GWS - 2205/15T
Specifications
- Type: Outrunner
Constants
- kV: 2257
- Rm: 0.21
- Io: 0.8
Io Test Data
Bruce Abbot test results
| Volts | Amps | RPM |
|---|---|---|
| 7.5 | 0.8 | 0 |
Test Data
Bruce Abbot test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS EP 6x3 | 1 | 7.1 | 6 | 42 | 13070 | 37.1 | 256 | 9.03 | 82% |
| GWS EP 6x5 | 1 | 6.7 | 10.6 | 71 | 10010 | 47.4 | 273 | 9.63 | 66% |
| GWS EP 7x3.5 | 1 | 6.4 | 7.5 | 48 | 10900 | 36.1 | 299 | 10.55 | 75% |
| APC SF 7x4 | 1 | 6.4 | 11.2 | 71 | 8982 | 34.0 | 350 | 12.35 | 62% |
| GWS EP 8x4 | 1 | 6.5 | 12.3 | 79 | 8821 | 33.4 | 426 | 15.03 | 60% |
