LittleScreamers - Super Park Jet
Specifications
- Type: Outrunner
- Weight: 42.00g (1.48oz)
- Maximum Amps: 20
Constants
- kV: 1845
- Rm: 0.205
- Io: 1.2
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 6.985 | 0.91 | 12450 |
| 8 | 1.01 | 14310 |
| 10.02 | 1.2 | 17940 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 4.1x4.1 | 1 | 6.9 | 2.9 | 20 | 11850 | 46.0 | 81 | 2.86 | 93% |
| APC E 4.1x4.1 | 1 | 7.9 | 3.4 | 26 | 13410 | 52.1 | 105 | 3.70 | 92% |
| APC E 4.1x4.1 | 1 | 8.9 | 4 | 35 | 14970 | 58.1 | 131 | 4.62 | 91% |
| APC E 4.1x4.1 | 1 | 9.9 | 4.7 | 46 | 16500 | 64.1 | 162 | 5.71 | 90% |
| APC E 4.1x4.1 | 1 | 10.9 | 5.5 | 59 | 18030 | 70.0 | 192 | 6.77 | 90% |
| Graupner CAM Speed 4.7x4.7 | 1 | 6.9 | 4.35 | 30 | 11400 | 50.7 | 123 | 4.34 | 90% |
| Graupner CAM Speed 4.7x4.7 | 1 | 7.9 | 5.3 | 41 | 12810 | 57.0 | 156 | 5.50 | 88% |
| Graupner CAM Speed 4.7x4.7 | 1 | 8.9 | 6.2 | 55 | 14220 | 63.3 | 193 | 6.81 | 87% |
| Graupner CAM Speed 4.7x4.7 | 1 | 9.9 | 7.25 | 71 | 15510 | 69.0 | 233 | 8.22 | 85% |
| Graupner CAM Speed 4.7x4.7 | 1 | 10.9 | 8.4 | 91 | 16770 | 74.6 | 272 | 9.59 | 83% |
| Cox Thimbledrone 5x4 | 1 | 10.8 | 7.7 | 83 | 16860 | 63.9 | 350 | 12.35 | 85% |
| Zagi Carbon 5.1x4.9 | 1 | 6.9 | 5.05 | 34 | 11100 | 51.5 | 176 | 6.21 | 87% |
| Zagi Carbon 5.1x4.9 | 1 | 7.9 | 6.2 | 48 | 12480 | 57.9 | 226 | 7.97 | 86% |
| Zagi Carbon 5.1x4.9 | 1 | 8.9 | 7.4 | 65 | 13800 | 64.0 | 277 | 9.77 | 84% |
| Zagi Carbon 5.1x4.9 | 1 | 9.9 | 8.6 | 85 | 15000 | 69.6 | 328 | 11.57 | 82% |
| Zagi Carbon 5.1x4.9 | 1 | 10.8 | 9.85 | 106 | 16200 | 75.2 | 383 | 13.51 | 81% |
| APC E 6x4 | 1 | 6.9 | 6 | 41 | 10800 | 40.9 | 227 | 8.01 | 85% |
| APC E 6x4 | 1 | 7.9 | 7.3 | 57 | 12060 | 45.7 | 292 | 10.30 | 83% |
| APC E 6x4 | 1 | 8.9 | 8.75 | 77 | 13320 | 50.5 | 363 | 12.80 | 81% |
| APC E 6x4 | 1 | 9.8 | 10.05 | 98 | 14460 | 54.8 | 433 | 15.27 | 80% |
| APC E 6x4 | 1 | 10.8 | 11.55 | 124 | 15540 | 58.9 | 533 | 18.80 | 78% |
| APC E 6x4 | 1 | 13.6 | 15.75 | 214 | 18390 | 69.7 | 705 | 24.87 | 73% |
| EMP 6x4 | 1 | 13.6 | 17.35 | 235 | 17760 | 67.3 | 809 | 28.54 | 71% |
| APC E 6x5.5 | 1 | 6.9 | 8.2 | 56 | 10080 | 52.5 | 223 | 7.87 | 79% |
| APC E 6x5.5 | 1 | 7.8 | 9.9 | 77 | 11190 | 58.3 | 282 | 9.95 | 78% |
| APC E 6x5.5 | 1 | 8.8 | 11.5 | 101 | 12330 | 64.2 | 347 | 12.24 | 76% |
| APC E 6x5.5 | 1 | 9.8 | 13 | 127 | 13380 | 69.7 | 419 | 14.78 | 74% |
| APC E 6x5.5 | 1 | 10.8 | 14.7 | 158 | 14340 | 74.7 | 485 | 17.11 | 72% |
| APC E 6x5.5 | 1 | 13.6 | 19.8 | 269 | 16950 | 88.3 | 693 | 24.44 | 68% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| APC E 7x5 | 1 | 6.8 | 10.65 | 72 | 9300 | 44.0 | 390 | 13.76 | 74% |
| APC E 7x5 | 1 | 7.8 | 12.7 | 99 | 10230 | 48.4 | 482 | 17.00 | 71% |
| APC E 7x5 | 1 | 8.7 | 15 | 130 | 11040 | 52.3 | 563 | 19.86 | 69% |
| APC E 7x5 | 1 | 9.7 | 17.5 | 169 | 11820 | 56.0 | 653 | 23.03 | 66% |
| APC E 7x5 | 1 | 10.7 | 19.6 | 209 | 12420 | 58.8 | 725 | 25.57 | 63% |
| APC E 7x5 | 1 | 13.2 | 25.3 | 333 | 13890 | 65.8 | 931 | 32.84 | 57% |
Comments
Dr Kiwi on 2009-04-10 22:57:02
My tests indicate a very different Kv (1845Kv v. 2350Kv) and max. amps (20A v. 30A/390W) from those suggested by Littlescreamers.
