GPS - 2830-D
Specifications
- Type: Outrunner
- Weight: 61.00g (2.15oz)
- Diameter: 27.80mm (1.09in)
- Length: 31.00mm (1.22in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 12
Constants
- kV: 740
- Rm: 0.37
- Io: 0.7
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 0.7 | 7230 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 8x8 | 1 | 10.9 | 6.85 | 74 | 6180 | 46.8 | 320 | 11.29 | 77% |
| APC E 8x8 | 1 | 14.6 | 10.35 | 151 | 7680 | 58.2 | 507 | 17.88 | 71% |
| GWS HD 9x5 | 1 | 7 | 2.5 | 17 | 4500 | 21.3 | 191 | 6.74 | 87% |
| GWS HD 9x5 | 1 | 7.9 | 3 | 23 | 5040 | 23.9 | 241 | 8.50 | 86% |
| GWS HD 9x5 | 1 | 8.9 | 3.6 | 32 | 5580 | 26.4 | 301 | 10.62 | 85% |
| GWS HD 9x5 | 1 | 9.9 | 4.25 | 42 | 6120 | 29.0 | 368 | 12.98 | 84% |
| GWS HD 9x5 | 1 | 10.9 | 4.9 | 53 | 6630 | 31.4 | 432 | 15.24 | 82% |
| GWS HD 9x5 | 1 | 14.6 | 7.7 | 112 | 8400 | 39.8 | 710 | 25.04 | 78% |
| GWS HD 10x6 | 1 | 6.9 | 3.3 | 22 | 4290 | 24.4 | 248 | 8.75 | 84% |
| GWS HD 10x6 | 1 | 7.9 | 4 | 31 | 4800 | 27.3 | 315 | 11.11 | 82% |
| GWS HD 10x6 | 1 | 8.9 | 4.75 | 42 | 5310 | 30.2 | 385 | 13.58 | 81% |
| GWS HD 10x6 | 1 | 9.9 | 5.5 | 54 | 5790 | 32.9 | 450 | 15.87 | 79% |
| GWS HD 10x6 | 1 | 10.9 | 6.35 | 69 | 6240 | 35.5 | 531 | 18.73 | 77% |
| GWS HD 10x6 | 1 | 14.6 | 9.7 | 141 | 7770 | 44.1 | 832 | 29.35 | 72% |
| GWS HD 11x7 | 1 | 6.9 | 4.7 | 32 | 3930 | 26.1 | 338 | 11.92 | 77% |
| GWS HD 11x7 | 1 | 7.9 | 5.7 | 45 | 4380 | 29.0 | 420 | 14.82 | 75% |
| GWS HD 11x7 | 1 | 8.9 | 6.7 | 59 | 4740 | 31.4 | 500 | 17.64 | 72% |
| GWS HD 11x7 | 1 | 9.8 | 7.7 | 75 | 5160 | 34.2 | 577 | 20.35 | 71% |
| GWS HD 11x7 | 1 | 10.8 | 8.8 | 95 | 5520 | 36.6 | 675 | 23.81 | 69% |
| GWS HD 12x8 | 1 | 6.9 | 6.05 | 41 | 3600 | 27.3 | 408 | 14.39 | 71% |
| GWS HD 12x8 | 1 | 7.9 | 7.2 | 56 | 3960 | 30.0 | 492 | 17.35 | 68% |
| GWS HD 12x8 | 1 | 8.8 | 8.4 | 73 | 4290 | 32.5 | 578 | 20.39 | 66% |
| GWS HD 12x8 | 1 | 9.8 | 9.55 | 93 | 4620 | 35.0 | 661 | 23.32 | 64% |
| GWS HD 12x8 | 1 | 10.8 | 10.75 | 116 | 4860 | 36.8 | 745 | 26.28 | 61% |
