EP - 2212-1330
Specifications
- Type: Outrunner
- Weight: 55.00g (1.94oz)
- Maximum Amps: 25
Constants
- kV: 1500
- Rm: 0.155
- Io: 1.45
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.3 | 10290 |
| 8 | 1.35 | 11700 |
| 10 | 1.45 | 14580 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| Zagi Carbon 5.1x4.9 | 1 | 6.9 | 3.6 | 24 | 9720 | 45.1 | 135 | 4.76 | 94% |
| Zagi Carbon 5.1x4.9 | 1 | 7.9 | 4.3 | 33 | 11220 | 52.1 | 173 | 6.10 | 95% |
| Zagi Carbon 5.1x4.9 | 1 | 8.9 | 5.1 | 45 | 12300 | 57.1 | 215 | 7.58 | 92% |
| Zagi Carbon 5.1x4.9 | 1 | 9.9 | 5.9 | 58 | 13380 | 62.1 | 258 | 9.10 | 90% |
| Zagi Carbon 5.1x4.9 | 1 | 10.8 | 6.75 | 72 | 14550 | 67.5 | 305 | 10.76 | 90% |
| Zagi Carbon 5.1x4.9 | 1 | 14 | 9.95 | 139 | 18240 | 84.6 | 474 | 16.72 | 87% |
| APC E 6x4 | 1 | 6.9 | 4.4 | 30 | 9480 | 35.9 | 176 | 6.21 | 92% |
| APC E 6x4 | 1 | 7.9 | 5.3 | 41 | 10830 | 41.0 | 230 | 8.11 | 91% |
| APC E 6x4 | 1 | 8.9 | 6.25 | 55 | 11970 | 45.3 | 287 | 10.12 | 90% |
| APC E 6x4 | 1 | 9.9 | 7.3 | 72 | 13110 | 49.7 | 353 | 12.45 | 88% |
| APC E 6x4 | 1 | 10.8 | 8.4 | 90 | 14160 | 53.6 | 418 | 14.74 | 87% |
| APC E 6x5.5 | 1 | 6.9 | 6.05 | 41 | 9240 | 48.1 | 186 | 6.56 | 89% |
| APC E 6x5.5 | 1 | 7.9 | 7.2 | 56 | 10500 | 54.7 | 237 | 8.36 | 89% |
| APC E 6x5.5 | 1 | 8.8 | 8.5 | 74 | 11400 | 59.4 | 295 | 10.41 | 86% |
| APC E 6x5.5 | 1 | 9.8 | 9.7 | 95 | 12540 | 65.3 | 364 | 12.84 | 85% |
| APC E 6x5.5 | 1 | 10.8 | 10.9 | 117 | 14280 | 74.4 | 435 | 15.34 | 88% |
| APC E 6x5.5 | 1 | 14 | 16 | 224 | 16740 | 87.2 | 660 | 23.28 | 80% |
| APC E 7x5 | 1 | 6.9 | 8.15 | 56 | 8700 | 41.2 | 341 | 12.03 | 84% |
| APC E 7x5 | 1 | 7.8 | 9.9 | 77 | 9660 | 45.7 | 426 | 15.03 | 83% |
| APC E 7x5 | 1 | 8.8 | 11.75 | 103 | 10590 | 50.1 | 521 | 18.38 | 80% |
| APC E 7x5 | 1 | 9.8 | 13.8 | 135 | 11520 | 54.5 | 620 | 21.87 | 78% |
| APC E 7x5 | 1 | 10.7 | 15.8 | 169 | 12360 | 58.5 | 719 | 25.36 | 77% |
| APC Sport 7x7 | 1 | 6.9 | 8.95 | 61 | 8580 | 56.9 | 313 | 11.04 | 83% |
| APC Sport 7x7 | 1 | 7.8 | 10.9 | 85 | 9540 | 63.2 | 394 | 13.90 | 82% |
| APC Sport 7x7 | 1 | 8.8 | 12.85 | 113 | 10440 | 69.2 | 474 | 16.72 | 79% |
| APC Sport 7x7 | 1 | 9.8 | 14.9 | 146 | 11340 | 75.2 | 560 | 19.75 | 77% |
| APC Sport 7x7 | 1 | 10.7 | 16.9 | 180 | 12060 | 79.9 | 644 | 22.72 | 75% |
| GWS HD 8x4 | 1 | 6.9 | 7.95 | 54 | 8790 | 33.3 | 408 | 14.39 | 85% |
| GWS HD 8x4 | 1 | 7.8 | 9.65 | 75 | 9750 | 36.9 | 508 | 17.92 | 83% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 8x4 | 1 | 8.8 | 11.5 | 101 | 10710 | 40.6 | 617 | 21.76 | 81% |
| GWS HD 8x4 | 1 | 9.8 | 13.5 | 132 | 11610 | 44.0 | 738 | 26.03 | 79% |
| GWS HD 8x4 | 1 | 10.7 | 15.45 | 165 | 12390 | 46.9 | 850 | 29.98 | 77% |
| APC E 8x6 | 1 | 6.8 | 13.3 | 90 | 7650 | 43.5 | 442 | 15.59 | 75% |
| APC E 8x6 | 1 | 7.8 | 16.3 | 127 | 8370 | 47.6 | 540 | 19.05 | 72% |
| APC E 8x6 | 1 | 8.7 | 19.2 | 167 | 9030 | 51.3 | 635 | 22.40 | 69% |
| APC E 8x6 | 1 | 9.6 | 21.8 | 209 | 9510 | 54.0 | 700 | 24.69 | 66% |
| APC E 8x6 | 1 | 10.6 | 24.7 | 261 | 10050 | 57.1 | 792 | 27.94 | 63% |
| GWS HD 9x5 | 1 | 6.8 | 12.65 | 86 | 7680 | 36.4 | 594 | 20.95 | 75% |
| GWS HD 9x5 | 1 | 7.7 | 15.35 | 118 | 8460 | 40.1 | 732 | 25.82 | 73% |
| GWS HD 9x5 | 1 | 8.7 | 18 | 156 | 9210 | 43.6 | 866 | 30.55 | 71% |
| GWS HD 9x5 | 1 | 9.6 | 20.5 | 196 | 9840 | 46.6 | 994 | 35.06 | 68% |
