Turnigy - C3530-1100
Specifications
- Type: Outrunner
- Weight: 73.00g (2.57oz)
- Maximum Amps: 20
Constants
- kV: 1075
- Rm: 0.185
- Io: 1.15
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.9 | 7330 |
| 8 | 1 | 8370 |
| 10 | 1.15 | 10587 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 8x4 | 1 | 6.9 | 3.9 | 26 | 6780 | 25.7 | 236 | 8.32 | 91% |
| GWS HD 8x4 | 1 | 7.9 | 4.7 | 37 | 7620 | 28.9 | 300 | 10.58 | 90% |
| GWS HD 8x4 | 1 | 8.9 | 5.65 | 50 | 8430 | 31.9 | 375 | 13.23 | 88% |
| GWS HD 8x4 | 1 | 9.9 | 6.9 | 68 | 9360 | 35.5 | 460 | 16.23 | 88% |
| GWS HD 8x4 | 1 | 10.8 | 7.95 | 85 | 10110 | 38.3 | 544 | 19.19 | 87% |
| GWS HD 9x5 | 1 | 6.9 | 6.55 | 45 | 6240 | 29.6 | 383 | 13.51 | 84% |
| GWS HD 9x5 | 1 | 7.9 | 8.05 | 63 | 6930 | 32.8 | 484 | 17.07 | 82% |
| GWS HD 9x5 | 1 | 8.9 | 9.65 | 85 | 7680 | 36.4 | 597 | 21.06 | 80% |
| GWS HD 9x5 | 1 | 9.8 | 11.3 | 110 | 8340 | 39.5 | 702 | 24.76 | 79% |
| GWS HD 9x5 | 1 | 10.8 | 13.05 | 140 | 8970 | 42.5 | 822 | 29.00 | 77% |
| GWS HD 10x6 | 1 | 6.9 | 8.35 | 57 | 5880 | 33.4 | 466 | 16.44 | 79% |
| GWS HD 10x6 | 1 | 7.8 | 10.1 | 78 | 6510 | 37.0 | 575 | 20.28 | 78% |
| GWS HD 10x6 | 1 | 8.8 | 12 | 105 | 7140 | 40.6 | 691 | 24.37 | 75% |
| GWS HD 10x6 | 1 | 9.8 | 13.9 | 136 | 7710 | 43.8 | 804 | 28.36 | 73% |
| GWS HD 10x6 | 1 | 10.7 | 16.05 | 171 | 8250 | 46.9 | 920 | 32.45 | 72% |
| GWS HD 3T 10x6 | 1 | 6.8 | 10.35 | 70 | 5460 | 31.0 | 531 | 18.73 | 75% |
| GWS HD 3T 10x6 | 1 | 7.8 | 12.6 | 98 | 6040 | 34.3 | 663 | 23.39 | 72% |
| GWS HD 3T 10x6 | 1 | 8.8 | 14.6 | 128 | 6580 | 37.4 | 770 | 27.16 | 70% |
| GWS HD 3T 10x6 | 1 | 9.8 | 17.05 | 167 | 7100 | 40.3 | 914 | 32.24 | 67% |
| GWS HD 3T 10x6 | 1 | 10.7 | 19.1 | 204 | 7540 | 42.8 | 1030 | 36.33 | 66% |
| APC E 11x5.5 | 1 | 6.8 | 10.2 | 69 | 5520 | 28.8 | 549 | 19.37 | 76% |
| APC E 11x5.5 | 1 | 7.8 | 12.6 | 98 | 6090 | 31.7 | 693 | 24.44 | 73% |
| APC E 11x5.5 | 1 | 8.7 | 14.7 | 127 | 6570 | 34.2 | 818 | 28.85 | 70% |
| APC E 11x5.5 | 1 | 9.7 | 17.15 | 166 | 7020 | 36.6 | 960 | 33.86 | 67% |
| APC E 11x5.5 | 1 | 10.7 | 19.5 | 208 | 7530 | 39.2 | 1090 | 38.45 | 65% |
| GWS HD 11x7 | 1 | 6.8 | 11.8 | 80 | 5250 | 34.8 | 610 | 21.52 | 72% |
| GWS HD 11x7 | 1 | 7.8 | 14.2 | 110 | 5790 | 38.4 | 739 | 26.07 | 69% |
| GWS HD 11x7 | 1 | 8.7 | 16.7 | 145 | 6270 | 41.6 | 855 | 30.16 | 67% |
| GWS HD 11x7 | 1 | 9.7 | 19.2 | 186 | 6660 | 44.1 | 1015 | 35.80 | 64% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 11x7 | 1 | 10.7 | 21.2 | 226 | 7020 | 46.5 | 1111 | 39.19 | 61% |
