arm, 26-magnet motor, with a built-in propsaver (no exposed shaft).
