HXT - D1811-2000
Specifications
- Type: Outrunner
Constants
- kV: 2168
- Rm: 0.79
- Io: 0.26
Io Test Data
Bruce Abbot test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.26 | 0 |
Test Data
Bruce Abbot test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS EP 4x2.5 | 1 | 7 | 1.46 | 10 | 12370 | 29.3 | 61 | 2.15 | 82% |
| GWS EP 4.5x3 | 1 | 7 | 2.13 | 14 | 11250 | 32.0 | 82 | 2.89 | 74% |
| Graupner CAM Folding 4.7x2.4 | 1 | 7 | 2.06 | 14 | 11330 | 25.8 | 77 | 2.72 | 75% |
| GWS EP 5x3 | 1 | 7 | 2.36 | 16 | 10830 | 30.8 | 107 | 3.77 | 71% |
| GWS EP 5x4.3 | 1 | 7 | 3.15 | 22 | 9450 | 38.5 | 109 | 3.84 | 62% |
| GWS EP 7x3.5 | 1 | 7 | 3.91 | 27 | 8051 | 26.7 | 153 | 5.40 | 53% |
wjbite test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 5x3 | 1 | 11.1 | 5.4 | 59 | 16000 | 45.0 | 229 | 8.10 | 66% |
| GWS HD 6x3 | 1 | 7.2 | 4.1 | 29 | 10000 | 28.0 | 158 | 5.60 | 64% |
